KA01696F/00/EN/01.24-00
71647156
2024-02-01
Products
Brief Operating Instructions
Liquiphant FTL43
HART
Vibronic
Point level switch for liquids
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet:
www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services
Advertisement
Table of Contents
Related Manuals for Endress+Hauser Liquiphant FTL43 HART
Summary of Contents for Endress+Hauser Liquiphant FTL43 HART
- Page 1 Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation: Available for all device versions via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App...
-
Page 2: Associated Documentation
Associated documentation Liquiphant FTL43 HART Associated documentation Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 About this document Document function The Brief Operating Instructions contain all the essential information from incoming acceptance to initial commissioning. - Page 3 Liquiphant FTL43 HART About this document Symbols 2.2.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.
-
Page 4: Registered Trademarks
Android, Google Play and the Google Play logo are trademarks of Google Inc. Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and trade names are those of their respective owners. HART®... -
Page 5: Basic Safety Instructions
Do not touch or clean device surfaces with pointed or hard objects. Clarification for borderline cases: ‣ For special media and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability. -
Page 6: Product Security
It left the factory in a condition in which it is safe to operate. The device fulfills general safety requirements and legal requirements. It also complies with the EU directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms this fact by affixing the CE mark. IT security Our warranty is valid only if the product is installed and used as described in the Operating Instructions. -
Page 7: Incoming Acceptance And Product Identification
Liquiphant FTL43 HART Incoming acceptance and product identification • Without the SmartBlue app, the device is not visible via Bluetooth® wireless technology. • Only one point-to-point connection is established between the device and a smartphone or tablet. • The Bluetooth® wireless technology interface can be disabled via onsite operation or via SmartBlue. -
Page 8: Storage And Transport
Incoming acceptance and product identification Liquiphant FTL43 HART • Firmware version, hardware version • Approval-specific information • DataMatrix code (information about the device) Compare the data on the nameplate with your order. 4.2.2 Manufacturer address Endress+Hauser SE+Co. KG Hauptstraße 1 79689 Maulburg, Germany Place of manufacture: See nameplate. -
Page 9: Mounting Requirements
Liquiphant FTL43 HART Mounting Mounting • Any orientation for compact version or version with a tube length up to approx. 500 mm (19.7 in) • Vertical orientation from above for device with long pipe • Minimum distance between the tuning fork and the tank wall or pipe wall: 10 mm (0.39 in) A0053113 ... - Page 10 Mounting Liquiphant FTL43 HART A0037915 3 Typical switch points. Unit of measurement mm (in) Installation from above Installation from below Installation from the side Switch point 5.1.3 Take viscosity into consideration Viscosity values • Low viscosity : < 2 000 mPa⋅s •...
- Page 11 Liquiphant FTL43 HART Mounting High viscosity NOTICE Highly viscous liquids may cause switching delays. ‣ Make sure that the liquid can run off the tuning fork easily. ‣ Deburr the socket surface. High viscosity, e.g. viscous oils: ≤ 10 000 mPa⋅s The tuning fork must be located outside the installation socket! >...
- Page 12 Mounting Liquiphant FTL43 HART A0033239 6 Installation examples for a highly viscous process medium 5.1.5 Take clearance into consideration. Allow sufficient clearance outside the tank for mounting and electrical connection. A0053359 7 Take clearance into consideration. Endress+Hauser...
- Page 13 Liquiphant FTL43 HART Mounting 5.1.6 Support the device Support the device in the event of severe dynamic load. Maximum lateral loading capacity of the pipe extensions and sensors: 75 Nm (55 lbf ft). A0053109 8 Examples of support in the event of dynamic load 5.1.7...
-
Page 14: Mounting The Device
Mounting Liquiphant FTL43 HART Mounting the device 5.2.1 Required tools Open-ended wrench for sensor installation 5.2.2 Installation Aligning the tuning fork using the marking The tuning fork can be aligned using the marking in such a way that the medium drains off easily and buildup is avoided. -
Page 15: Post-Mounting Check
Liquiphant FTL43 HART Mounting A0034851 11 Installation in pipes (take fork position and marking into consideration) Screwing in the device (for process connections with thread) • Turn by the hex bolt only, 15 to 30 Nm (11 to 22 lbf ft) •... -
Page 16: Electrical Connection
Electrical connection Liquiphant FTL43 HART Electrical connection Connecting the device 6.1.1 Potential equalization If necessary, establish potential equalization using the process connection or the grounding clamp supplied by the customer. 6.1.2 Supply voltage 12 to 30 V on a direct current power unit The power unit must be safety-approved (e.g. - Page 17 Liquiphant FTL43 HART Electrical connection 6.1.5 Overvoltage protection The device satisfies the IEC/DIN EN IEC 61326-1 product standard (Table 2 Industrial environment). Depending on the type of port (DC supply, input/output port) different test levels against transient overvoltages (IEC/DIN EN 61000-4-5 Surge) are applied according to IEC/DIN EN 61326-1: Test level on DC power ports and input/output ports is 1 000 V line to earth.
-
Page 18: Ensuring The Degree Of Protection
Operation options Liquiphant FTL43 HART 2-wire 0.5A A0052662 Supply voltage L+, brown wire (BN) OUT (L-), blue wire (BU) Ensuring the degree of protection For mounted M12 connecting cable: IP66/68/69, NEMA type 4X/6P NOTICE Loss of IP protection class due to incorrect installation! ‣... - Page 19 Liquiphant FTL43 HART Commissioning Commissioning Preliminaries WARNING Settings on the current output can result in a safety-related condition (e.g., product overflow)! ‣ Check current output settings. ‣ The setting of the current output depends on the setting in the Assign PV parameter.
- Page 20 Commissioning Liquiphant FTL43 HART 8.4.2 Establishing a connection via FieldCare, DeviceCare and FieldXpert A0044334 14 Options for remote operation via HART protocol PLC (programmable logic controller) Transmitter power supply unit, e.g. RN42 Connection for Commubox FXA195 and AMS Trex...
-
Page 21: Protecting Settings From Unauthorized Access
Liquiphant FTL43 HART Commissioning Simulation 8.7.1 "Simulation" submenu Process variables and diagnostic events can be simulated with the Simulation submenu. Navigation: Diagnostics → Simulation During simulation of the switch output or current output, the device issues a warning message for the duration of the simulation. - Page 24 *71647156* 71647156 www.addresses.endress.com...
