- Page 1 Infrared Thermometer Operating Manual Model: AOJ-20A Issue date: 2023-04 Version of manual:A0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction Page 2 2. Foreword Page 2 3. Package Contents Page 2 4. Warnings and Precautions Page 3 5. Product Description Page 6 6. Features Page 9 7. Product Structure Page 9 8. Display Description Page 10 9. -
Page 3: Introduction
1. Introduction Thank you for purchasing this Forehead & Ear Infrared Thermometer. Please read the Operating Manual carefully before using the thermometer, and put it in a safe and secure place for reference. The Company will make available on request circuit diagrams,component part lists,descriptions, calibration instructions, or other information necessary to assist the User's qualified technicians in repairing parts of the... -
Page 4: Warnings And Precautions
4. Warnings and Precautions 1. Keep this equipment out of children's reach, as they may inadvertently damage it. 2. Never immerse the thermometer into water or other liquids (not waterproof). For cleaning and disinfecting, please follow the instructions in the “Care and Cleaning” section. 3. - Page 5 determine the severity of their illness. 9. Temperature elevation may signal a serious illness, particularly in older adults, those who are frail or have weakened immune systems, as well as in newborns and infants. Please seek professional advice immediately when there is a temperature elevation and if you are taking temperature for whom are: •...
- Page 6 17. Do not modify this equipment without authorization of the manufacturer. 18. Please follow local ordinances and recycling instructions regarding disposal or recycling of the equipment and batteries. 19. When the ambient temperature is outside the 10°C–40°C range, please bring the device to a location within this range and allow it to acclimate for at least 1 hour if initially below 10°C or for at least 2 hours if initially above 40°C.
-
Page 7: Product Description
5. Product Description 1. Overview Infrared Thermometer measures the body temperature based on the infrared energy emitted from the eardrum or the forehead. Users can quickly get measurement results after positioning properly the temperature probe in the ear canal or forehead. Normal body temperature is a range. - Page 8 than the absolute zero (-273.15°C), for the sake of molecule’ s thermal motion, radiate electromagnetic wave to the surrounding ambient including the infrared wave without a break, the relationship between the density of radiation energy with the object’ s temperature conform to the radiation law.
- Page 9 Figure 3 4. Indications for use The infrared thermometers take human body temperature via the eardrum or forehead. The forehead mode is indicated for people of all ages and the eardrum mode is indicated for people above three months old. It applies to both professional use and home use.
-
Page 10: Features
6. Features • Magnetic probe cover and automatic mode switch between forehead & ear mode (OPTIONAL) Quick. • Small Body with super large font. • Multi-functional, can measure ear, forehead. • Easy operation, one button design, to measure ear, forehead. •... -
Page 11: Display Description
8. Display Description 1. Adult forehead mode 2. Child forehead mode (under 12 years old) 3. Ear mode 4. Object mode 5. Celsius / Fahrenheit degrees 6. Previous temperature value 7. Low battery indication 8. Mute /Un-mute icon 9. Current temperature value 9. - Page 12 sensitive to heat. • The device has undergone clinical test, it is safe and accurate when using in accordance with operation manual. 2. Take your forehead temperature • When using the thermometer for the first time, please load the batteries. •...
- Page 13 3. Take your ear temperature 1. Press the Measure/Mute-unmute button to power on. 2. Press the Mode/Memory button to choose and take off the probe cover (if with magnetic probe cover, it is automatically switched between forehead & ear mode), fit the probe snuggly into the ear canal.
- Page 14 is sensitive to the ambient temperature. • After each measurement, clean the temperature probe with a soft cloth, and put the thermometer in a dry and well-ventilated place. • You should wait at least 10 seconds between each measurement. • It is dangerous to make a self-diagnosis or self-treatment based on the obtained measurement results.
- Page 15 7. Checking 40 sets of memory data When the thermometer is turned on or off, hold the Mode/ Memory button for 5 seconds to go to the memory mode, press this button again to check the 40 sets of memories one by one.
-
Page 16: Temperature Taking Tips
10. Replace the battery. Put two AAA batteries correctly into the compartment. Caution • Please make sure the polarities of the batteries are not reversed when installing the batteries, otherwise damage may be caused to the thermometer. • If you’re unable to take a measurement with the low battery icon displaying on the screen, you need to replace with new batteries. -
Page 17: Care And Cleaning
and wait 20 minutes prior to taking a temperature. Use the untreated ear if prescription ear drops or other ear medications have been placed in the ear canal. 4. Holding the thermometer for too long in the hand before taking a measurement can cause the device to warm up. This means the measurement could be incorrect. -
Page 18: Maintenance And Storage
Ensure that no liquid enters the interior of the thermometer. Never use abrasive cleaning agents, thinners or benzene for cleaning and never immerse the instrument in water or other cleaning liquids. Take care not to scratch the surface of the LCD screen. -
Page 19: Error And Troubleshooting
2. After each use, please clean the probe according to the methods mentioned in“ Cleaning and Disinfection”. 3. Please keep the thermometer in a dry, well-ventilated, dust-free and pollution-free place without direct sunlight. Ensure the storage and transportation conditions meet the requirements. - Page 20 One long beep, and red backlit for 3 seconds. Take You have just a measurement under reading is come from a hot an ambient temperature too high environment. between 10°C (50 °F) and 40 °C (104°F) The ambient One long beep, and red temperature is not in backlit for 3 seconds.
-
Page 21: Technical Specifications
14. Technical Specifications Product name Forehead & Ear infrared thermometer Segment LCD, Four color LED backlight Display (white, green, orange, red) Temperature units °C /°F, switchable Power supply 2x1.5V AAA Batteries Measurement: 32.0°C–42.9°C (89.6°F–109.2°F) Direct mode: 0°C–100°C (32°F–199°F) Measurement range Measurement mode ±0.2°C/±0.4 °F Direct mode... -
Page 22: Symbols
Statement: The clinical accuracy or clinical deviation of the medical infrared frontal thermometer has been clinically verified and can be obtained by contacting the manufacturer. 15. Symbols Symbol Description Type BF applied part Information about a manufacturer Refer to instruction manual Comply with local regulations about disposal Date of manufacture Use-by date... -
Page 23: Appendix: Emc Information-Guidance And Manufacturer' S Declarations
Authorized Representative In The European Community Unique Device Identifier Keep away from sunlight Keep dry Fragile, handle with care RoHS mark Non-ionizing electromagnetic radiation Catalogue number 16. Appendix: EMC Information-Guidance and Manufacturer’ s Declarations Warning: • Don’t near active HF surgical equipment and the RF shielded room of an ME system for magnetic resonance imaging, where the intensity of EM disturbances is high. - Page 24 • Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the equipment, including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment could result.
- Page 25 Electrostatic ±8 kV contact ±8 kV contact discharge (ESD) IEC ±2 kV, ±4 kV, ±2 kV, ±4 kV, 61000-4-2 ±8 kV, ±15 kV air ±8 kV, ±15 kV air Electrical fast transient/burst Not applicable Not applicable IEC 61000-4-4 Surge Not applicable Not applicable IEC 61000-4-5 Voltage dips, short...
- Page 26 IEC 60601- Test Complian- Band Modu- Maximum Distance Frequency Service ce level (MHz) lation Power (W) Test Level (MHz) (V/m) (V/m) Pulse 380-390 TETRA 400 modulation 18 Hz FM ± 5 kHz GMRS 460, 430-470 deviation 1 FRS 460 kHz sine Radiated RF IEC61000-4-3 Pulse...
-
Page 27: Warranty And After-Sale Service
Guidance and manufacturer’s declaration - electromagnetic Immunity IEC 60601-1-2 Test Compliance level Modulation Test Level Frequency (A/m) (A/m) Radiated RF IEC61000-4- 30 kHz (Test specifications Pulse modulation 2.1 for ENCLOSURE PORT 134,2 kHz IMMUNITY to proximity magnetic fields) Pulse 13,56 MHz modulation 50 kHz 17. - Page 28 Scannen Sie es für die deutsche Version. Scannez-le pour la version française. Scansiona per la versione italiana. Shenzhen AOJ Medical Technology Co., Ltd. Room 301 & 4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA Email: info@aojmedical.com Website: www.aojmedical.com Tel: 86-755-2778 6026...
