A+ Server
AS -2124US-TNR
AS -2124US-TNRP
USER'S MANUAL
Revision 2.0a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-2124US-TNR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supermicro AS-2124US-TNR

Summary of Contents for Supermicro AS-2124US-TNR

  • Page 1 A+ Server AS -2124US-TNR AS -2124US-TNRP USER’S MANUAL Revision 2.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

  • Page 3: About This Manual

    If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    A+ Server AS -2124US-TNR/TNRP User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Chassis Features .......................10 Control Panel ........................10 Chassis Front ........................11 Chassis Rear ........................12 1.5 Motherboard Layout ......................13 Quick Reference .......................14 System Block Diagram ......................15 1.6 Where to Get Replacement Components ................15 1.7 Returning Merchandise for Service ..................15...
  • Page 5 Contents Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................26 3.2 Accessing the System ......................27 3.3 Motherboard Components ....................28 Processor and Heatsink Installation ..................28 Memory Installation ......................35 Memory Support ......................35 Memory Population Guidelines ..................36 Installing Memory ......................38 Motherboard Battery ......................39 3.4 Chassis Components ......................40 Storage Drives ........................40 Drive Carrier Indicators ....................40...
  • Page 6 A+ Server AS -2124US-TNR/TNRP User's Manual Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................66 5.2 Driver Installation ........................68 5.3 SuperDoctor 5 ........................69 ® 5.4 BMC ............................70 BMC ADMIN User Password ....................70 Chapter 6 UEFI BIOS 6.1 Introduction .........................71 Starting BIOS Setup Utility ....................71 6.2 Main Setup .........................71 6.3 Advanced Setup Configurations ..................73 6.4 IPMI ...........................

  • Page 7: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Unpacking The System

    Chapter 1 Introduction 1.1 Overview The Supermicro AS -2124US-TNR/TNRP A+ is a high-end enterprise server well suited for virtualization and Cloud Computing with flexible networking options. It is based on the H12DSU-iN motherboard and the CSE-219U2TS-R1K62P3-TN24 chassis. This chapter provides a brief outline of the functions and features.

  • Page 9: Chapter 1 Introduction 1.1 Overview

    Expansion Slots One double-width, full-height, full-length PCIe 4.0 x16 slot Additional PCIe slots may be available if using the 24 SAS Kit solution (Contact Supermicro for more information) Cooling Four mid-chassis 8-cm heavy duty fans; two air shrouds, two CPU heatsinks...
  • Page 10 A+ Server AS -2124US-TNR/TNRP User's Manual Ultra Riser Card Options Ultra Riser cards provide network connections and other capabilities. An Ultra Riser card is required to be installed on this system for proper functionality. Ultra Riser Card Options Model LAN Ports Part Number Description Two PCIe 4.0 x16 and one PCIe 4.0 x8...

  • Page 11: Chassis Features

    Chapter 1: Introduction 1.4 Chassis Features Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Figure 1-1. Control Panel Control Panel Features Item Features Description The main power switch applies or removes primary power from the power supply to Power button the server but maintains standby power.

  • Page 12: Chassis Front

    A+ Server AS -2124US-TNR/TNRP User's Manual Chassis Front The illustration below shows the features included on the front of the chassis. Externally accessible hard drive carriers display status lights. Figure 1-2. Front View Chassis Front Features Item Features Description Control Panel Power buttons and status indicators;...

  • Page 13: Chassis Rear

    Chapter 1: Introduction Chassis Rear The illustration below shows the features included on the rear of the chassis. Power supply modules display status lights. Figure 1-4. Rear View Chassis Rear Features Item Features Description Power Supply Two redundant power supply modules Zero, two, or four network ports, depending on the Ultra Riser card Two USB 3.0 ports...

  • Page 14: Motherboard Layout

    A+ Server AS -2124US-TNR/TNRP User's Manual 1.5 Motherboard Layout Below is a layout of the H12DSU-iN motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. BMC_LAN COM1 USB0/1 (3.0)

  • Page 15: Quick Reference

    Chapter 1: Introduction Quick Reference Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JWD1 Watch Dog Pins 1-2 (Reset) Connector Description JIPMB1 4-pin External I C Header (for an IPMI card) Onboard Battery VGA Port UID_SW UID Switch COM1 COM Port BMC_LAN LAN port to access the BMC...

  • Page 16: Motherboard Block Diagram

    A+ Server AS -2124US-TNR/TNRP User's Manual Motherboard Block Diagram System Block Diagram – AS -2124US-TNR/TNRP 16 DDR4 DIMM Slots 16 DDR4 DIMM Slots AMD EPYC AMD EPYC xGMI x4 PCI-E x32 WIO LH Riser Slot (CPU 0) (CPU1) PCI-E x40 (32 PCI-E Lanes) Ultra Riser Slot (40 PCI-E Lanes)

  • Page 17: Where To Get Replacement Components

    For faster service, RMA authorizations may be requested online (http://www.supermicro.com/ support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.

  • Page 18: Chapter 2 Server Installation

    A+ Server AS -2124US-TNR/TNRP User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components.

  • Page 19: Server Precautions

    Chapter 2: Server Installation • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 20: Circuit Overloading

    A+ Server AS -2124US-TNR/TNRP User's Manual Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 21: Installing The Rails

    Chapter 2: Server Installation 2.3 Installing the Rails This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided.

  • Page 22: Releasing The Inner Rail

    A+ Server AS -2124US-TNR/TNRP User's Manual Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. 1.

  • Page 23: Installing The Inner Rails

    Chapter 2: Server Installation Installing the Inner Rails Begin the rack mounting procedure by installing the inner rails to the chassis. 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 24: Installing The Outer Rails Onto The Rack

    A+ Server AS -2124US-TNR/TNRP User's Manual Installing the Outer Rails onto the Rack 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks on the front of the outer rail onto the square holes on the front of the rack.

  • Page 25: Installing The Server Into A Rack

    Chapter 2: Server Installation 2.4 Installing the Server into a Rack Once rails are attached to the chassis and the rack, you can install the server. Caution: Heavy! Use two or more people, or a lift to install the server. 1.

  • Page 26: Removing The Chassis From The Rack

    A+ Server AS -2124US-TNR/TNRP User's Manual Removing the Chassis from the Rack Caution! It is dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have sufficient assistance supporting the chassis when removing it from the rack.

  • Page 27: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 28: Accessing The System

    A+ Server AS -2124US-TNR/TNRP User's Manual 3.2 Accessing the System The CSE-219U chassis features a removable top cover that allows access to components. Check that all ventilation openings in the chassis are clear and unobstructed. Removing the Top Cover 1. Remove the two screws on the side of the chassis that secures the cover to the chassis 2.

  • Page 29: Motherboard Components

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. All graphics in this manual are for illustration only. Your components may look different. Installing the Processor and Heatsink Begin by removing power from the system as described in Section 3.1.
  • Page 30 A+ Server AS -2124US-TNR/TNRP User's Manual 2. The spring-loaded Force Frame will raise up after the last screw (#1) is removed. Gently allow it to lift up to its stopping position. Figure 3-3. Raising the Force Frame 3. Lift the Rail Frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the Rail Frame, lift it to a position so you can do the next step of removing the External Cap.
  • Page 31 Chapter 3: Maintenance and Component Installation 4. Remove the External Cap from the Rail Frame by pulling it upwards through the rail guides on the Rail Frame. External Cap PnP Cover Cap Figure 3-5. Removing the External Cap 5. The CPU Package is shipped from the factory with the blue Carrier Frame pre- assembled.
  • Page 32 A+ Server AS -2124US-TNR/TNRP User's Manual Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the Rail Frame plate.
  • Page 33 Chapter 3: Maintenance and Component Installation Figure 3-8. Securing the Force Frame 10. Replace the screws in the order 1-2-3, tightening to 16.1 kgf-cm (14 lbf-in) of torque. The Force Frame secures both the Rail Frame and CPU Package. Caution: Tightening must be executed in proper 1-2-3 sequence to avoid causing catastrophic damage to the socket or CPU Package.
  • Page 34 A+ Server AS -2124US-TNR/TNRP User's Manual 11. Lower the heatsink down till it rests securely on CPU Package over the four screw holes on the socket frame. Figure 3-10. Mounting the Heatsink 12. Using a diagonal pattern and a Torx T20 driver, tighten the four heatsink screws evenly to 16.1 kgf-cm (14.0 lbf-in) of torque.

  • Page 35: Removing A Heatsink

    Chapter 3: Maintenance and Component Installation Removing a Heatsink We do not recommend removing the heatsink. If necessary, please follow the instructions below to prevent damage to the CPU or the CPU socket. Note: Wait for the heatsink to cool down before removing it. 1.

  • Page 36: Memory Installation

    A+ Server AS -2124US-TNR/TNRP User's Manual Memory Installation Memory Support The H12DSU-iN supports up to 8TB of ECC DDR4 3200 MHz speed, RDIMM/LRDIMM/3DS/ NVDIMM memory in thirty-two slots. Check the Supermicro website for possible updates to memory support. Processors and their Corresponding Memory Modules CPU#...

  • Page 37: Memory Modules

    Balance memory. Using unbalanced memory topology, such as populating two DIMMs in one channel while populating one DIMM in another channel, reduces performance. It is not recommended for Supermicro systems. • In single-CPU configurations, memory must be installed in the DIMM slots associated with the installed CPU.
  • Page 38 A+ Server AS -2124US-TNR/TNRP User's Manual Figure 3-12. DIMM Numbering...

  • Page 39: Installing Memory

    Chapter 3: Maintenance and Component Installation Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge.

  • Page 40: Motherboard Battery

    A+ Server AS -2124US-TNR/TNRP User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 41: Chassis Components

    These carriers also help promote proper airflow. Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at https://www.supermicro.com/en/Aplus/system/2U/2124/AS-2124US-TNRP.cfm...
  • Page 42 A+ Server AS -2124US-TNR/TNRP User's Manual Removing a Hot-Swap Drive Carrier from the Chassis 1. Press the release button on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. Figure 3-14.

  • Page 43: Installing A Drive

    Chapter 3: Maintenance and Component Installation Installing a Drive 1. Remove the dummy drive, which comes pre-installed in the drive carrier. Pull open the latches on the left side of the carrier and remove the dummy. Dummy Drive Latches Carrier Figure 3-15.

  • Page 44: Cabling For Nvme

    (AOC-SLG4-2E4T and AOC-SLG4-4E4T) and the motherboard. The proper ports must be connected so that all NVMe drives will be detected. Note: These instructions are not applicable if using the 24 SAS Kit solution. (Contact Supermicro for more information.) SXB2 for Riser Card, RSC-WR-6...
  • Page 45 Chapter 3: Maintenance and Component Installation Positions of Add-on Cards • Plug AOC-SLG4-4E4T into the lower slot of RSC-W2-66G4 in SXB1. • Plug AOC-SLG4-4E4T into the slot of RSC-WR-6 in SXB2. • Plug AOC-SLG4-2E4T into the lower-left slot of Ultra Riser card in SXB3. •...
  • Page 46 A+ Server AS -2124US-TNR/TNRP User's Manual Figure 3-18. Backplane BPN-NVME4-216N-S24 Showing NVMe Drive Numbers (Also labeled on the backplane) NVMe Cabling From Connector on Cable Drive Bay Backplane Port Motherboard JSLIM1 (P1_NVMe0/1) CBL-SAST-1268-85 NVMe1 JSLIM2 (P1_NVME2/3) CBL-SAST-1256A-85 NVMe3 CBL-SAST-1282-85 NVMe5&7 In 2UR68G4-i4XTS upper slot AOC-SLG4-4E4T CBL-SAST-1265A-8...

  • Page 47: Hot-Swap For Nvme Drives

    Chapter 3: Maintenance and Component Installation Hot-Swap for NVMe Drives Supermicro Ultra servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Ejecting a Drive 1.

  • Page 48: Checking The Temperature Of An Nvme Drive

    A+ Server AS -2124US-TNR/TNRP User's Manual Checking the Temperature of an NVMe Drive There are two ways to check using IPMI. Checking a Drive • IPMI > Server Health > NVMe SSD – Shows the temperatures of all NVMe drives, as in Figure 3-4.

  • Page 49: System Cooling

    2. Push the release tab and pull the failed fan from the chassis. Fans can be replaced while the system is running. 3. Replace the failed fan with an identical fan, available from Supermicro. Push the new fan into the housing, making sure the air flow direction is the same.

  • Page 50: Installing The Air Shrouds

    A+ Server AS -2124US-TNR/TNRP User's Manual Installing the Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. They do not require screws to install. If you use an M.2 SSD, a specialized shroud is installed instead of the standard shrouds.

  • Page 51: Checking The Server Air Flow

    Overheat Temperature Setting Some backplanes allow the overheat temperature to be set at 45, 50, or 55 by changing a jumper setting. For more information, consult the backplane user manual at www.supermicro. com. (Click Support, then the Manuals link.) Responses If the server overheats: 1.

  • Page 52: Power Supply

    It should be replaced as soon as convenient. They can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120v or 180-240v.
  • Page 53 Chapter 3: Maintenance and Component Installation Figure 3-23. Replacing the Power Supply 4. Push the new power supply module into the power bay until it clicks. Replace with the same model. 5. Plug the AC power cord back into the module.

  • Page 54: Pcie Expansion Cards

    A+ Server AS -2124US-TNR/TNRP User's Manual PCIe Expansion Cards Riser cards on chassis brackets allow you to add one double-width, full-height, full-length x16 PCIe 4.0 expansion card. Only slot below is available as the other are used for system NVMe support. Note that more slots may be available when the system includes the 24 SAS kit.

  • Page 55: Installing Full Height Expansion Cards

    Chapter 3: Maintenance and Component Installation Installing Full Height Expansion Cards Riser Card Brackets Only this slot is available for a PCIe expansion card.* Figure 3-25. Installing an Expansion Card *Not applicable if using the 24 SAS Kit solution. (Contact Supermicro for more information.)

  • Page 56: Removing The Ultra Riser Card

    A+ Server AS -2124US-TNR/TNRP User's Manual Removing the Ultra Riser Card To remove the Ultra riser card, use two hands. One hand lifts the mylar release tab and the other hand lifts at the PCIe x8 slot at the same time. Caution: Lifting at only one of these points may cause damage to connectors on the motherboard.

  • Page 57: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections, jumpers and LED indicators on the motherboard and provides pinout definitions. Not all connections are required. A motherboard layout indicating component locations may be found in Chapter 1. Please review the Safety Precautions in appendix B before installing or removing components.

  • Page 58: Headers And Connectors

    A+ Server AS -2124US-TNR/TNRP User's Manual 4.2 Headers and Connectors The data cables in the system have been carefully routed to maintain airflow efficiency. If you disconnect any of these cables, take care to re-route them as they were originally. Important! Make sure the the cables do not come into contact with the fans.
  • Page 59 The JTPM1 header is used to connect a Trusted Platform Module (TPM), which is available from Supermicro. A TPM is a security device that supports encryption and authentication in hard drives. It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.

  • Page 60: Control Panel

    Control Panel JF1 contains header pins for various control panel connections designed specifically for use with Supermicro chassis. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.

  • Page 61: Power Button

    Chapter 4: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (with a setting in the BIOS - see Chapter 6). To turn off the power when the system is in suspend mode, press the button for 4 seconds or longer.

  • Page 62: Nmi Button

    A+ Server AS -2124US-TNR/TNRP User's Manual NIC1/NIC2 (LAN1/LAN2) The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and the LED connection for LAN Port 2 is on Pins 9 and 10. Attach the NIC LED cables here to display network activity.

  • Page 63: Ports

    Chapter 4: Motherboard Connections 4.3 Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-2. Rear I/O Ports Rear I/O Ports Description Description USB 0/1 Ports UID button and LED BMC LAN Port VGA Port COM1 Port...

  • Page 64: Jumpers

    A+ Server AS -2124US-TNR/TNRP User's Manual 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 65 Chapter 4: Motherboard Connections Watch Dog JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 66: Led Indicators

    A+ Server AS -2124US-TNR/TNRP User's Manual 4.5 LED Indicators LAN LEDs For LAN ports with two LEDs, one LED indicates activity when blinking. The other may be green, amber or off to indicate the speed of the connection. For LAN ports with one LED, the LED indicates activity when blinking and may be green, amber or off to indicate the speed of the connection.

  • Page 67: Chapter 5 Software

    1. Create a method to access the MS Windows installation ISO file. That can be a USB flash or media drive. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 68 SuperServer AS -2124US-TNR/TNRP User's Manual 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner.

  • Page 69: Driver Installation

    Chapter 5: Software 5.2 Driver Installation The Supermicro website contains drivers and utilities for your system at www.supermicro.com/ wdl/driver/AMD/SP3. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard.

  • Page 70: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 71: Bmc

    There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 72: Chapter 6 Uefi Bios

    A+ Server AS -2124US-TNR/TNRP User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMI BIOS setup utility for the H12DSU-iN and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated.
  • Page 73 HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2016 after RTC reset. Supermicro H12DSU-iN (Motherboard model) BIOS Version Build Date (of the BIOS) CPLD (Complex Programmable Logic Device) Version: This item displays the CPLD version used in the system.

  • Page 74: Advanced Setup Configurations

    A+ Server AS -2124US-TNR/TNRP User's Manual 6.3 Advanced Setup Configurations Use the arrow keys to select the Advanced tab and press <Enter> to access the submenu items. Caution: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.

  • Page 75: Trusted Computing

    Chapter 6: UEFI BIOS Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...

  • Page 76: Super Io Configuration

    A+ Server AS -2124US-TNR/TNRP User's Manual PSP Firmware Versions  This section displays the Platform Security Processor (PSP) firmware versions. PSP Directory Level 1 (Fixed) • PSP Recovery BL Ver • SMU FW Version • ABL Version PSP Directory Level 2 (Updateable) •...

  • Page 77: Sol Configuration

    Chapter 6: UEFI BIOS Device Settings This item displays the status of a serial part specified by the user. Change Settings This feature specifies the base I/O port address and the Interrupt Request address of a serial port specified by the user. Select Auto to allow the BIOS to automatically assign the base I/O and IRQ address.
  • Page 78 A+ Server AS -2124US-TNR/TNRP User's Manual Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 79 Chapter 6: UEFI BIOS Putty KeyPad This feature selects the settings for Function Keys and KeyPad used for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SC0, ESCN, and VT400. Redirection After BIOS POST For this setting, when the Bootloader is selected, then the Legacy Console Redirection is disabled before booting to the legacy OS.

  • Page 80: Legacy Console Redirection Settings

    A+ Server AS -2124US-TNR/TNRP User's Manual as a parity bit to be sent along with the data bits. Select Space to add a Space as a parity bit to be sent with your data bits. The options are None, Even, Odd, Mark, and Space. Stop Bits A stop bit indicates the end of a serial data packet.
  • Page 81 Chapter 6: UEFI BIOS Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection Select Enabled to enable EMS console redirection support for a serial port specified by the user. The options are Enabled and Disabled. *If the item above set to Enabled, the following items will become available for user's configuration: ...

  • Page 82: Cpu Configuration

    A+ Server AS -2124US-TNR/TNRP User's Manual as a parity bit to be sent along with the data bits. Select Space to add a Space as a parity bit to be sent with your data bits. The options are None, Even, Odd, Mark, and Space. Stop Bits A stop bit indicates the end of a serial data packet.
  • Page 83 Chapter 6: UEFI BIOS CPU1/CPU2 Information  These sections are for informational purposes. They will display some details about the detected CPUs on the motherboard, such as: • CPU Version • Number of Cores Running • Processor Family • Processor Model •...

  • Page 84: Memory Configuration

    A+ Server AS -2124US-TNR/TNRP User's Manual Memory Configuration  Memory Clock This setting allows you to select different memory clock speed. Options include Auto and speed settings from 2666Mhz, 2933MHz to 3200MHz. Memory Interleaving This setting controls fabric level memory interleaving. Note that the channel, die and socket have requirements on memory populations and it will be ignored if the memory doesn't support the selected option.
  • Page 85 Chapter 6: UEFI BIOS SR-IOV Support If the system has SR-IOV capable PCI-E devices, this setting will Enable or Disable the Single Root IO Virtualization Support for the system. BME DMA Mitigation Re-enable Bus Master Attribute disabled during Pci enumeration for PCI Bridges after SMM Locked.

  • Page 86: Usb Configuration

    A+ Server AS -2124US-TNR/TNRP User's Manual Network Stack This setting allows you to Enable or Disable the UEFI Network Stack. IPv4 PXE Support This setting allows you to Enable or Disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. IPv4 HTTP Support This setting allows you to Enable or Disable IPv4 HTTP boot support.

  • Page 87: Port 60/64 Emulation

    Chapter 6: UEFI BIOS Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which in turn, will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices.The options include Disabled and Enabled. SATA Configuration This section displays the detected SATA devices installed on the system.
  • Page 88 A+ Server AS -2124US-TNR/TNRP User's Manual Network Configuration iSCSI Configuration  iSCSI Initiator Name This feature allows the user to enter the unique name of the iSCSI Initiator in IQN format. Once the name of the iSCSI Initiator is entered into the system, configure the proper settings for the following items.
  • Page 89 Chapter 6: UEFI BIOS Use this feature to enroll to discard all changes and exit TLS settings. Delete Certification  Use this feature to delete certification. RAM Disk Configuration Press <Enter> to add/remove RAM disks. Disk Memory Type Speficifies type of memory to use from available memory pool in system to create a disk. Create raw The valid RAM disk size should be multiples of the RAM disk block size.

  • Page 90: Ipmi

    A+ Server AS -2124US-TNR/TNRP User's Manual 6.4 IPMI Use this tab page to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system. System Event Log Enabling/Disabling Options SEL Components...

  • Page 91: Bmc Network Configuration

    Chapter 6: UEFI BIOS to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset. When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full.
  • Page 92 A+ Server AS -2124US-TNR/TNRP User's Manual Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1). VLAN This item displays the virtual LAN settings. The options are Disable and Enable. Configure IPv6 Support This section displays configuration features for IPv6 support.

  • Page 93: Event Logs

    Chapter 6: UEFI BIOS 6.5 Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 94: View Smbios Event Log

    A+ Server AS -2124US-TNR/TNRP User's Manual When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full.

  • Page 95: Security

    Chapter 6: UEFI BIOS 6.6 Security Use this tab page to configure Security settings. Administrator Password Press <Enter> to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well. User Password Press Enter to create a new, or change an existing User password.

  • Page 96: Key Management

    A+ Server AS -2124US-TNR/TNRP User's Manual Secure Boot Mode Use this item to select the secure boot mode. The options are Standard and Custom. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot. The options are Disabled and Enabled.
  • Page 97 Chapter 6: UEFI BIOS Restore DB defaults  Select Yes to restore all DBs to the default settings. The options are Yes and No. Platform Key (PK)  Details Select this feature to view the details of the Platform Key. Export Select Yes to export a PK from a file on an external media.
  • Page 98 A+ Server AS -2124US-TNR/TNRP User's Manual Append Select Yes to add the db from the manufacturer's defaults list to the existing db. Select No to load the db from a file. The options are Yes and No. Delete Select Ok to remove the db and then the system will reset to Setup/Audit Mode. Forbidden Signatures ...
  • Page 99 Chapter 6: UEFI BIOS Append Key Select Yes to add the DBT from the manufacturer's defaults list to the existing DBT. Select No to load the DBT from a file. The options are Yes and No.  OsRecovery Signature The options are Update and Append. This item uploads and installs an OSRecovery Signature.

  • Page 100: Boot

    A+ Server AS -2124US-TNR/TNRP User's Manual 6.7 Boot Use this tab page to configure Boot Settings. Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are Legacy, UEFI, and DUAL. The default setting is DUAL. Legacy to EFI Support This option Disables or Enables the system to boot to an EFI OS after the boot failed from the legacy boot order.

  • Page 101: Save & Exit

    Chapter 6: UEFI BIOS 6.8 Save & Exit Use this tab page to configure Save & Exit settings. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 102 A+ Server AS -2124US-TNR/TNRP User's Manual Default Options Restore Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>.

  • Page 103: Bios Update Using Ipmi

    If necessary, the system BIOS can be updated using IPMI. Documentation on IPMI is available at http://www.supermicro.com/products/nfo/IPMI.cfm. 1. Download the BIOS file using the link on the server web page. Unzip and save it. 2. Access the IPMI web interface. Enter the IP address and log in. The default username and password are ADMIN/ADMIN.
  • Page 104 A+ Server AS -2124US-TNR/TNRP User's Manual Start Button Verify Date Clear Checkboxes Figure 6-3. Start Upgrade Dialog 6. In the Start Upgrade dialog, make sure the three checkboxes are not checked, and verify the date of the BIOS file you uploaded before proceeding. 7.

  • Page 105: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 106 A+ Server AS -2124US-TNR/TNRP User's Manual 2. While the system is turned off, open the chassis and locate the internal USB 3.0 Type-A port on the motherboard. Insert the USB device that contains the new BIOS binary image, SUPER.ROM.. 3. Power on the system. 4.
  • Page 107 SUPERMICRO BIOS Update: https://www.youtube.com/watch?v=S8z6iOEHGwY • If the BIOS flash recovery fails, contact our RMA Department to have the BIOS chip reprogrammed. This will require shipping the board to Supermicro for repair. Submit your RMA request at https://www.supermicro.com/support/rma. Please follow all...

  • Page 108: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 109 Appendix A Standardized Warning Statements for AC Systems Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.

  • Page 110: Installation Instructions

    A+ Server AS -2124US-TNR/TNRP User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...

  • Page 111: Circuit Breaker

    Appendix A Standardized Warning Statements for AC Systems Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 112 A+ Server AS -2124US-TNR/TNRP User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.

  • Page 113: Power Disconnection Warning

    Appendix A Standardized Warning Statements for AC Systems Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...

  • Page 114: Equipment Installation

    A+ Server AS -2124US-TNR/TNRP User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...

  • Page 115: Restricted Area

    Appendix A Standardized Warning Statements for AC Systems Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 116 A+ Server AS -2124US-TNR/TNRP User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.

  • Page 117: Battery Handling

    Appendix A Standardized Warning Statements for AC Systems Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...

  • Page 118: Redundant Power Supplies

    A+ Server AS -2124US-TNR/TNRP User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가...
  • Page 119 Appendix A Standardized Warning Statements for AC Systems ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.

  • Page 120: Backplane Voltage

    A+ Server AS -2124US-TNR/TNRP User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.

  • Page 121: Comply With Local And National Electrical Codes

    Appendix A Standardized Warning Statements for AC Systems ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스...

  • Page 122: Product Disposal

    A+ Server AS -2124US-TNR/TNRP User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.

  • Page 123: Hot Swap Fan Warning

    Appendix A Standardized Warning Statements for AC Systems Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 124 A+ Server AS -2124US-TNR/TNRP User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.

  • Page 125: Power Cable And Ac Adapter

    Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 126 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 127 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 128: Appendix B System Specifications

    A+ Server AS -2124US-TNR/TNRP User's Manual Appendix B System Specifications Processors Dual AMD EPYC 7003/7002 series in SP3 type sockets; System on Chip (7003 Series Processor drop-in support requires BIOS version 2.0 or newer) BIOS 128Mb SPI AMI BIOS SM Flash UEFI BIOS Memory Up to 8 TB of ECC DDR4 3200 MHz speed, RDIMM/LRDIMM/3DS/NVDIMM memory in 32 slots SATA Controller...
  • Page 129 Appendix B: System Specifications Operating Environment Operating Temperature: 10º to 35º C (50º to 95º F) Non-operating Temperature: -40º to 70º C (-40º to 158º F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA, NRTL, CB Applied Directives, Standards...

  • Page 130: Appendix C Ipmi Crash Dump

    In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using IPMI. The IPMI manual is available at https://www.supermicro.com/solutions/IPMI.cfm. Check IPMI Error Log 1.
  • Page 131 Appendix C IPMI Crash Dump Downloading the Crash Dump File 1. In the IPMI interface, click the Miscellaneous tab, then the Trouble Shooting option. 2. Click the Dump button and wait five minutes for the file to be created. (No confirm ation message will appear.) 3.

This manual is also suitable for:

As-2124us-tnrp

Table of Contents
