DTS BRICK 12 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the BRICK 12 and is the answer not in the manual?

Questions and answers

Related Manuals for DTS BRICK 12

Summary of Contents for DTS BRICK 12

  • Page 3 Release Code:0517I385 For more information Language All trademarks, both marked and not marked, are the property of their respective owners.
  • Page 4 BRICK 12 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S .

  • Page 5: Table Of Contents

    BRICK 12 INDEX: 1- SYMBOLS ................................3 2- GENERAL WARNING ............................4 3- GENERAL WARRANTY CONDITIONS ........................4 The unit is guaranteed for 36 months from the date of purchase against manufacturing material defects..4 4- TECHNICAL FEATURES ............................4 5- ACCESSORIES ...............................

  • Page 6: 1- Symbols

    BRICK 12 1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL INDICATES THE MINIMUM DISTANCE FROM THE ILLUMINATED OBJECTS THIS SYMBOL MEANS “DO NOT STARE...

  • Page 7: 2- General Warning

    BRICK 12 is suitable for various purposes, offering a range of projection angles quickly interchangeable (no tools required). BRICK 12 comes with an IP65 power cable plus 2 DMX cables with M / F XLR connectors (all IP65), that make it perfect for temporary lighting applications, For permanent installations, the IP68 Kit is available on request: IP68 power connector + two IP68 DMX IN/OUT connectors (code 03.LA.214)
  • Page 8 BRICK 12 Control DMX 512 / RDM 10 DMX channels (Default) Power supply Built-in full-range PSU 100-240Vac 50-60 Hz Consumption: 200W Connections Power supply: 3 x 1 sq mm cable (1,5 m length) DMX In/Out: 0,7 m cable with XLR 5 pins IP65 connector...

  • Page 9: 5- Accessories

    • Power supply cable 3 x 1 mm² (Lenght on request) (code 0509C160) • Safety cable 3 x 600 mm - BGV-C1 certified (code:0521A049) -Single stranded: Max 20Kg (44Lbs) -Double stranded: Max 30 Kg (66Lbs) • DTS firmware uploader dongle (code 03.LA.206) Rel.1.0 6 di 26...

  • Page 10: 6- Important Safety Information

    -High voltage is present inside the unit. Unplug the unit prior to performing any function which involves touching the inside of the projector. -The level of technology inherent in the BRICK 12 requires the assistance of specialised personnel for all servicing.

  • Page 11: Level Of Protection Against The Penetration Of Solid And Liquid Objects

    • A correct orientation of the light beam. 7.2 Check-up List for the Installation • Prepare all cables and necessary accessories. • Test the BRICK 12 before installing. Pay attention not to damage cables/connectors during check-up. Rel.1.0 8 di 26...

  • Page 12: Tips For The Installation

    ALWAYS keep the cables protected from pointy objects and ensure that no cable is damaged. • Failing to keep the BRICK 12 into the -10 to 45 °C operating temperature range (14 to 113 °F) and the -25 to 60 °C storage temperature range (-13 to 140 °F), will cancel the warranty issued by D.T.S.

  • Page 13: Cable Folding

    BRICK 12 7.5 Cable folding Cables MUST NOT be folded with a curvature radius inferior to four times their external diameter (4x cable diameter). The cable, when extending from the product, must be kept straight for a minimum length of 5 cm (1.97 in) next to the cable gland.

  • Page 14: Movement

    BRICK 12 7.6 Movement The projector has a maximum movement of 110° for Tilt. 7.7- Risk of fire Each fixture produces heat and must be installed in a well-ventilated place. Minimum distance from the object being illuminated is 0,5 m.

  • Page 15: 8- Input / Output Connections

    BRICK 12 8- INPUT / OUTPUT CONNECTIONS Terminal block or plug not included. Installation may require advice from a qualified person. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.

  • Page 16: 9- Dmx Signal Connection

    BRICK 12 9- DMX SIGNAL CONNECTION: The unit operates using a digital DMX 512 signal. Connection between the controller and the unit or between units must be carried out using a two pair screened ø 0.5 mm. Ensure that the conductors do not touch each other.

  • Page 17: 10- Rdm Functions

    10- RDM FUNCTIONS By using a RDM controller it is possible to set DMX address, DMX mode and other parameters. BRICK 12 accepts the following RDM commands: RDM Device Model ID : 0 X 0D49 DEVICE_INFO To read the following parameters: •...

  • Page 18: 11- Firmware Updating

    Please follow the procedure below to perform the update: 1. Connect the DTS Dongle Firmware Uploader to a spare USB port on the PC. 2. Connect the unit DMX input to the DTS Dongle Firmware Uploader DMX output with a standard DMX cable and turn ON the unit.

  • Page 19: 15- Barndoor Installation

    BRICK 12 15- BARNDOOR INSTALLATION The Barndoor for BRICK 12 is available on demand. Fix the barndoor on the BRICK 12 by using the 4 marked screws previously removed from the unit body. SAFETY CABLE CONNECTION Once installed, fix the safety cable on the side cap by using the marked screw and the washer provided in the box as shown in the picture.

  • Page 20: 16- Dmx Protocol

    BRICK 12 16- DMX PROTOCOL 10 CHANNELS MODE (Default) GREEN BLUE WHITE SHUTTER DIMMER DIMMER FINE MACRO COLOR FUNCTIONS Name DMX levels 0..255 Proportional color from min to max GREEN 0..255 Proportional color from min to max BLUE 0..255 Proportional color from min to max WHITE 0..255...
  • Page 21 BRICK 12 Name DMX levels MACRO COLOR 0..14 No function 15..24 1: LEE FILTER NO. 19 "FIRE" (R255 G16 B0 W0 =) (R255 G64 B0 W0 =) 25..34 2: LEE FILTER NO. 20 "MEDIUM AMBER" (R255 G84 B0 W0 =) (R255 G146 B0 W0 =) 35..44...
  • Page 22 BRICK 12 Name DMX levels 85..104 OUTPUT FREQUENCY 610 Hz (DEFAULT) OUTPUT FREQUENCY 800 Hz OUTPUT FREQUENCY 1000 Hz OUTPUT FREQUENCY 1500 Hz OUTPUT FREQUENCY 2000 Hz OUTPUT FREQUENCY 2500 Hz OUTPUT FREQUENCY 3000 Hz OUTPUT FREQUENCY 3500 Hz OUTPUT FREQUENCY 4000 Hz...
  • Page 23 BRICK 12 “RGBW” MODE (4 CHANNELS) GREEN BLUE WHITE Name DMX levels 0..255 Proportional color from min to max GREEN 0..255 Proportional color from min to max BLUE 0..255 Proportional color from min to max WHITE 0..255 Proportional color from min to max...
  • Page 24 BRICK 12 “FINE” MODE (10 CHANNELS) RED FINE GREEN GREEN FINE BLUE BLUE FINE WHITE WHITE FINE DIMMER DIMMER FINE Name DMX levels 0..255 Proportional color from min to max RED FINE 0..255 Proportional color from min to max GREEN 0..255...
  • Page 25 BRICK 12 NOTES Rel.1.0 22 di 26...
  • Page 26 BRICK 12 NOTES Rel.1.0 23 di 26...
  • Page 28 BRICK 12 Rel.1.0 24 di 26...
