Jensen SPX-11 Quick Start Manual

Speaker System with inbuilt dual Subwoofers.
Congratulations on investing in one of
Systems. You will find this information valuable for the long term
Part A & Part B.
should be marked "PART A" and the other "PART B". Part A houses a powerful 160 Watt Subwoofer
amplifier that requires connection to a power point.
Your JENSEN SPX-11's
stereo listening as well as Home Theatre listening. Subwoofer enclosures are built into the bottom section
of each speaker box. These "twin" subwoofers are self powered by an onboard 160 Watt RMS amplifier.
By having a speaker system that has inbuilt powered subwoofers, there is reduced need for "extra"
component subwoofer enclosures cluttering up your lounge room, although, you can still add-on extra
JENSEN subwoofers to your SPX-11's if you wish.
Room placement.
location. The SPX-11 side-firing subwoofers are located on opposite sides of each box and can face
"inwards" (towards each other) or "outwards" (away from each other). Bass response can vary
enormously pending room acoustics so we suggest try both. Best positioning for your SPX-11's is to
stand them appx. 10-20cm from a wall. This will enable the rear ports to breathe efficiently and provide
maximum acoustic coupling into your room. i.e. more efficient Bass.
Connection Tip 1.
connections first.
Connection Tip 2.
positives, and all negatives (-) connect to negatives. Severe Bass loss will result if reversed. Ensure all
speaker leads and gold terminal connectors are screwed tight and that gold screw terminals are firmly in
place between top and bottom gold connectors.
Option 1 or 2 ?
recommend you connect using OPTION 2 as per following page illustrations.
Spikes.
Spikes are fitted to both SPX-11 enclosures to maximize performance. Gold tip on each
spike-foot is adjustable so that enclosures can be leveled and stabilized. It is recommended to use these
spikes, however, if floor surface prevents, you may remove gold tips or remove spike-feet completely. If
the latter, cover revealed screw holes with 4 padded discs (supplied) to prevent air leaking.
SPX-11
enjoyment of your SPX-11's.
Firstly, please ensure both cartons you have are a matched pair. One carton
are an integrated Active Speaker System designed for Hi-Fi
Part A can be either your left or right speaker pending power point
Be sure to connect your SPX-11 to power point last. Make all other
It is most important that all Speaker Lead positives (+) connect to
If you are using a Dolby Digital Multi Channel receiver (5.1, 6.1 or 7.1) we
's finest ever Speaker
