SportsPlay 581-702-WC Installation Instructions Manual

5” od ada arch post swing
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
581-702-WC 5" OD ADA ARCH POST SWING
Installation Guide
INSTALLATION INSTRUCTIONS
581-702-WC
5" OD ADA ARCH POST SWING
Please read the entire manual before beginning installation.
TOTAL PCS = 1 - 4' x 14' PALLET 591# WEIGHT CLASS 70
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 581-702-WC and is the answer not in the manual?

Questions and answers

Related Manuals for SportsPlay 581-702-WC

Summary of Contents for SportsPlay 581-702-WC

  • Page 1 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide INSTALLATION INSTRUCTIONS 581-702-WC 5” OD ADA ARCH POST SWING Please read the entire manual before beginning installation. TOTAL PCS = 1 - 4’ x 14’ PALLET 591# WEIGHT CLASS 70...
  • Page 2 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide TAB SECTION INDEX 1. 3D AND 2D DRAWINGS 2. INSTALLATION GUIDE 3. INSTALLATION STEPS 4. COMPONENT INSTALLATION 5. APPENDIX 6. ORIGINAL COMPONENT MAINTENANCE FORMS 7. COMPLETED COMPONENT MAINTENANCE FORMS...

  • Page 3: Table Of Contents

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide Table of Contents HARDWARE DRAWINGS 3D DRAWING ..................COMPONENT INSTALLATION INSTRUCTION SETS TOP DOWN VIEW ................... APPENDIX FOOTING VIEW ..................FINAL INSTALLATION STEPS Important ....................6 When your receive your playground ..........6 MAINTENANCE AND INSPECTION Before you begin ..................
  • Page 4 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide...
  • Page 5 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide...

  • Page 6: Important

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide Important storing the equipment. Care should be taken with all powder coated and thermoplastic-coated parts to prevent damage to the coating. Please read completely before beginning installation. • You have 30 days from receipt of your equipment to file a claim for This equipment has been designed for safety as well as challenge and fun.
  • Page 7 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide • SportsPlay Equipment inc. has provided two warning labels that state: “WARNING – Installation over a hard surface such as concrete, asphalt or packed earth may result in serious injury or death from falls.” These labels must be installed on vertical posts as per ASTM F1487.

  • Page 8: Safety Surfacing

    SERIOUS INJURY OR DEATH FROM A FALL 100 Bar harbor drive West Conshohocken PA, 19428-2959 Because accidental falls are likely to occur around play equipment, SportsPlay Equipment Inc. recommends that a resilient safety surfacing that will meet Call – 618-832-9585 standard ASTM F1292 be placed under and around the structure and extend throughout the entire use zone.

  • Page 9: Tools And Materials

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide • Tools and Materials Files and sand paper • List is for tools and materials needed that are not included with the Safety surfacing playground • Spray paint to mark holes Follow manufacturer’s guidelines for proper use of tools and materials.

  • Page 10: Before Beginning

    All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:...

  • Page 11: Step 1: Layout

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide FOOTING SIDE VIEW Step 1: Layout Lay structure in the desired location using the top view layout drawing. Measure from each post to ensure there is adequate space for any component and the components fall zone. This drawing is a standard drawing and does not represent the actual playground you are installing.

  • Page 12: Step 3: Deck, Post & Component Installation

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide Step 3: Post & Component Installation SportsPlay recommends having a CPSI (certified playground safety inspector) present during installation. If that’s not possible you should We recommend installing the posts once the post are square and level...

  • Page 13: Other Installation Tips

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide Other Installation Tips • If you are mocking up components with the intention of removing the hardware at some point, you may want to apply lubricating oil to the hardware. Stainless steel hardware has a tendency to seize so if you are planning on removing the hardware you may want to apply lubricant to prevent this.

  • Page 14: Supervision Guide

    581-702-WC 5” OD ADA ARCH POST SWING Installation Guide ▪ Loose clothing, hoods, strings or jewelry shall be tight or not worn SUPERVISION GUIDE while playing to prevent strangulation. ▪ Although the equipment is designed, installed and maintained in accordance with Ensure the temperature of the equipment is not hazardous.
  • Page 15 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide 3/16 ALLEN 1/2 X 3/4 SET SCREW D-SHACKLE ¼ ALLEN 3 1/2” SWING HANGER 5/16 ALLEN...
  • Page 16 581-702-WC 5” OD ADA ARCH POST SWING Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...
  • Page 17 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION INSTALLATION DETAILS ▪ Recommended crew (Adult): 2 ▪ Installation time: 4 hr ▪ User age: 5-12 ▪ Use zone: 32’ x 24’ ▪ Weight: 591 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 18 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 583-572 End Arch Legs 3 1/2” Top Rail 583-211 3 1/2” Swing Hangers 585-521 ½” x 3/4” Socket Set Screw 196-803 3/16” Socket Key 416-350 ¼” Socket Key 416-400 5/16”...
  • Page 19 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION FOOTING INFORMATION ▪ Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
  • Page 20 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT VIEW March 2, 2016...
  • Page 21 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING ▪ Apply locktite to all bolts during assembly prior to ▪ Tube – FloCoat® Galvanized 5” O.D. completely tightening them. ▪ Hardware – Stainless steel & tamper resistant ▪...
  • Page 22 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:...
  • Page 23 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Dig footing holes: Footing holes may be marked out and dug from footing layout; however, it is easier to position swing in proper location, mark holes, move swing aside, and dig holes.
  • Page 24 581-702-WC 5” OD ADA ARCH POST SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __10) Inspect the components: for sharp edges and if necessary file them down and apply touch up paint. March 2, 2016...
  • Page 25 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 4 hr  User age: 5-12  Use zone: 0’ x 0’  Weight: 123 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 26 ¼” Lock Nut 342-506 D - Shackle 416-500BPK 5/16” Socket Key 805-532 Warning Label 805-534 SportsPlay Label 516-400 Locktite 317-140 2’ Galv. Chain 336-012 Lock NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts.
  • Page 27 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION Note: The swing hanger’s pivot point to the ground should be 91” which will result an approximate 4” distance from the bottom of the platform to the ground. May 21, 2020...
  • Page 28 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING  Hardware – Stainless steel & tamper resistant  Do not tighten bolts all the way until the unit is completely assembled and all components are square and level. ...
  • Page 29 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 30 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Front and Back Restrain Chain: To do this all you have to do is use the swivel snaps and hooks it to the D- Shackle. The small restrain chain goes in back and the long for the front.
  • Page 31 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION OPERATIONAL INSTRUCTION CONTIUDE __6) The front platform/chain assembly should be pushed back into its original position and snapped back on the chain assembly of the platform with the swivel snaps. __7) Finally, the long restraining chain should be placed or snapped back onto the chain assembly by using the swivel snaps.
  • Page 32 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION This equipment has been designed for use under STRICT CONTROL BY AN ADULT. This Equipment does not meet the standards set by ASTM and is designed to allow people who are bound to a wheelchair to swing. This unit can cause serious injury if used in an un-supervised area where other children are playing.
