Open Web Net/Zigbee Gateway
Description
Interface for interaction with the functions of the ZigBee radio system using a Personal
Computer and an Open Web Net communication protocol.
The device must be connected to a USB port of the computer and features a radio
transmitter for sending/receiving data to and from ZigBee devices installed in the
electric system.
Technical data
Power supply:
From USB 2.0 socket
Operating temperature:
5 – 45 °C
Technology:
Radio 2.4 GHz standard ZigBee®
Capacity:
150 m free field, 15 m in rooms with concrete walls
Front view
1
4
Side view
Legend
1. USB connector
2. Data traffic indicator LED
3. NETWORK key
4. NETWORK LED
Technical sheets - Radio system MY HOME
0883 28
3578
2
3
1
Advertisement
Table of Contents
Related Manuals for LEGRAND bticino 0883 28 3578
Summary of Contents for LEGRAND bticino 0883 28 3578
- Page 1 Open Web Net/Zigbee Gateway 0883 28 3578 Description Front view Interface for interaction with the functions of the ZigBee radio system using a Personal Computer and an Open Web Net communication protocol. The device must be connected to a USB port of the computer and features a radio transmitter for sending/receiving data to and from ZigBee devices installed in the electric system.
- Page 2 TechNical sheeTs 0883 28 3578 Configuration Connecting the device to the network Disconnecting the interface from the network 1. In the system identify the actuator device with “ZigBee network coordinator” 1. Press the NETWORK key on the interface. The NETWORK LED will flash quickly. function, and press the NETWORK key for 3 seconds.
