LEGRAND 1 991 05 Quick Start Manual

Plug & Play Gateway
1 991 05
The Plug & Play Gateway makes it easy to connect all connected solutions «with Netatmo» and
Zigbee 3.0 lighting. It plugs into an existing power socket and simply connects to the Wi-Fi network
of your internet router
Pack composition
Installation steps
Plug the gateway into an easily accessible protected socket
with a maximum 16 a circuit breaker.
Complete your installation:
Your Legrand connected installation is scalable. You can easily add all Legrand connected solutions (to be found on legrand.com),
Netatmo products or even Zigbee 3.0 certi ed lighting products from other brands.
And so, customise your scenarios and schedules via the Home + Control App.
Wireless 4 scenes switches
5 743 12/13/14/15
x1
Plug & Play Gateway
Wireless light switches
5 742 44/45/46/47
Apple HomeKit: When you install the iOS mobile application, you will
be asked for this code
Con guration button
Download the Home + Control App and follow the
instructions to add wired and wireless products to your
installation.
You are ready to control your installation via a vocal assistant
and can customise your scenarios via the Home + Control App.
Connected mobile
socket outlet
0 648 89
Unique Apple HomeKit installation code to be kept
S I M P L Y
CONNECTED
Frequency band: 2.4 to 2.4835 GHz
Power level: < 100 mW
Wireless home/away
master switches
5 742 06/15/24/33
