Model 73BHER
Security Overhead Concealed Closer
With Emergency Release, Non-Hold Open
Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm.
For more information go to: www.P65warnings.ca.gov.
7
Model 73BHER, Emergency Release Hinge Hung
Components
(Supplied fasteners shown on page 3)
Arm
70218- (finish)
Closer Body
73 LAP
Tools Needed
Flathead
Phillips
Screwdriver Screwdriver
7
Copyright © 2024, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
IS-73BHER Rev 1 10/24
6 5
Cover Plate
70202- (finish)
Security Track &
End Cap
(90382)
Retrofit Track Spacer and
Screws, Optional (90260)
Not for new installation.
Replacement only.
Consult factory.
Drill #7 1/4-20
for Metal
6 5
Approved 2024-10-04
These instructions utilize Markar and Pemko Anti-
Barricade Rescue Hardware, supplied separately, to
illustrate an emergency release hinge installation. For
other manufacturers' hinge and/or stop products, please
consult Norton Rixson Support for templating and
installation modifications.
4
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Closer
Screw Pack
(90241-finish)
Cover Plate
Screw Pack
(90278-finish)
Arm
Screw Pack
(90283-finish)
Slider Centering
Hub (70219)
Framing
Square
ASSA ABLOY Accessories and Door Controls Group, Inc.
ANGLES
3/16"
Tape
FRACTIONS
SURFACE FINISH
for Wood Measure
ASSA ABLOY Accessories and
Door Controls Group, Inc.
4
3 2
Track
Screw Pack
(90242)
Non-hold Open
Stop Block
Security Torx
(90255)
Screw Pack
(90385)
Slider
(90253)
Safety Glasses
Pencil
MATERIAL
SEE BOM
WITH ASME Y14.5M - 1994
.03
.01
INCH
.005
MM
T10 T15 T30
1/64
HEAT TREATMENT
THIRD ANGLE
63
Security Security Security
SURFACE/FINISH
Torx Bit Torx Bit Torx Bit
MASS VOLUME SURFACE AREA
0.029 lb 1594.634 in³ 5574.144 in²
