Assa Abloy NORTON RIXSON 6300 Series Installation Instructions Manual

6300 Series Full Feature Low Energy Operator
Models 6312, 6352 (Pull Side)
Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm. For more information go to:
www.P65warnings.ca.gov.
6312 Pull Side Up to 180° opening
End Cap Kit
(6300END)
6352 Pull Side Double Egress Up to 130° opening (Right Hand Shown)
Double Egress
Pull Arm Pkg
(6350-1L (LH);
6350-1R (RH)
Tools Needed
1/4-20 12-24
#7 #16
2.5mm
10" or 12"
#2 & #3
Stripper
The table below provides a list of documents associated with this product. These documents are available for download
from www.nortonrixson.com. If additional information or assistance is needed, contact Technical Product Support.
6300 Series Quick Start Guide
6300 Series Operator Programming Guide
6300 Series Operator, 6311/6351 Pull Side and Double Egress Installation Instructions
6312/6352 Pull Side Template, 36-48" Door Width, 90-250 lb. Door Weight, 180° Max Open Angle
Copyright © 2019, 2021, 2023, 2025, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9363-0008-020 Rev 7 01/25
Backplate
Operator Body
(6300LAP)
Standard Pull Arm Pkg
(6310-1)
Safety
Glasses
9/32" 3/32"
3/8" 3/16"
Ø7/8 Drill
Hole Saw
3/4"
Deep
Wire
1/2" Well
Pliers
Document Title
Approved 2025-01-28
Track
(7100-1T)
Supplied Fasteners & Tools
3x
Track Option
Zip #12-24 x 1-3/4"
or
Ties Sleeve Nut & Bolt
4x
Operator Body
Punch
1/4-20 x 3-3/4"
Pour la version francaise voir NortonRixson.com.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Optional
Power Cord/Surface Conduit Brackets
(6300CBPC or 6300CB)
End Cap Kit
(6300END)
Power Supply
(6300CM)
(6300COV or
6300COVCB)
3/16"
2x 10x
1/4-14 x 1-3/4"
Self-drilling
Machine Screw
Screw
6x 10x
Power Supply 1/4-20 x 5/8"
& End Caps Machine
1/4-20 x 3/8" Screws
Document Number
80-9363-0014-020
80-9363-0015-020
80-9363-0005-020
80-7363-0003-020
Cover
5/32"
1x
2x
Cable
Optional
Retaining Clip
8-32 x 1/4"
1x
2x
Arm
Cable Retaining
1/4-20 x 7/8"
Clips
w/ Nut
