USER MANUAL
1. GENERAL RULES ....................................................................................................................................
2. SAFETY ....................................................................................................................................................
3. INDICATOR .............................................................................................................................................
4. USABILITY ...............................................................................................................................................
5. INSTRUCTION FOR USE ........................................................................................................................
6. PRINTER FUNCTIONS ............................................................................................................................ 13
7. SETTING SETUP ..................................................................................................................................... 14
8. ERROR MESSAGES ................................................................................................................................. 15
9. MAINTENANCE AND ASSISTANCE ....................................................................................................... 16
10. SCRAPPING AND WASTE DISPOSAL .................................................................................................. 16
11. WARRANTY .......................................................................................................................................... 17
12. TECHNICAL SPECIFICATION ............................................................................................................... 17
13. INSTALLATION ..................................................................................................................................... 18
14. CONFORMITY ...................................................................................................................................... 21
15. IDENTIFICATION LABELS .................................................................................................................... 21
16. SAFETY LABELS .................................................................................................................................... 22
RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025
WEIGHING PLATFORM FOR WHEELCHAIR
MOD. RW 2.0 - BASIC (WU150)
EN
www.wunder.it
INDEX
WUNDER SA.BI.SRL
2
3
7
8
8
1
Advertisement
Table of Contents
Related Manuals for WUNDER RW 2.0 BASIC
Summary of Contents for WUNDER RW 2.0 BASIC
-
Page 1: Table Of Contents
10. SCRAPPING AND WASTE DISPOSAL ....................16 11. WARRANTY ............................17 12. TECHNICAL SPECIFICATION ....................... 17 13. INSTALLATION ............................. 18 14. CONFORMITY ............................21 15. IDENTIFICATION LABELS ........................21 16. SAFETY LABELS ............................ 22 RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 2: Read This Manual Carefully Before Using The Instrument
By choosing the WUNDER professional electronic personal scale, you have purchased a high-precision device. For over 40 years, WUNDER has been putting its expertise at the service of health. This instrument complies with national standards in force for hospitals, outpatient clinics and nursing institutions with in-patient care, medical class Im with measuring function and it is calibrated in accordance with accuracy class III. -
Page 3: Intended Use
• Do not remove seals from the instrument. • Do not short-circuit the battery terminals • Use only the power supply provided by Wunder. Before using it, make sure that the local mains voltage is compatible with the voltage of the adapter shown on the identification plate •... - Page 4 Power frequency (50, The product power frequency magnetic fields 60 Hz) Magnetic field 30 A/m should be at levels of a typical location in a typical IEC 61000-4-8 commercial or hospital environment. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
- Page 5 The field strength over a frequency range of 150 kHz to 80 MHz should be less than 3 V/m. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
- Page 6 (m) can be calculated using the equation applicable to the frequency of the transmitter, where P is the maximum rated power output of the transmitter in Watt (W) according to the manufacturer of the transmitter. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
-
Page 7: Function Keys
[UNIT OF Allows using different units of measurement MEASUREMENT] Allows you to calculate the tare weight, i.e. patient's clothes, by manually [PRETARA] setting the value to be subtracted [0] … [9] Numeric keys RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 8: Display Functions
08:00 Use the numeric keys to enter the correct value, press to access the next step once correctly set. 202 1 05.24 08:00 Display Format YYYY → MM.DD → HH:SS RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... - Page 9 5. Insert the battery pack with the technical text 6. Close the battery compartment facing upwards and the connector cable on the left. Insert the battery pack first and then gently place the cable in the bottom notch. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
- Page 10 3. Remove the discharged batteries 4. Insert the new alkaline batteries 5. Insert the batteries container first and then gently 6. Close the battery compartment place the cable in the bottom notch. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
-
Page 11: Instruction For Charging And Connecting
“Mother & Child” function in one step, thanks to the dedicated function. After turning on the scale, step on it and press the button Step off the scale, pick up the baby and step back on; the baby's weight will then be displayed. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 12: Bmi Function
Severe malnutrition <16 Moderate malnutrition 16-16.9 Underweight Mild malnutrition 17-18.4 Normal weight 18.5-24.9 Normal weight Overweight 25-29.9 Overweight degree obesity (mild) 30-34.9 degree obesity (moderate) 35-39.9 Obesity degree obesity (severe or morbigena) ≥40 RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 13: Tare Function
Obesità classe III >40 RS232 Interface parameteres (not editable): Baud rate: 9600 bps Parity check: None Data length: 8 bits Stop bit: 1 bit Connector RS232 Handshake: RTS / CTS Data code: ASCII RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 14: Setting Setup
3 seconds, display shows “SETUP” and after “A.OFF”. = ▼ go to the next function = ► enter and edit parameters Setting procedure: Tare_Key Hold_key Zero_key When the display shows “ End ” press key to confirm settings. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 15: Error Messages
-10% while power ON Error normally caused by a serious fault of the Error EEPROM: indicates an error with Err.P scale (load cell or wiring). software of the scale Please contact the local technical service. RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 16: Maintenance And Assistance
If the instrument remains idle for a long period, remove the batteries from the terminal. During shipping, make sure not to subject the instrument to blows or excessive mechanical stress. In case of repairs or assistance, contact your dealer or an authorised service centre contacting service2@wunder.it or sales@wunder.it 10. -
Page 17: Warranty
Wunder Service Centre, expenses and relative travel risk are borne by the user. Wunder will not be held liable for damage of any nature caused directly or indirectly to persons, animals or objects resulting from failure to comply with all the instructions indicated in this manual or anyway resulting from improper use. -
Page 18: Installation
N°01 Indicator WU150 - N°01 Handrail - N°01 Indicator support (fixed to the handrail) - N°02 Knobs for fixing the handrail - N°02 Knobs (fixed to the indicator support) - N°01 External adapter RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... - Page 19 USER MANUAL WUNDER SA.BI.SRL 13.1 MOUNTING OF THE INSTRUMENT (POSITION OF USE) 1. Open the package 2. Remove from packaging RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
- Page 20 A ( 1 : 2 ) Secure the handrail with the 3 tie-rod clamps (make sure all 3 hooks are securely fastened) A ( 1 : 1 ) 3. Handrail and visor assembly RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
-
Page 21: Conformity
Consult the user manual to replace the battery Internamente alimentata con batteria o alimentata esternamente (rechargeable model type: RETC 7,2V 2000mAh) da modello UES24LCP-120200SPA MATR.0000 IN ACCORDANCE WITH REGULATION (EU) 2017/745 CONFORME AL REGOLAMENTO (UE) 2017/745 0425 RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... -
Page 22: Safety Labels
Before each use, always ensure that the red hooks are correctly fixed (2.1) and do not go under the platform (figure 2.3). 16.1 CORRECT WEIGHING POSITIONS WEIGHING IN WHEELCHAIR WEIGHING WHEN STANDING (FOR PATIENTS WITH STABILITY PROBLEMS) RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025... - Page 23 WUNDER SA.BI.SRL USER MANUAL RW 2.0 BASIC (WU150) - REV.06 - 13/01/2025...
- Page 24 Wunder Sa.Bi. S.r.l. Via Vecchia per Monza, 20 20056 Trezzo sull’Adda (MI) Tel. +39 02 90964566 www.wunder.it...
