PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY.
installed in accordance with these instructions.
Lading and Parts list.
within 10 days of receipt of your order.
equipment will give many years of Safe, Trouble-Free use.
or broken parts.
Loose bolts must be tightened and broken parts must be replaced as they
can possibly create dangerous situations leading to unnecessary accidents.
Surfacing should be used under all playground equipment.
available at no charge, from the Consumer Product Safety Commission, include "A Handbook
for Public Playground Safety".
PACKING LIST
1 PIPE
- 1
513-617
1 PIPE
511-113 Vault Bar
IMPORTANT
Any missing or broken parts must be reported to your distributor
When properly installed and maintained,
You can receive your free copy by calling 1-301-504-7908.
Bar
1 TOTAL PC
All equipment must be
Check your shipment against Bill of
Periodically check for loose
Appropriate publications,
HARDWARE BAG
1
- 805-532
Warning Label
1
- 805-534
Sportsplay Label
1
- Maintenance Checklist
WT 80#
Page 1 of 1
Rev 8/5/08
Resilient
CLASS 70
Advertisement
Table of Contents
Related Manuals for SportsPlay Vault Bar
Summary of Contents for SportsPlay Vault Bar
- Page 1 511-113 Vault Bar Page 1 of 1 Rev 8/5/08 IMPORTANT PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY. All equipment must be installed in accordance with these instructions. Check your shipment against Bill of Lading and Parts list. Any missing or broken parts must be reported to your distributor within 10 days of receipt of your order.
- Page 2 511-113 Vault Bar Page 2 of 2 Rev 8/5/08 GENERAL USE/FALL ZONE & FOOTING RECOMMENDATIONS Use/Fall Zones should extend a minimum of 6 Feet in All Directions from the Perimeter of the Equipment Ground Space. This are should be covered with the required amount of Resilient Safety Surfacing Material.
- Page 3 511-113 Vault Bar Page 3 of 3 Rev 8/5/08 GENERAL ASSEMBLY INSTRUCTIONS: Only hand-tighten nuts & bolts on initial assembly. Final tightening should be done EVENLY after final assembly when unit has been plumbed & leveled. After assembly is complete, ANY ENDS OF BOLTS PROTRUDING BEYOND NUTS SHOULD BE CUT OFF AND/OR PEENED OVER TO REMOVE ANY SHARP EDGES.
