Pro-Ject Audio Systems Debut E Carbon Setup Manual

Debut E Carbon
Setup Guide
Start with this side
1
Unpack all items from accessory bag.
a) RCA cable
b) Standard fl at belt for 33/45 RPM
c) Cartridge alignment protractor
d) Round belt for 78 RPM
e) Anti skating weight
f) Adapter for 7" singles,
Allen key 1.5mm for azimuth setting
4
Carefully remove the protection covering.
Tonearm is fragile!
8
Put the fl at drive belt on the small pulley
and sub-platter.
Manual Speed Change:
Small pulley 33/45 RPM
Large pulley 78 RPM
Remove the stylus protection cover.
12
(Attention! Depending on your location there might
be a diff erent cartridge mounted.)
Turn the front dial of the counterweight
16
(not the whole weight) so the '0' is in line
with marker at the back of the tonearm.
20
Unpack dust cover and put it on the
turntable.
d) d)
a) c)
b)
e)
f)
5
Unpack the counterweight.
9
Put the platter & feltmat on the turntable.
13
Put a record on the platter.
17 Turn the whole counterweight counter-
clockwise until the scale reads 18 - 20.
21
Use the rocker switch on the bottom
left to select the playback speed.
RIGHT: 45 RPM / 78 RPM
LEFT: 33 RPM
STOPS THE MOTOR
Getting started:
• Make sure to have enough space to unpack your turntable.
• Always unpack and set up in a clean enviroment.
• Please Do NOT throw away the packaging! If you need
service or want to return your product, please send them in
the original packaging including all inserts. In case of any
damage in another packaging your dealer cannot guarantee
a full refund.
• Setup is demonstrated with Debut E Carbon
2
Remove dust cover carton from the box.
6
Unpack the power supply.
10
Remove tonearm twist tie.
14
Place the tonearm between platter
and armrest.
Put the loop of the Anti Skating Weight in
18
the second groove on the tonearm post.
Balance the tonearm so it stays level by Balance the tonearm so it stays level by
turning the counterweight forwards and turning the counterweight forwards and
backwards on the rod. backwards on the rod.
22
How to connect the diff erent models +
possible sets on the backside of this sheet.
3
Lift the wrapped turntable out of the box.
7
Unpack the platter.
11
Screw the counterweight in place.
Balance the tonearm so it stays level by
15
turning the counterweight forwards and
backwards on the rod.
19
Plug in power supply.
