SUPER 3600 ICE AA31024 RIB يتم ضمان التشغيل الصحيح للمشغل فقط في حالة إدارته بواسطة لوحة تحكم The correct operation of the operator is guaranteed only if it is managed by a RIB control panel 3 / الصفحة العربيةENGLISH page 5...
Page 2
الحد األدنى وsqmm 1،5 معH05RN -F برقية نوعRIB 2 ° - لل قسم ونوع من النصائح الستخدام الكابالت 3° - Positioning of a possible couple of photoelectric cells: the radius of the photoelectric cells ....
Page 3
يمكن ضبط وقت اإليقاف المؤقت (للبوابة المفتوحة مع التحكمPED.( .من ثانيتين على األقل إلى 03 ثانية كحد أقصى 2: ضبط نهاية املسار في برغي الفتح وإدارته 3 مراتRIB )الصحيح، ثم إدخال مفتاح آلين (مفتاح مسدس األضالع .بعكس اتجاه عقارب الساعة...
Page 4
.هام: يجب أن يتطا بق النظام مع كل ا ملعا يري والتوجيهات ا ملعمول بها حال ي ً ا .L1 لالستفادة من جميع الوظائف املتقدمة التي ميكن أن يقدمها لك مجلسRIB GATE App + مع وحداتها) واستخدام هاتفك الذيك مع تطبيقAPP (أو بطاقةAPP تنبيه: • قم بتثبيت بطاقة...
Page 5
The sump with the appropriate key must be opened. below, therefore releasing the G nuts. Insert the RIB hex key in the release screw and turn it 3 times anti-clockwise. Move the mobile part manually to establish the To restore the electric functioning, operate in the opposite direction.
Page 6
IMPORTANT: The system must comply with all the standards and Directives currently in force. ATTENTION: Install the APP card (or the APP+ card with its modules) and use your smartphone with the RIB GATE App to take advantage of all the advanced features that the...
SYSTEM LAY-OUT A - SUPER 3600 operator B - Photoelectric cells (external) C - Rack M6 D - Key selector E - Tuned aerial F - Flashing lamp H - Galvanized column for P.E. cells I - Photo electric cells (internal)
Page 8
INSTALLATION SUPER 3600 CHECKING BEFORE THE INSTALLATION !! THE GATE SHALL MOVE FRICTIONLESS !! 2” N.B.: Gate features must be uniformed with the standards and laws in force. The door/gate can be automated only if it is in a good condition and its conditions comply with the EN 12604 norm.
Page 9
MOTOR AND RACK INSTALLATION The rack must be fixed at a certain height with respect to the motor base. This height can be varied thanks to the slots on the rack. The height needs to be adjusted so that the gate does not rest on the reduction unit traction gear (Fig.
ELECTRIC CONNECTIONS L1 code AC08082 Interactive online manuals...
Page 11
+ 24 Vdc accessories power supply / Common contacts RADIO Connector for radio module ACG8069 - 24 Vdc accessories power supply RADIO Connector for radio receiver RIB, 24 Vdc supply A+ TEST + 24 Vdc photocells self-test power supply 433 MHz Radio antenna COM A+ Common contacts / Positive 24 Vdc PROG.
Page 12
POINT B - SETTINGS OPEN OPEN command (NO) (green) DIP 1 MAINTENANCE CHECK (See Page 36) PROBE DIP 2 TIMES PROGRAMMING (See Point C) IS NOT AVAILABLE DIP 2-1 PROGRAMMING OF PEDESTRIAN OPENING (See Point D) DIP 1-2 SAVE/DELETE RADIO CODES FOR COMPLETE OPENING (DIP 1 ON followed by DIP 2 ON) POINT C - TIMES PROGRAMMING (POINT E) DIP 1-3...
Page 13
control. Wait 4 seconds for the procedure to exit. The flasher will turn off. ALL RADIO CODES FOR TOTAL OPENING CANCELLATION PROCEDURE If you do not want to use this function, set DIP 3 to ON to deactivate it. Cancellations can only be performed when gate is stationary. 1 - Set DIP 1 to ON and then DIP 2 to ON.
a second, even if they are still engaged). DIP 5 OFF => motor and blinker start simultaneously. ATTENTION: In case the receiver led remains lit, malfunctioning of the main supply is DIP 5 ON => blinker starts 3 s before the motor. suspected.
Page 15
In case of no ignition of the LEDS, always with gate in intermediate position, check the following and replace any faulty components. Stop button malfunction (if Stop is not connected, perform the jump between COM A+ and STOP). DL7 or DL8 Faulty photocells (In case the edge is not connected, carry out jumper between COM A+ and PHOTO 1/PHOTO 2) DL9 or DL10...
Page 16
FAULT SOLUTION After having carried out the various connections and having supplied voltage, all the LEDS are On the board there are resettable fuses which intervene in the event of a short circuit, switched OFF. interrupting the output assigned to them. In the event of troubleshooting, it is advisable to disconnect all the removable connectors and insert them one at a time in order to more easily identify the cause of the fault.
Page 17
ACCESSORIES - For the connections and the technical data of the optional equipments follow the relevant handbooks. APP8050 APP card APP8054 APP+ card to manage the control panel using to manage the control panel using Bluetooth 4.2 transmission Bluetooth 4.2 transmission APP8064 Wi-Fi module for APP+ card APP8066 RJ45 module for APP+ card to manage the control panel using the...
Page 18
PHOTOCELLS CONNECTIONS 4 FIT SLIM / FIT SYNCRO photocells with self-test and infrared signal synchronizer 2 photocells FIT SLIM, FIT SYNCRO with self-test TX SYNCRO COM A+ COM A+ cod. ACG8028 A+ TEST PHOT1 PHOT2 A+ TEST PHOT1 PHOT2 cod. ACG8029 A*D+ A*D+ A*D+...
