- Page 1 User Manual Important, read before use! SMART/SMART XL DISCOVERY/DISCOVERY XL PATROL/PATROL XL...
-
Page 2: Warranty
Contact If you have any questions about the product and how to use it, contact your dealer or Technical Aid Centre. Eurovema Mobility AB Baldersvägen 38 SE-332 35 Gislaved Tel.: +46 (0)371 39 01 00... -
Page 3: Table Of Contents
List of contents Intended use Use tips - “comfort chassis” Warranty Learn the “scissors technique” Standards Maintenance: Contact Cleaning Safety rules Reconditioning Contents Cable lubrication Marking Troubleshooting Seat height adjustment Profile clips Handle height adjustment Accessories 12-15 Folding and unfolding the rollator Technical data Fixed transportation strap Braking... -
Page 4: Seat Height Adjustment
Adjusting your rollator Seat height adjustment Adjust one side at a time. Pull out the knob under the seat. At the same time, raise or lower the seat to the po- sition required. Release the knob, ensuring that it locates properly to secure the seat in place. -
Page 5: Learn The "Scissors Technique
Tips for use Comfort Frame Volaris rollators are built with a Comfort Frame™, which enables it to pass smoothly over uneven surfaces. When you need to pass over larger obstacles or mount a pave- ment edge, you can get help from the tilt peddles located by the rear wheels. - Page 6 Unfolding and folding your Volaris Unfolding your Volaris 1. Hold one of the push handles and tilt the rollator slightly to that side so the wheels on the opposite side just lift off the ground. 2. Unfold the rollator using the grey lifting handle on the opposite side.
- Page 7 Braking Service brake The foot brake is applied by pulling up the brake lever located under the handle. Parking brake The parking brake is applied by pushing the brake lever forward until it is horizontal and points straight forwards. The parking brake must not be applied when the brake or the handle height are being adjusted.
- Page 8 Adjust the brake for the correct functionality Braking effect can be set using the cable adjuster located under the frame. 1. Release the parking brake. 2. Undo/loosen the nut using an 8mm spanner, and turn the threaded shaft. 3. Screw in the threaded shaft to increase the braking effect.
-
Page 9: Maintenance
Maintenance Cleaning of rollators Look after your rollator, and your rollator will look after you. Remove dirt using a wet cloth and a mild detergent. En- sure that dirt does not collect between the wheels and the brake shoes. You can rinse the product using a high-pres- sure cleaner or garden hose. -
Page 10: Profile Clips
Accessories Restriction brake A brake with adjustable, continuous friction. Profile clips Profile clips are used to prevent anything getting caught in the openings. These are included with the product and should sit in all visible notches. Both above and below the seat. -
Page 11: Accessories
Accessories Single-handed brake Locks both of the rear wheels and is applied by either the service brake or the parking brake. Oxygen bottle holder Strong steel basket that hooks onto the seat and accom- panying bracket. Easy to remove. Drip stand IV pole with 2 hooks for IV bags and has 2 brackets that are screwed securely to the side of the rollator. - Page 12 Accessories Walking stick holder Two pieces that are firmly screwed in place. Holds a walking stick, crutch, or umbrella in place. Bottle holder Holder in plastic covered wire for a bottle/can. Holds a 0.5 litre bottle or 33 cl can. Hangs on the handle. Maximum load: 0.6 kg.
- Page 13 Accessories Transport strap The transport strap is attached around the rollator handle to keep the rollator in folded position. Easily to fit. Cloth bag Soft, woven nylon bag, which can be left in place when the rollator is folded. Easy to remove. Washable. Maximum load: 5 kg.
- Page 14 Accessories Tray Tray which fits over the rollator seat. Fabric basket Basket made from nylon mesh suspended from two plas- tic ends. The basket can be fitted to all Volaris models. It can be left in place when the rollator is folded. Easy to fit and remove.
- Page 15 Accessories Lights These are fastened to the upright using Velcro. Red to the rear, white to the front. Battery-powered unit that is easy to turn on and change battery.
-
Page 16: Technical Data
Walking stick holder Bottle holder Umbrella/ parasol Transport strap holder Fabric bag Mesh basket Tray Fabric basket Soft seat One hand operated brake IV pole Baldersvägen 38| SE-332 35 Gislaved| Sweden Tel. +46 (0)371 390 100 | www.eurovema.se | info@eurovema.se...
