  • Page 1                       9 Unit Courses 511-200 Installation Booklet...
  • Page 3                                         ...
  • Page 4                                         ...
  • Page 5 • Pencils and markers Tool and Material Checklist • String line • Bar clamp 4’ • To dig holes, the best method is a tractor with an auger. • Sometimes bracing material is helpful (2” x 4” x 6’ Use a 12” auger bit. No matter what you use, there will studs with sturdy lag bolt/nut combinations) be a considerable amount of hand digging as well •...

  • Page 6: Maintenance

    BEFORE STARTING INSTALLATION OF YOUR PLAYGROUND, PLEASE READ INSTRUCTIONS All SportsPlay Equipment play events have been engineered to THOROUGHLY. meet all applicable safety guidelines, but if installed improperly, these problems may occur: SITE REQUIREMENTS: •...
  • Page 7 Consult the instruction booklet for post and deck installation the parts around the perimeter of the area. If you find damaged instructions. or parts missing, contact your SportsPlay Distributor immediately. BRACING – As the decks and kick plates are installed, be sure to level the posts and place braces in the holes to keep INSTRUCTIONS –...
  • Page 8 MAINTENANCE - Consult your instruction booklet for the maintenance checklist. Schedule and complete periodic maintenance checks of the entire playground. If any hardware is worn, or any item missing or broken, close the playground and contact your SportsPlay distributor for replacement parts. Page 8...
  • Page 9 Safety Surfacing/Fall Heights 1. 12” below existing grade 2. 6” below and 6” above existing grade You must consider the type of safety surfacing you will use 3. 12” above existing grade before beginning the installation process. There are two general types, organic/loose fill or synthetic unitary.
  • Page 10 Safety Surfacing Chart Chart taken from The Handbook for Public Playground Safety written by the U.S. Consumer Product Safety Commission Table – Critical heights (in feet) of Tested Materials (CPSC) page 5 (www.cpsc.gov). Material Uncompressed Compressed Depths Depths 6” 9” 12”...
  • Page 11 on the other three posts at the same distance. Now use Punch List a four-foot level across to each line, raising or lowering as necessary to make the lines level. Repeat this for the Step 1: Layout remaining two posts. 1.
  • Page 12 Step 4 – Component Installation 1. Begin installing the components by working from the lowest deck around to the highest deck. Install the components in either a clockwise or counter clockwise rotation. Step 5: Concrete 1. Once all components and posts are tight and level, you may concrete.
  • Page 13                                         ...
  • Page 14                                ...
  • Page 15 ½” x ½” Socket Set Screw 585-901 S-Hook 416-400 ¼” Socket Key 805-535 Warning Label 805-534 SportsPlay Label Maintenance Checklist 1 CTN 1 BDL 2 TOTAL PCS WEIGHT 110# CLASS 70 SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis MO 63120 (314) 389-9034 www.sportsplayinc.com...
  • Page 16 Check local building codes. If resilient surfacing is to be less than 12”, then additional pipe should be put in concrete to maintain proper finish grade for equipment. SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis MO 63120 (314) 389-9034 www.sportsplayinc.com...
  • Page 17 3. Attach posts (513-603) to each of the Elbows (503-501) per Detail B found on page 1. Only hand-tighten nuts and bolts on initial assembly. Final tightening should be done EVENLY after final assembly when SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis MO 63120 (314) 389-9034 www.sportsplayinc.com...
  • Page 18 The labels must be replaced if they become illegible, destroyed or removed. Contact your distributor for replacement labels. SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis MO 63120 (314) 389-9034 www.sportsplayinc.com...

  • Page 19: Packing List

    PACKING LIST HARDWARE BAG 1 PIPE 513-617 - 805-532 Warning Label - 805-534 Sportsplay Label - Maintenance Checklist 1 PIPE 1 TOTAL PC WT 80# CLASS 70 SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 20 * If resilient surfacing is to be less than 12”, then additional pipe should be put in concrete to maintain proper finish grade for equipment. USE AREA & FOOTING LAYOUT SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...

  • Page 21: General Maintenance Instructions

    Labels must be replaced if they become illegible, destroyed or removed. Contact your distributor for replacement Labels. SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 22 1 416-400 "” Socket Key 2 PIPE 2 583-602A 1 7/8” x 13’ Pipe 1 805-532 Warning Label 1 805-534 SportsPlay Label 1 Maintenance Checklist 1 CTN 4 PIPE 5 TOTAL PCS WT 105# CLASS 70 !"#$%&'()*+,-./"012%3+425 ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 23 511-105 Pole Climb 2 of 2 Page Rev 04/04/03 GENERAL USE/FALL ZONE & FOOTING RECOMMENDATIONS STATIONARY & PORTABLE EQUIPMENT – USE/FALL ZONES SHOULD EXTEND A MINIMUM OF 6 FEET IN ALL DIRECTIONS FROM THE PERIMETER OF THE EQUIPMENT GROUND SPACE. THIS AREA SHOULD BE COVERED WITH THE REQUIRED AMOUNT OF RESILIENT SAFETY SURFACING MATERIAL.
  • Page 24 511-105 Pole Climb 3 of 3 Page Rev 04/04/03 GENERAL ASSEMBLY INSTRUCTIONS: Check all the parts and hardware with the packing list to be sure you have received everything needed to assemble this product. CONTACT YOUR LOCAL DISTRIBUTOR WITH NOTIFICATION OF ANY MISSING OR DAMAGED PARTS. Contact must be made within ten days of receipt of your order.
  • Page 25                                         ...
  • Page 26                                         ...
  • Page 27 SportsPlay Label 2 PIPE 2 503-622 Leg 2 3/8”” OD x 9’’ Long Maintenance Checklist 1 CTN 2 WF 3 PIPE 6 TOTAL PCS WT 220# CLASS 70 SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 28 CHECK LOCAL BUILDING CODES. * If resilient surfacing is to be less than 12””, then additional pipe should be put in concrete to maintain proper finish grade for equipment. SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 29 The labels must be replaced if they become illegible, destroyed, or removed. Contact your distributor for replacement labels. SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 30 Turning Bar - Maintenance Checklist 1 503-203 Turning Bar 1 BDL 6 503-203 Turning Bar 1 CTN 2 BDL 3 PIPE 6 TOTAL PCS WT 100# CLASS 70 SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 31 * If resilient surfacing is to be less than 12”, then additional pipe should be put in concrete to maintain proper finish grade for equipment. FOOTING LAYOUT AND USE AREA SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 32 Contact your distributor for replacement labels. SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 33 Warning Label 1 WF 503-317 Ladder 805-534 SportsPlay Label 1 WF 503-318 Ladder Maintenance Checklist 1 CTN 1 BDL 2 WF 4 TOTAL PCS WT 110# CLASS 70 SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 34 IF RESILIENT SURFACING IS TO BE LESS THAN 12”, THEN ADDITIONAL PIPE SHOULD BE PUT IN CONCRETE TO MAINTAIN PROPER FINISH GRADE FOR EQUIPMENT. Footing Layout and Use Area: SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 35 Plumb & level. Tighten all nuts & bolts so that lock washers are flat. Pour Concrete. Wait 48 hours before removing braces, installing Resilient Surfacing & using equipment. SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 36 Labels must be replaced if they become illegible, destroyed or removed. Contact your distributor for replacement Labels. SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
  • Page 37 226-501 5/16”” Lock Washer 216-501 5/16”” Hex Nut 805-532 Warning Label 805-534 SportsPlay Label Maintenance Checklist 1 CTN 1 BDL 2 TOTAL PCS WT 40# CLASS 70 SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 38 CHECK LOCAL BUILDING CODES. * If resilient surfacing is to be less than 12””, then additional pipe should be put in concrete to maintain proper finish grade for equipment. SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 39 The labels must be replaced if they become illegible, destroyed or removed. Contact your distributor for replacement labels. SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 40                                        ...
  • Page 41 12’’ PACKING LIST HARDWARE BAG 2 PIPE 503-611 Turning Bar 805-532 Warning Label 805-534 SportsPlay Label Maintenance Checklist 2 PIPE 2 TOTAL PCS WT 76# CLASS 70 SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 42 * If resilient surfacing is to be less than 12””, then additional pipe should be put in concrete to maintain proper finish grade for equipment. Use Area and Footing: 12’’ Use Area 14’’ x 24’’ 24’’ SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...
  • Page 43 Contact your distributor for replacement labels. SportsPlay Equipment, Inc ., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140...

  • Page 44: Label Installation

    Install them where they will not be disturbed during play. Inspect labels regularly. If torn, disfigured, damaged or faded, contact your SportsPlay distributor for replacement labels. Top of Surfacing Label Install one to each upright post at the level you have determined will be your “Top of Surfacing”...

  • Page 45: Troubleshooting

    Problem: There is interference between a vertical portion of Trouble Shooting one component and another vertical portion of another component going into the opposite direction. (For instance, in Problem: Incorrect sized hole or no hole where there is the case of a tunnel or bubble window that has a vertical spacer supposed to be one.
  • Page 46 • Roll pins; make sure they are flush and to not stick out. Safety Checklist • Clamps, when aluminum is hammered, it can cause a rough area. De-burr if necessary. Carefully go over each post, deck and component with bare •...

  • Page 47: Other Items

    Appendix C PLAYGROUND SAFETY CHECKLIST SITE: ________________________________________ DATE: ___________________ WORK AREA: _________________________________ INSPECTOR: _____________ N/A S LOCATION/COMMENT ___ ___ All playground equipment securely ___ ___________________ anchored ___ ___ Equipment anchored in concrete: concrete ___ ___________________ not raised above ground level ___ ___ Playground equipment using chains: ___ ___________________ chain links not worn more than 50%...
  • Page 48 Notification for action: Grounds Maintenance __________________ ___________ Building Maintenance __________________ ___________ Security __________________ ___________...
  • Page 49 Daily Playground Inspection Checklist Date of Inspection ___________________ Inspected by:_________________________________ Area Inspected ____________________________________________________________________ Playground Surfaces Comments Surface materials appropriate? Surface thickness correct? (12””) Does it extend 6 feet in all directions? For swings, does it extend twice the height of the suspending bar in back and front? Any holes or gaps that need filling in? Other? Hardware...
  • Page 50 Daily Playground Inspection Checklist Equipment Comments Do elevated surfaces (platforms, ramps) have guardrails? Is equipment properly anchored? Is there at least 9 ft. between play structures > 30”” high? Are spaces that could trap children (i.e., in guardrails/ladder rungs), < 3.5”” or > 9””? Any splintering on wood? Any sharp points or edges on equipment? Is equipment in good overall condition?
