External Monitor
You can add a standard external monitor to your NEC Versa FXi system using a
display signal cable (usually provided with the monitor). One end of the cable must
have a 15-pin connector for the system.
Follow these steps to connect an external monitor to your NEC Versa.
Check that power to both the NEC Versa and the monitor is off.
1.
Open the monitor port cover at the far left on the back of the system.
2.
3. Attach the 15-pin cable connector to the monitor port on the system. Secure the
cable connection with the screws provided.
Connect the monitor power cable and plug it into a properly grounded wall outlet.
4.
Follow any setup instructions in the monitor's user's guide.
5.
6. Turn on power to the system and device.
Press
7.
8-2 Using External Devices
Connecting a monitor
to toggle through the video modes.
Fn-F3
