WUNDER RA User Manual

Professional electronic mdd scale

Advertisement

WUNDER SA.BI.SRL
EN
USER MANUAL
www.wunder.it
PROFESSIONAL ELECTRONIC MDD SCALE MOD. RA
USER MANUAL
Read this manual carefully before using the instrument
2. GENERAL RULES ......................................................................................................................... 2
3. SAFETY........................................................................................................................................... 3
4. THECHNICAL SPECIFICATION .................................................................................................. 6
5. INDICATOR .................................................................................................................................... 6
6. INSTALLATION ............................................................................................................................. 7
7. INSTRUCTION FOR USE .............................................................................................................. 8
8. PRINTER FUNCTIONS................................................................................................................ 10
9. SETTING SETUP .......................................................................................................................... 12
10 .ERROR MESSAGE ..................................................................................................................... 12
11. MAINTENANCE AND ASSISTANCE ...................................................................................... 13
12. CONFORMITY ........................................................................................................................... 13
13. IDENTIFICATION LABELS ...................................................................................................... 13
14. SCRAPPING AND WASTE DISPOSAL .................................................................................... 13
15. WARRANTY ............................................................................................................................... 14
17. THERMAL PRINTER (OPTIONAL) ......................................................................................... 18
1
RA(WU150) REV. 02- 10/01/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WUNDER RA

  • Page 1: Table Of Contents

    WUNDER SA.BI.SRL USER MANUAL www.wunder.it PROFESSIONAL ELECTRONIC MDD SCALE MOD. RA USER MANUAL Read this manual carefully before using the instrument 2. GENERAL RULES ......................... 2 3. SAFETY............................3 4. THECHNICAL SPECIFICATION ....................6 5. INDICATOR ............................ 6 6. INSTALLATION ..........................7 7.
  • Page 2: General Rules

    By choosing the WUNDER model RA professional electronic scale, you have purchased a high precision instrument. Since over 40 years WUNDER has placed its experience at the service of health. This instrument is compliant with national standards in hospitals and clinics with medical class I with measurement function and Is calibrated in conformity with accuracy class III.
  • Page 3: Safety

    • Do not remove seals from the instrument. • Do not short-circuit the battery terminals. • Use only the power supply provided by Wunder. Before using it, make sure that the local mains voltage is compatible with the voltage of the adapter shown on the identification plate.
  • Page 4 Manufacturer's guide and declaration - Electromagnetic emissions The electronic scales RA model can be used in the electromagnetic environment specified below. The customer or the user of the seat must ensure that it is used in compliance with the specifications below.
  • Page 5 Recommended separation distances between portable radio equipment unity. The scales RA model is expected to operate in an electromagnetic environment in which they control the noise radiated RF. The customer or the tooth may be of help to prevent electromagnetic interference by ensuring a minimum distance between mobile communication devices and portable RF (transmitters) and unity, as recommended below, with respect to the maximum power output of equipment radio.
  • Page 6: Thechnical Specification

    Adapter 12 V - 2 A Rechargeable Batteries Pack- (OPTIONAL) Operation temperature da 5°C a 35°C 5. INDICATOR 1. Key function 2. Weighing capacity and division 3. Second LCD automatically calculates BMI 4. Main LCD: Weight 5.Power display RA(WU150) REV. 02- 10/01/2017...
  • Page 7: Installation

    INSTRUMENT WITH THE SUPPLIED POWER SUPPLY TO CORRECTLY RECHARGE THE BATTERIES Position the instrument on a level and stable surface The instrument must be placed away from heat sources, in an environment without excessive vibrations and drafts. Assembly (for column version only) RA(WU150) REV. 02- 10/01/2017...
  • Page 8: Instruction For Use

    The battery should be recharged at least every 3 months regardless if it is used or not. After a long period in storage, e.g. over 3 months, the battery should run a full cycle (charge/discharge) to allow it to restore to full capacity. Ac Jack connector RA(WU150) REV. 02- 10/01/2017...
  • Page 9 • Press HOLD again to release the weight memorized on the display. The instrument goes back to normal weighing mode. • The HOLD function may be activated before or after the patient has climbed onto the platform. RA(WU150) REV. 02- 10/01/2017...
  • Page 10: Printer Functions

    Weight can be printed for records using RS232 interface cable. After weighing simply press PRINT key to print out the results The format presented below is the standard format of results print-out and cannot be changed. More informations info@wunder.it or service@wunder.it RA(WU150) REV. 02- 10/01/2017...
  • Page 11 • Click Bits per second to set up rate at 9600, Data bits at 8, Parity at None, Stop bits at 1 and Flow control at Hardware. Then click OK to complete your setting. • Output Data • When press the PRINT key to output data from scale to PC or an Optional Printer. RA(WU150) REV. 02- 10/01/2017...
  • Page 12: Setting Setup

    This enables operator to select the auto turn OFF time of the device. BUZZER ON/OFF SETUP This enables operator to select beep sound ON/OFF. Note: To confirm the settings, please press when displays on the display. 10 .ERROR MESSAGE RA(WU150) REV. 02- 10/01/2017...
  • Page 13: Maintenance And Assistance

    In case of repairs or assistance, contact your dealer or an authorised service centre contacting service2@wunder.it or sales@wunder.it. 12. CONFORMITY WUNDER MODEL RA CABLE ELECTRONIC SCALE SERIAL N°............... We hereby certify that this instrument has been inspected and has successfully passed the functional test. It complies with the following standards and directives: EN 45501 / EN60601-1-2 / EN60601-1 93/42/EEC –...
  • Page 14: Warranty

    By warranty we mean the replacement or repair free of charge of parts making up the appliance which, at the discretion of the manufacturer, are deemed faulty from the origin; Wunder therefore has the faculty of repairing or replacing the item.
  • Page 15: Assembly-Use Mechanical Telescopic Height Meter (Optional)

    Wunder Service Centre, expenses and relative travel risk are borne by the user. Wunder will not be held liable for damage of any nature caused directly or indirectly to persons, animals or objects resulting from failure to comply with all the instructions indicated in this manual or anyway resulting from improper use.
  • Page 16 Removing battery cover at the rear of indicator Installing code AAA batteries * Reinstalling the battery cover STAGE 2: CONNECTING CABLE DIGITAL TELESCOPIC HEIGHT METER Plug power indicator Plug power digital telescopic height meter Indicator connector Height meter connector RA(WU150) REV. 02- 10/01/2017...
  • Page 17 2. Ask the person to be measured to stand with his or her back to the rod. 3. Sliding the head stop down until it touches the head. 4. Read the height measured on the display unit. RA(WU150) REV. 02- 10/01/2017...
  • Page 18: Thermal Printer (Optional)

    Roll Holder Tear Bar Printer Button Status Indicator RS 232 connect ON/OFF Power (Adattatore) 17.1. HOW TO USE YOUR PRINTER Connect the AC Adaptor and RS232 interface cable. Press the I/O button to power on the printer. RA(WU150) REV. 02- 10/01/2017...
  • Page 19 Printing method Thermal dot line printing Number of dots 384 dot/line Resolution (dots/mm) 8 dot/mm Printing width (mm) 48 mm Max. paper thickness (μm) 80μm Paper 57.5±0.5 mm (W) x ψ30mm max Paper loading Easy loading RA(WU150) REV. 02- 10/01/2017...
  • Page 20 Reset the paper roll. Please refer to “CHANGING Printer paper jammed. THE PAPER ROLL”. Paper roll is out. Reload a new source of paper roll Status Indicator is flashing green. so the printer can continue printing. Please refer to “CHANGING THE PAPER ROLL”. RA(WU150) REV. 02- 10/01/2017...
