SMC Networks SMC7904WBRAS-N2 v2 Specifications

POWER TO CONNECT
www.edge-core.com
www.smc.com
SMC7904WBRAS-N2 v2
4-Port ADSL2+ 11n 1x1 Wireless Router
Product Overview
The SMC7904WBRAS-N2 v2 is a three-in-one wireless ADSL2/2+ router designed
for Internet connectivity. It includes an ADSL modem, four Ethernet ports, and an
802.11n high-speed wireless function. The SMC7904WBRAS-N2 v2 supports the
most up-to-date ADSL2/2+ standards to provide the best DSL performance, with up
to 24 Mbps* downstream and 2Mbps* upstream and a long-reach rate from your
ISP's DSLAM site. Through its QoS and security features, the SMC7904WBRAS-N2
v2 can deliver high-quality video/audio streams without sacrificing security. The
SMC7904WBRAS-N2 v2 is an ideal, cost-effective solution for ISPs and carriers
with all its value services in one small box.
*ADSL speeds vary depending on individual contracts and services offered by ISPs, and distances from the ISP DSLAM.
Key Features and Benefits
Bridge/Router Mode
The SMC7904WBRAS-N2 v2 supports both Bridge and Router modes. This means that the SMC7904WBRAS-N2 v2 can
be operated in a bridging, routing, or hybrid mode (bridging and routing simultaneously). This allows the
SMC7904WBRA-N2 to be operated within different ISP deployment plans.
802.11n 2.4GHz Wireless with 1x1 Antenna and Multi-SSIDs
The SMC7904WBRAS-N2 v2 Wi-Fi solution is compliant with 802.11n draft v2.0 specifications. As a Wi-Fi AP/Router, the
SMC7904WBRAS-N2 v2 can achieve a 72.2 Mbps PHY rate using an 11n 1x1 antenna system. Multiple SSIDs are also
supported, which enables the SMC7904WBRAS-N2 v2 to provide separate Wi-Fi networks for private and public use
without sacrificing security.
Better User Experience
With IGMP Proxy and Snooping, users can enjoy HDTV with a smooth streaming experience. By leveraging this function,
operators can increase the ARPU by providing a high-quality IPTV service to customers. In addition, the
SMC7904WBRAS-N2 v2 supports a Parental Control feature to prevent children from accessing harmful websites.
Auto-Configuration
Server
Set-top Box
ATM
SMC7904WBRAS-N2 v2
POTS
Splitter
DSLAM
