PLEASE RETAIN THIS INSTRUCTION SHEET IN YOUR FILES.
PARTS INFORMATION.
INSTRUCTIONS.
IT IS IMPORTANT TO USE AND MAINTAIN ALL PUBLIC PLAYGROUND EQUIPMENT PROPERLY.
EQUIPMENT WHICH IS IMPROPERLY MAINTAINED CAN CAUSE SERIOUS INJURY.
INSPECTIONS, MAINTENANCE, REPAIR AND/OR REPLACEMENT OF DAMAGED PARTS IS NECESSARY FOR
SAFE OPERATION OF EQUIPMENT AND SAFETY OF USERS.
UNDER ALL PLAYGROUND EQUIPMENT.
THE CONSUMER PRODUCT SAFETY COMMISSION, INCLUDE "A HANDBOOK FOR PUBLIC PLAYGROUND
SAFETY."
YOU CAN RECEIVE YOUR FREE COPY BY CALLING 1-301-504-7908.
PACKING LIST
1 CTN
- 1
Hardware
1 BDL
- 3
603-906
1 BDL
- 3
603-505
1 BDL
- 4
503-216
1 PIPE
- 1
513-615
1 CTN
Sportsplay Equipment, Inc
511-114 SIT-UP STATION
ALL EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THESE
APPROPRIATE PUBLICATIONS, AVAILABLE AT NO CHARGE, FROM
Bag
6' Alum Board
Angles
Legs
Toe Bar
3 BDL
1 PIPE
.,
5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
* IMPORTANT *
IT CONTAINS IMPORTANT REPLACEMENT
RESILIENT SURFACING SHOULD BE USED
12
- 605-506
4
- 116-512
12
- 126-504
16
- 316-501
16
- 216-501
1
- 805-532
1
- 805-534
1
- Maintenance Checklist
5 TOTAL PCS
PERIODICAL
HARDWARE BAG
Clips
5/16" x 3" Hex Hd Bolt
5/16" x 1" Carriage Bolt
5/16" Flat Washer
5/16" Hex Nut
Warning Label
SportsPlay Label
WT 80#
CLASS 70
Page 1 of 1
Rev 4/7/03
PLAYGROUND
Advertisement
Table of Contents
Related Manuals for SportsPlay 511-114
Summary of Contents for SportsPlay 511-114
- Page 1 511-114 SIT-UP STATION Page 1 of 1 Rev 4/7/03 * IMPORTANT * PLEASE RETAIN THIS INSTRUCTION SHEET IN YOUR FILES. IT CONTAINS IMPORTANT REPLACEMENT PARTS INFORMATION. ALL EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THESE INSTRUCTIONS. IT IS IMPORTANT TO USE AND MAINTAIN ALL PUBLIC PLAYGROUND EQUIPMENT PROPERLY.
- Page 2 511-114 SIT-UP STATION Page 2 of 2 Rev 4/7/03 GENERAL USE/FALL ZONE & FOOTING RECOMMENDATIONS STATIONARY & PORTABLE EQUIPMENT – USE/FALL ZONES SHOULD EXTEND A MINIMUM OF 6 FEET IN ALL DIRECTIONS FROM THE PERIMETER OF THE EQUIPMENT GROUND SPACE.
- Page 3 511-114 SIT-UP STATION Page 3 of 3 Rev 4/7/03 GENERAL ASSEMBLY INSTRUCTIONS: Check all the parts and hardware with the packing list to be sure you have received everything needed to assemble this product. CONTACT YOUR LOCAL DISTRIBUTOR WITH NOTIFICATION OF ANY MISSING OR DAMAGED PARTS.
