- Page 1 511-107C CURVED BALANCE BEAM Installation Guide INSTALLATION INSTRUCTIONS 511-107C CURVED BALABCE BEAM Please read the entire manual before beginning installation.
- Page 2 511-107C CURVED BALANCE BEAM Installation Guide...
- Page 3 Heat, weather and sunlight can damage the packing materials, which can impact the components. If storage is required you must store the equipment in a controlled environment away from heat, moisture and sunlight. SportsPlay recommends carefully unpacking the unit and taking an inventory before...
- Page 4 100 Bar harbor drive West Conshohocken PA, 19428-2959 Because accidental falls are likely to occur around play equipment, SportsPlay Equipment Inc. recommends that a resilient safety surfacing that will meet standard ASTM F1292 be placed under and around the structure and extend Call –...
- Page 5 511-107C CURVED BALANCE BEAM Installation Guide Tools and Materials List is for tools and materials needed that are not included with the playground Follow manufacturer’s guidelines for proper use of tools and materials. Shovels (long handled spades) Post hole digger Spray paint to mark holes Levels –...
- Page 6 All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:...
- Page 7 511-107C CURVED BALANCE BEAM Installation Guide Loose clothing, hoods, strings or jewelry shall be tight or not worn SUPERVISION GUIDE while playing to prevent strangulation. Although the equipment is designed, installed and maintained in accordance with Ensure the temperature of the equipment is not hazardous. Direct all safety guidelines adult supervision is required.
- Page 8 511-107C CURVED BALANCE BEAM Installation Guide ½ X ½ SET SCREW ¼ ALLEN WRENCH (BLUE BAG)
- Page 9 511-107C CURVED BALANCE BEAM Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...
-
Page 10: Installation Details
511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION INSTALLATION DETAILS Recommended crew (Adult): 2 Installation time: 4 hr User age: 5-12 Use zone: 24’ x 14’ Weight: 50 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required. -
Page 11: Parts List
511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 513-933 Curved Balance Beam 513-934 Leg Curved Balance Beam ½” x ½” Socket Set Screw 196-802 ¼” Socket Key 416-400 805-532 Warning Label 805-534 SportsPlay Label 516-400 Locktite NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts. - Page 12 511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION FOOTING INFORMATION Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
- Page 13 511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION FOOTING LAYOUT VIEW March 2, 2016...
-
Page 14: Specifications
511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING Apply locktite to all bolts during assembly prior to Tube – FloCoat® Galvanized 1 7/8” O.D. and 2 3/8” O.D. completely tightening them. Hardware – Stainless steel & tamper resistant ... -
Page 15: Before You Begin
511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:... - Page 16 511-107C CURVED BALANCE BEAM INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __7) Once the entire beam has been installed and you have verified that the entire beam is level you can add the concrete to the footing holes. Be sure to use concrete with a minimum 2,500 psi and mix the concrete per the manufacturer’s directions before you...
