- Page 1 D5232Q INSTRUCTION MANUAL SIL2 Switch/Proximity Relay-Out Repeater DIN-Rail, Model D5232Q D5232- SIL2 Switch/Proximity Relay-Out Repeater G.M. International ISM0659-0...
-
Page 2: Technical Data
Characteristics General Description: The Switch/Proximity Detector Repeater D5232 is a module suitable for applications requiring SIL 2 level in safety related systems for high risk industries. The unit can be configured for switches or proximity detectors, located in Hazardous Area, and repeats the input state to a relay contact in Safe Area. The selectable fault detection circuit is available for proximity sensors or switches equipped with end-of-line resistors. -
Page 3: Ordering Information
Ordering Information Power Bus and DIN-Rail accessories: Model: D5232 Connector JDFT050 Bus Mounting Kit OPT5096 4 channels Front Panel and Features SIL 2 / SC 3 (pending) Input from Zone 0/Div. 1 Installation in Zone 2/Div. 2 CONFIG High output current Field open and short circuit detection STS/FLT Input inversion available... - Page 4 Parameters Table In the system safety analysis, always check the Hazardous Area/Hazardous Locations devices to conform with the related system documentation, if the device is Intrinsically Safe check its suitability for the Hazardous Area/Hazardous Locations and group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not exceeded by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the D5232 series Associated Apparatus connected to it.
-
Page 5: Function Diagram
Out 1 In 1 Out 2 In 2 Out 3 Out 4 In 3 In 4 Supply BUS Connector D5232Q used as double channel with Duplicator or Fault Output Configurator Voltage Free Voltage Free Contact Contact Proximity In 1 Out 1... - Page 6 Any unauthorized modification must be avoided. Operation The Switch/Proximity Detector Repeater type D5232Q is a unit with four independent channels suitable for applications requiring SIL 2 level (according to IEC 61508:2010) in safety related systems for high risk industries.
