Servicing Instructions Work Chair
Servicing, inspection, and repairs may only be carried out by personnel who possess the relevant
technical knowledge of the product in order to maintain the validity of the CE mark. No-one may sit
in the product whilst it is being serviced.
Customised products can be restored if the relevant parts are replaced with original parts from
Eurovema and the restoration is carried out by an authorised technician. A new label showing the
CE mark can be ordered.
During servicing, it is important that a visual inspection of the product's metal components is carried
out in order to rule out the presence of damage or cracks that may impact the safety of the product.
Check brakes, seat functions, tilt and lift, attachment, and function.
Any defects identified must be addressed. If parts need to be replaced, only Eurovema original
parts must be used - except in the case of screws and nuts, where replacements of the right model,
length, and grade are to be sourced.
Instructions about how to fit/remove and adjust components can be found on our website in the
section Assembly Instructions.
Instructions in respect of batteries and electronics can also be found on the website in the section
Batteries and Electronics.
Suitable tools
Allen key kit
Torx wrench kit
Box wrenches 8,10, 13, 17, 19mm
Flat head screwdrivers
Phillips screwdrivers
Snips
Revision: 15.01.2024
Troubleshooting, re-use, and destruction
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Eurovema Sigma
Summary of Contents for Eurovema Sigma
- Page 1 Customised products can be restored if the relevant parts are replaced with original parts from Eurovema and the restoration is carried out by an authorised technician. A new label showing the CE mark can be ordered.
-
Page 2: Troubleshooting
Troubleshooting Manual chairs Symptom Cause See assembly instructions or separate instruction Brakes do not engage well or allow Wheel brake incorrectly adjusted Centrally braked the chair to move when the central wheels brake is applied Brakes do not engage well or allow Brake cables incorrectly adjusted Seat-mounted brake. - Page 3 Troubleshooting Electric chairs Symptom Cause See assembly instructions or separate instruction Brakes do not engage well or allow Brake incorrectly adjusted at wheel Centrally braked wheels the chair to move when the central brake is applied Brakes do not engage well or allow Brake cables incorrectly adjusted Seat-mounted brake the chair to move when cable brake is...
- Page 4 Reconditioning In this instruction, “reconditioning” does not constitute a full refurbishment as outlined in Regulation (EU) 2017/745 MDR with the aim of reintroducing the product on the market with a reset expected service life. Products that are prescribed by a licensed medical practitioner are not subject to periodic maintenance requirements.
- Page 5 Service points and intervals In order to ensure the usability of the product for the duration of its expected service life, the following servicing schedule should be followed. 1= visual inspection 2= function test 3= replacement 4= lubrication 5= cleaning 6= adjustment if necessary 7= check screw joint tightening Service point year 2...
- Page 6 See Assembly Instructions, Sigma chassis wheel. 1.3 The wheel forks must swing without resistance. Replace defective wheels/forks with perfect original wheels, see Assembly Instructions, Sigma wheel chassis. Check that all wheels are in contact with the floor on a flat surface.
- Page 7 5.3 Check that the seat cross tilt axle is tightened. If there is abnormal play between the upper and lower section, the axle must be removed for inspection. If the axle is intact, the seat cross is worn or damaged and must be replaced with a perfect original part, See Assembly Instructions, Sigma seat cross 5.4 Check the armrest, back support, and leg support attachments.
- Page 8 Specially adapted products may be restored provided that such restoration has been carried out by an authorised assistive device technician and that modified parts have been replaced with original parts. If a new label is required, notify Eurovema and quote the chair serial number. Cleaning Do not clean using a high pressure washer or washing cabinet, water, or any other liquid! Clean the chassis using a mild detergent/non-abrasive disinfectant.
- Page 9 3. Lifting actuator, Electric 3.1 Check that the actuator sits securely in the chassis and does not rotate. Check ground clearance under the lifting device. See Assembly Instructions, lifting device for the relevant chassis. 3.2 Listen for any abnormal noises from the electric actuator. Raise the seat to its highest position, wipe the lifting pillar clean with a cloth and then lubricate pillar with thin oil.
- Page 10 7. Battery 7.1 Check attachment and that the cable and connector are intact. 7.2 Charge the battery to full and test electrical functions under load. If the capacity of the battery falls significantly after a short period of use, the battery must be replaced with a new original part. See Assembly Instructions, battery for the relevant chair model.
- Page 11 Reconditioning checklist Work Chair Sigma Eurovema Mobility products are intended to be reused during their expected service life. Reconditioning does not mean that the expected service life of the chair is extended. Cleaning The product may be flushed with water, but not using a high pressure washer, provided that stuffed parts have been removed.
- Page 12 5. Seat cross 5.1 Check play 5.2 Visual inspection 5.3 Tilt axle 5.4 Attachment of armrests, back support, leg support 6. Electronics 6.1 Charging 6.2 Test of all electrical functions 6.3 Cables correctly routed, protected 7. Battery 7.1 Cabling 7.2 Test of electrical functions. Product serial number Reconditioned by...
- Page 13 Reconditioning checklist, work chair Flexbase, Junior, Basic & EXL Eurovema Mobility products are intended to be reused during their expected service life. Reconditioning does not mean that the expected service life of the chair is extended. Cleaning The product may not be cleaned using a high pressure washer or washing cabinet.
- Page 14 5. Seat cross 5.1 Check play 5.2 Visual inspection 5.3 Tilt axle 5.4 Attachment of armrests, back support, leg support 6. Electronics 6.1 Charging 6.2 Test of all electrical functions 6.3 Cables correctly routed, protected 7. Battery 7.1 Cabling 7.2 Test of electrical functions. Product serial number Reconditioned by...
- Page 15 Products that are to be permanently put out of use must be disassembled and sorted at source. disassembly instructions can be found on the eurovema.se website in the Assembly Instructions section, along with exploded diagrams in the Exploded Diagrams section.
- Page 16 Notes...
- Page 17 Eurovema Mobility AB Baldersvägen 38, SE-332 35 Gislaved, Sweden Tel. +46 371 390 100 | info@eurovema.se | www.eurovema.se...
