- Page 1 GRUNDFOS INSTRUCTIONS PROFIBUS and PROFINET for Digital Dosing CIM 150 PROFIBUS DP CIM 500 Ethernet for PROFINET IO Functional profile and user manual...
- Page 3 PROFIBUS and PROFINET for Digital Dosing English (GB) Functional profile and user manual ............4 Appendix A .
-
Page 4: Table Of Contents
CIM 150 PROFIBUS DP ..... . 7 CIM 500 PROFINET IO ..... . . 7... -
Page 5: Introduction
IANA Internet Assigned Numbers Authority Internet Protocol Light-emitting Diode Settings done via the pump HMI or via the Grundfos Local settings GO app Media Access Control: unique network address for a piece of hardware... -
Page 6: System Description
3. System description DDA XL pump The system diagrams provide an overview of the two different technologies and how to connect a CIM to a CIU 900 that you connect to a PROFIBUS DP or PROFINET IO network. The CIM 150/500 is a communication module installed internally in a CIU 900 using a 10-pin connection. -
Page 7: Specifications
Off, permanently green, flashing red, permanently red 4.2 CIM 150 PROFIBUS DP The table below provides an overview of the specifications for the Grundfos CIM 150. For further details, refer to the specific sections of this functional profile. PROFIBUS DP specifications... -
Page 8: Profibus Dp, Cim 150 Setup
Related information 6.2 Setting the industrial Ethernet protocol 5. PROFIBUS DP, CIM 150 setup Pos. Designation Description +5 VDC (only for external termination) 5.1 PROFIBUS bus topology On and off switches for termination SW1/SW2 The PROFIBUS-preferred bus topology is daisy chaining as resistors illustrated in the figure below. -
Page 9: Setting The Profibus Address
5.6 Status LEDs Pos. Description The CIM 150 PROFIBUS module has two LEDs: PROFIBUS terminal B • red and green status LED1 for PROFIBUS communication PROFIBUS terminal A • red and green status LED2 for GENIbus communication Earth clamp between the CIM 150 and the connected DDA pump. +5 VDC LED1 DGND... -
Page 10: Reaction To Plc Stop Button
15) in the event log. If for DDA model C the GO app connection 6. PROFINET IO, CIM 500 setup is active, the backlight remains blue and the event log can be WARNING accessed via the GO app. Electric shock When PROFINET communication is reestablished, the pump Death or serious personal injury resumes dosing and returns to the normal display backlight. -
Page 11: Setting The Industrial Ethernet Protocol
The CIM 500 Ethernet module has two Status LEDs: • red and green status LED, LED1, for Ethernet communication • red and green status LED, LED2, for internal communication between the CIM 500 and the Grundfos product. LED1 Status Description The CIM 500 is switched off. -
Page 12: Data Activity And Link Leds
7. Detailed description of data modules Status Description 7.1 Data types The CIM 500 is switched off. The Grundfos CIU 150 and CIU 500 support the following data There is no internal communication between the types. Flashing red CIM 500 and the Grundfos product. -
Page 13: Control Module (Controlmodule, Module 1)
7.2 Control module (ControlModule, module 1) 7.2.1 Explanation of control bits in ControlModule This is a PROFIBUS/PROFINET output module used for the control RemoteAccessReq of the DDA pump. Its data type is 10, non-standard. It is a control bit used by the CIM 150/500 to activate control from the bus. - Page 14 FlowControlEnable 7.2.2 Explanation of control mode When the FlowControl function is enabled, various faults and It is a control enumeration for remote start/stop of the pump. deviations related to the dosing process are detected and indicated. Value Name FlowControl function disabled ReqStart FlowControl function enabled If the pump is ready to be controlled from the PROFIBUS/...
-
Page 15: Dosing Settings
7.3 Dosing settings Module Name Data type Unit Description It is for setting the setpoint used in the operating mode Manual. SetSetpointManual It can also be set via the pump HMI or the GO app. The present value can always be read from the ActSetpointManual (module 12). It is for setting the pulse volume used in the operating mode Pulse. -
Page 16: Overview Of Dda Settings And Controls
7.5 Overview of DDA settings and controls Selectable from Selectable from Preserved after DDA Model C DDA XL HMI/GO app power cycling General dosing settings ✔ ✔ ✔ ✔ ✔ Main network watchdog (enable, disable) ✔ ✔ ✔ ✔ Bus control (enable, disable) ✔... -
Page 17: Status Module (Statusmodule, Module 11)
Selectable from Selectable from Preserved after DDA Model C DDA XL HMI/GO app power cycling ✔ ✔ ✔ Bluetooth (enable, disable) ✔ ✔ ✔ ✔ CIM 150 PROFIBUS address ✔ ✔ ✔ ✔ RS485, AYB (GENIbus protocol settings) ✔ ✔ ✔... - Page 18 7.6.1 Explanation of status bits 0: PROFIBUS/PROFINET watchdog disabled 1: PROFIBUS/PROFINET watchdog enabled ActRemoteAccess It is a status bit indicating whether the pump is in a state where it is See section PROFIBUS communication watchdog, CIM 150 controllable from the bus. or PROFINET communication watchdog, CIM 500 for a description of how to use the watchdog features.
- Page 19 7.6.2 Explanation of command acknowledge bits 7.6.3 Explanation of the ActualOperatingMode If the ActRemoteAccess bit is not set, PROFIBUS/PROFINET It is the status enumeration for reading the actual operating mode. commands (and writings in general) will be prohibited and none of For an explanation of these modes and the belonging enumeration, the acknowledge bits will ever be set.
-
Page 20: Measurement Data Modules
7.7 Measurement data modules Module Name Data type Unit Description It is the actual setpoint used in the operating mode Manual. ActualSetpointManual It can be set via the SetpointManual (module 2) or via the pump HMI or the GO app. It is the actual pulse volume used in the operating mode Pulse. - Page 21 Module Name Data type Unit Description It is the status of the two output relays: Logical "0": The output is not active. Logical "1": The output is active. The relay output type (NO or NC) is selected via the pump HMI or the GO app. The output relay modules are defined as follows: OutputRelays Bits...
-
Page 22: Alarms And Warning
7.8 Alarms and warning Module Name Data type Description It is the code for active pump alarm. FaultCode See the event code in the table below. It is the code for the first active pump warning. WarningCode See the event code in the table below. It shows all active warnings. -
Page 23: Device Identification (Deviceidentification, Module 40)
3: Smart Digital Dosing, DDA XL 4: Smart Digital Dosing, DDA-C UnitType [enumeration] According to description above. UnitVersion [enumeration] Used by Grundfos. CIMSoftwareVersion [number] CIMSoftwareRevision [number] CIMModel [enumeration] 8. Product simulation The CIM can be put in product simulation mode in which case it generates life-like simulated values of all the PROFIBUS/ PROFINET input data modules. -
Page 24: Fault Finding
9.1.1.1 Both LEDs (LED1 and LED2) remain off when the power supply is connected Cause Remedy The CIM is fitted incorrectly in the Grundfos product. • Check if the CIM is fitted correctly in the Grundfos product. The CIM is defective. • Replace the CIM. 9.1.1.2 LED2 for internal communication is flashing red... - Page 25 Cause Remedy The protocol switch (SW1) is in an illegal position. • Make sure the rotary switch SW1 is set to 0. 9.2.1.6 PROFINET IO LED1 is flashing red Cause Remedy There is a fault in the CIM 500 PROFINET IO configuration. •...
-
Page 26: Profibus Address
10. PROFIBUS address This is the decimal to hexadecimal conversion table for setting the PROFIBUS address switches. PROFIBUS address PROFIBUS address PROFIBUS address Related information 5.4 Setting the PROFIBUS address... - Page 27 Appendix A A.1. How to configure an IP address on your PC using Windows 11 Make sure that you have the necessary administrator rights. 1. Go to Ethernet settings (for example, use the Windows "Search" function). 2. Select the drop-down menu for the Ethernet port in question. 3.
-
Page 28: Web Server Configuration
2. Log in to the webserver. A.3. Login Login User name Enter the user name. Default: admin. Password Enter the password. Default: Grundfos. The user name and password can be changed on the web server under Grundfos Management. Related information A.5. User Management... -
Page 29: Profinet Io Configuration
PROFINET IO master to a module fitted in a CIU 900 without installing this device in a real industrial process system. In an office environment, it can then be verified that communication works and data is received and handled correctly by the Grundfos product PROFINET IO master application program, for example, PLC program, before installing the device. -
Page 30: User Management
A.5. User Management A login is required for any change in the CIM 500 settings, and this web page is used for configuring the username and password. It is possible to configure one user only. User management Related information A.3. Login... - Page 31 A.6. Update You can update the firmware by the built-in webserver. The binary file is supplied by Grundfos. To make installation and configuration easier, you can upload the configuration to a PC for backup or distribution to multiple modules. If you experience problems with logging in to the webserver after a firmware update, perform a factory reset.
- Page 32 Unit 1, Ground floor, Siu Wai industrial Turkey www.ba.grundfos.com Centre GRUNDFOS Pumps NZ Ltd. GRUNDFOS POMPA San. ve Tic. Ltd. Sti. E-mail: grundfos@bih.net.ba 29-33 Wing Hong Street & 68 King Lam 17 Beatrice Tinsley Crescent Gebze Organize Sanayi Bölgesi Street, Cheung Sha Wan...
- Page 33 98125976 01.2025 ECM: 1414766 www.grundfos.com...
