No: 9000249 – 02/18 rev. 2
Qsync
Country of Origin: Made in China
•
Smartphone and tablet control from many units on the same Qsync network system
•
Sends QMotion commands as a standard remote would
•
Use pictures and names to identify groups or zones
•
Create groups that can be controlled together
•
Set up once on a single device, then the settings load to the other smartphones and tablets automatically
Verify the contents of the Qsync
package and gather materials:
A. Ethernet Cable
B. Qsync
C. Antenna
D. Power Adapter
QMotion's Qsync™ is a network gateway for QMotion automated shades. The
Qsync system with the QMotion app enables control of all QMotion products
including motorized roller shades, honeycomb shades, and motorized drapery
rods. QMotion shades move up and down easier than sending a text message.
The updated version is available for iOS and Android.
The Qsync application is compatible with both Gen2 and Gen3 shades. Please
confirm the correct Qsync is installed to match the technology of the shades.
FEATURES AND OPERATION OVERVIEW
IDENTIFY PARTS OF THE QSYNC PACKAGE
A
C
QMotion
®
Qsync™ Network Gateway
Installation Instructions
OVERVIEW
COMPATIBILITY
B
D
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for LEGRAND QMotion Qsync
Summary of Contents for LEGRAND QMotion Qsync
- Page 1 QMotion ® Qsync™ Network Gateway Installation Instructions No: 9000249 – 02/18 rev. 2 Qsync Country of Origin: Made in China OVERVIEW QMotion’s Qsync™ is a network gateway for QMotion automated shades. The Qsync system with the QMotion app enables control of all QMotion products including motorized roller shades, honeycomb shades, and motorized drapery rods.
- Page 2 WiFi network. INSTALLING THE QSYNC APP Download and Install the “QMotion Qsync” app from the App Store or Google Play by searching under that name. Open the QMotion Qsync app. The screen shown allows you to select Qsync devices on the same WiFi network.
- Page 3 ADDING A GROUP AND ADD/DELETE SHADES IN A GROUP Name the group. Add shades by selecting Add Shades. Delete shades by selecting Remove Shades. Follow on-screen To add a group of shades, tap to add a new group. instructions for each. Shades can You can also swipe from the left to be added to one or multiple groups.
- Page 4 DELETING A SHADE GROUP Choose the group name that you wish to delete. For Apple Devices, swipe that name to the left. For Android Device, press and hold the group name you wish to delete. Then you will see an option to delete the group. Tap the red delete button to delete that group.
-
Page 5: Troubleshooting
USING QSYNC WITH SCENES You can add one or multiple groups to a scene. You can also set the position for each group within that scene to a desired setting. When To begin, tap on the main page. Then to add a new scene. You you access the scene, all the shade select the scenes section. - Page 6 TROUBLESHOOTING (continued) GROUP DELETION AND ADDITION 1. Shades are added to groups based on “Channel Numbers” which are a simple identifier number linking them to the group NOTE: Max # groups supported: AM/FM: 200 2. Shades are NOT added to groups based on group names. 3.
- Page 7 IEC 61000-4-2: Ed. 2.0 IEC 61000-4-3: Ed. 3.2 CISPR 16-2-3 1st Ed.2003 No. IS-9000249 – 02/18 rev. 2 © Copyright 2017 Legrand All Rights Reserved. © Copyright 2017 Tous droits réservés Legrand. 800.555.9891 © Copyright 2017 Legrand Todos los derechos reservados. www.legrand.us/qmotion...
