Ethernet Cable
Caution: DO NOT plug a phone jack connector into any RJ-45 port.
Specifications
Cable
10BASE-T
100BASE-TX Cat. 5 100-ohm UTP
Wiring Conventions
For Ethernet connections, a twisted-pair cable must have two pairs of
wires. Each wire pair is identified by two different colors. For example,
one wire might be red and the other, red with white stripes. Also, an RJ-45
connector must be attached to both ends of the cable.
Use only twisted-pair cables with RJ-45 connectors that
conform with FCC standards.
Cable Types and Specifications
Type
Cat. 3, 4, 5 100-ohm UTP
A
PPENDIX
C
Max. Length
100 m (328 ft)
100 m (328 ft)
B
ABLES
Connector
RJ-45
RJ-45
B-1
