Chapter 1 Product Introduction
This chapter describes the features of the model of SMCFS1601/SMCFS2401
16/24-Port 10/100Mbps Fast Ethernet Switch.

1.1 Product Overview

SMCFS1601/SMCFS2401
Negotiation RJ45 ports. Each port of the SMCFS1601/SMCFS2401 supports auto
MDI/MDI-X function, eliminating the need for crossover cables or Uplink ports. The
Switch is Plug- and-Play and any port can be simply plugged into a server, a hub
or a switch, using straight cable or crossover cable.
The SMCFS1601/SMCFS2401 16/24-port 10/100Mbps Fast Ethernet Switch
provides you with a low-cost, easy-to-use, high-performance, seamless and
standard upgrade to improve your old network to a 100Mbps network. It will boost
your network performance up to full duplex data transfer.

1.2 Features

Complies with IEEE802.3, IEEE802.3u standards
16/24 10/100Mbps Auto-Negotiation RJ45 ports supporting Auto- MDI/MDIX
Supports IEEE802.3X flow control for full-duplex mode and backpressure for
half-duplex mode
LED indicators for monitoring power, link, activity, speed
Rack-mountable steel case
Internal power supply
Chapter 2 Identifying External Components
This Chapter describes the front panel, rear panel and LED indicators of the
Switch. SMCFS1601/SMCFS2401 just differ in the number of LED indicators and
ports, and all figures in this guide are of SMCFS2401.
Switch provides
2
16/24-Port 10/100Mbps Auto-
