ALS FLEXYIP10 Quick Start Manual

DESCRIPTION OF PARTS
LED FLEX-MODUL, Length 5m, 7,2W/m
1400 LED/roll (280 LED/m)
Backing with 3M self-adhesive. Every 25mm cuttable, cutting line
on dark dots. Accessories: 1x Tube silicone glue, 10x mounting
clips incl. 20x screws, 5x end cap, 5x end cap with hole for
feeder/connector.
TECHNICAL DATA
FLEXY, LED-FLEX-MODUL, L5m with 1400 LED (280 LED/m)
7,2W/m, CRI>90, 24VDC, 2220 SMD LED, with
3M self-adhesive backing, incl. accessories, IP67
Dimensions (sketch overleaf):
Without end cap: W12xH3,5 mm
With end cap: W13xH5,5 mm
Color temperature:
FLEXYIP10-1400WWN: 3000K
FLEXYIP10-1400SWN: 2700K
LAMP
SMD--LED
The LED light agent cannot be replaced.
Protection class III Notification of Risks
CE label Safety Instructions
The light can be Cleaning Instructions
IP67
used in interiors and
exteriors.
The product may not Don't look directly into
be disposed of in the the LED! The LED is that
household garbage. bright that it might
damage your eyes!
Installation only by Not recommended
qualified and autho- for children under 3
rised persons. years
ESD protection com- Produkt nicht dem
ponent Sonnenlicht aus-
setzen
DISPOSAL
The packaging consists of environmentally friendly materials.
Dispose of them in the local recycling containers.
Do not dispose of this product in the household gar-
bage when it has reached the end of its lifecycle, but
rather take it to a disposal center. Your local officials
will provide you with information about collection
offices and their business hours.
SAFETY
READ THE INSTRUCTIONS BEFORE USING THIS PRODUCT.
KEEP THE SAFETY AND OPERATING INSTRUCTIONS FOR
FUTURE USE.
SAFETY INFORMATION
• The flexy stripe is suitable for indoor and outdoor use.
IP67
• Before mounting, the intended splice must be thoroughly
cleaned (free from dust, oil and grease layers).
• Assembly only on suitable carrier material, for example
Aluminum regarding heat conduction as well as reliable
A adhesion of the adhesion foil.
F
G
• Don't install under power.
• Follow the instruction manual for installation.
• Installation only by qualified and authorised persons.
• Do not use the product when it has been damaged (defective
covers) or there are operational faults such as flickering,
smoking, steaming, crackling noises or the smell of smoke.
• A damaged or defective product must be changed
or repaired by the manufacturer, a service person or a
comparable qualified person.
• Installation only under observance of the valid guidelines
specific to application and country among others VDE 0.100.
• Never open one of the electrical operating agents or plug any
objects into them. Such procedures signify a danger to life
through electrical shock.
• Avoid contact of the product with liquids such as strong
detergents and oily substances.
• The product may not be changed or modified.
• Keep the product and its components out of the reach of
children. There is a risk of small parts being swallowed. Risk of
injury for children! If children or persons who can not assess
the dangers use the LED control, there is a risk of injury!
• The warranty claim and guarantee is rendered invalid in the
event of damage to the product, which is caused by not
following the operating instructions. We are not liable for the
consequent damage. Because of specific characteristics of
LED's (life, deviation in colour etc.) we formulated special
terms for planing and installing our LED products. They
are part of these installation manual! Should they not be
available, request them please!
• Don't look directly into the LED! The LED is that bright that it
might damage your eyes!
• Storage temperature -40-+80°C
• Processing temperature: +10°C (glue), do not install below
0°C or bend the LED band.
• Operating temperature in operation: -25-+60°C
MAINTENANCE AND CLEANING
The LED light agent cannot be replaced.
• Do not use solvents, such as benzene and similar
agents. The flexy stripe would be damaged thereby.
• Only use a dry, lint-free cloth for cleaning the
product.
FLEXYIP10
Flexible LED-stripe
FLEXYIP10-1400WWN
FLEXYIP10-1400SWN
A
F
G
INTENDED USAGE
This product will only serve the purpose of illumination.
The LED-stripe can be used indoor and outdoor.
SCOPE OF DELIVERY
1 x ESD packaging, content, flexy stripe 5m
1 x set of instructions for assembly, operation and safety
TECHNICAL CHANGES
Changes in the sense of technical progress can be made
without prior notice.
address | contact
A.L.S. GmbH
Mastorter Str. 31 | 88069 Tettnang (Germany)
Tel.: +49 (0) 75 42 93 44-0 | Fax.: +49 (0) 75 42 93 44-30
E-Mail: info@als.de | Web: www.als.de
EN
Version: 2022-11-10
