CSG1000 Series Hardware Guide
At a Glance
The Versa Cloud Services Gateway (CSG) 1000 series appliances deliver carrier-grade reliability, high performance,
and high compute capacity for enterprise-grade routing, SD-WAN, next-generation security, and uCPE scenarios. They
are designed for deployment in large enterprise branches, campus sites, or data centers that require advanced secure
SD-WAN along with comprehensive advanced application and cloud-intelligent SD-WAN services on premises.
The CSG1000 series appliances come with LAN and WAN ports, including Ethernet and non-Ethernet (ADSL2+/VDSL2
and T1/E1) interfaces and wireless (3G, 4G LTE, LTE Advanced, 5G, and WiFi access point) WAN and LAN access
technologies.
These appliances provide the following features:
• Support for different CPUs and memory sizes
• Interface ports
◦ One RJ45 1-Gigabit Ethernet port
◦ One RJ45 serial console port
◦ Two RJ45 10-Gigabit Ethernet ports for WAN Interfaces
◦ Eight RJ45 1-Gigabit Ethernet PoE (30 W) ports for LAN Interfaces
◦ Two SFP+ 10-Gigabit Ethernet ports for WAN Interfaces
◦ Four SFP+ 10-Gigabit Ethernet ports for LAN Interfaces
◦ Two USB 2.0 management port for plugging in external LTE or WiFi modems
◦ Two LTE wireless interface
◦ Two WiFi wireless interface
• Field replaceable 1+1 redundant, hot-swappable power supply units (PSUs)
• Field replaceable 3+1 fans for cooling
• Rack-mountable in a 19-inch rack.
◦ Two of the 10-Gigabit Ethernet interfaces are multirate copper interfaces capable of operating as 1- or
10-Gigabit Ethernet interfaces.
◦ The remaining 10-Gigabit Ethernet interfaces have SFP+ ports that support 10-Gigabit Ethernet or 1-Gigabit
Ethernet fiber or copper modules.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_...
Updated: Fri, 03 Jan 2025 15:22:49 GMT
Copyright © 2024, Versa Networks, Inc.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CSG1000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Versa Networks CSG1000 Series

Summary of Contents for Versa Networks CSG1000 Series

  • Page 1 SD-WAN along with comprehensive advanced application and cloud-intelligent SD-WAN services on premises. The CSG1000 series appliances come with LAN and WAN ports, including Ethernet and non-Ethernet (ADSL2+/VDSL2 and T1/E1) interfaces and wireless (3G, 4G LTE, LTE Advanced, 5G, and WiFi access point) WAN and LAN access technologies.

  • Page 2: Chassis Views

    CSG1000 Series Appliance Models The CSG1000 series appliances are available in the following models: • CSG1300, with 128 GB of storage • CSG1500, with 256 GB of storage Chassis Views The CSG1300 series and CSG1500 series appliances are physically identical.

  • Page 3: Chassis Specifications

    LTE wireless interfaces WiFi wireless interfaces 2 x 16 MB Memory SPI Flash 128 GB (for Versa Operating System [VOS Disk 1 SSD, M.2 SATA 3 software) https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 4 Chassis height 1.72” (43.7 mm) 17.24” (438 mm) Chassis width 14.96" (380 mm) Chassis depth 23.81 lb (10.80 kg) Chassis weight 1 RU Rack height Package Specifications https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 5 –40°C to 70°C (–40°F to 158°F) at sea level Temperature 5% to 90% non-condensing Humidity CSG1500 Appliance Table 2 lists the specifications for a CSG1500 appliance chassis. Table 2: CSG1500 Chassis Specifications https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 6 128 GB (for VOS software) Disk 1 SSD, M.2 SATA 3 16 GB (for diagnostics) Disk 2 SSD, M.2 SATA 3 Power Specifications AC input Power supply https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 7 23.90 lb (10.84 kg) Chassis weight 1 RU Rack height Package Specifications 7" (17.78 cm) Package height 16.7" (42.4 cm) Package width 12" (30.48 cm) Package depth https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 8 Temperature 5% to 90% non-condensing Humidity CSG1000 Series Appliance SKUs CSG1000 series SKUs have the following format: model – xxx – yyy model indicates the CSG1000 appliance model number. It can be one of the following: • CSG1300 • CSG1500 xxx indicates the number and type of wireless modules.

  • Page 9: Regulatory Compliance

    • 4GP—4 general-purpose NIC ports • 8GP—8 general-purpose NIC ports • Blank—No LTE or WiFi Module Regulatory Compliance Table 3 lists the regulatory compliance specifications for a CSG1000 series chassis. Table 3: CSG1000 Series Regulatory Compliance Specifications Item Specification CB (IEC/EN60950-1 and IEC/EN 62368-1) Safety UL (CSA 22.2 No 62368-1 and UL62368-1)
  • Page 10 • JATE—Article 9 and 34 Japan • MIC—ARIB STD-T66 (V3.7) • VCCI—CISPR 32:2016 Class A Export Control Information Table 5 lists the ECCN, HTS, and CCATS numbers for a CSG1000 series appliance. Table 5: ECCN, HTS, and CCATS Numbers ECCN CCATS Versa Use of...

  • Page 11: Front And Rear Panel Components

    Front Panel The front panel of a CSG1000 series appliance has a power button, a reset button, and six status LEDs located in two rows, as shown in Figure 1. (Note that the CSG1300 series and CSG1500 series appliances are physically identical.)
  • Page 12 • Blinking white—LTE module is connecting. Power Button The Power button on the front panel of a CSG1000 series appliance turns the power on and off. To turn the power on, press and immediately release the Power button when the appliance is off.
  • Page 13 SIM Card Slots The front panel of a CSG1000 series appliance has two nano-SIM card slots. If you subscribe to a single wireless service, install the LTE device in the SIM 1 slot. If you subscribe to dual wireless services, use both the SIM 1 and SIM 2 slots to activate the LTE devices.

  • Page 14: Rear Panel

    5. Power off the appliance. Rear Panel The rear panel of a CSG1000 series appliance has the following components, as shown in Figure 2: • Two power supply units, internal 920 W, that provide 1+1 redundancy, hot-swappable, with back-to-front airflow and AC to DC •...

  • Page 15: Additional Information

    • One ground contact Figure 2: Rear Panel of a CSG1000 Series Appliance Additional Information Factory Default Settings for Branch Devices Network Interface Cards The Cloud Services Gateway (CSG) 1000 series appliances offer field-based configurability using the network interface card (NIC) slot. This article describes the CSG1000 appliance NICs.

  • Page 16: Nic Specifications

    Ethernet ports (1-GB copper Gigabit Ethernet port and 1-GB copper Gigabit Ethernet with PoE port.) Figure 1: CSG1500 RJ-45 Connectors for 1-GB Copper Gigabit Ethernet Ports NIC Specifications Table 2 lists the NIC specifications for a CSG1000 series chassis. Table 2: CSG1000 Series NIC Specifications https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_…...
  • Page 17 0.44 lb (200 gm) • 4GF 0.33 lb (150 gm) Package Specifications Package height 3.25" (82.55 mm) Package width 6" (152.4 mm) Package depth 9" (228.6 mm) https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 18 LTE dongle. With two internal modems, you can deploy up to four simultaneous LTE WAN connections. All CSG1000 series appliances support 4G LTE-A, and you can use the appliances as the primary or backup WAN access link for branch and remote sites. Enterprise customers can deploy CSG1000 series appliances with up to two built-in and two additional attached LTE links simultaneously, providing unmatched resiliency and flexibility for wireless WAN access from the branch.
  • Page 19 KDDI, NTT Docomo, Softbank, Telstra Cellular, Verizon, Vodafone, Location BeiDou, Galileo, GLONASS, standalone, SUPL BeiDou, Galileo, GLONASS, standalone, SUPL solution 1.0 and 2.0, Xtra 1.0 and 2.0, Xtra https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 20 (AP) module to deliver enterprise-grade WLAN connectivity to the branch. The CSG1000 series appliance has two internal wireless slots that can be configured for single LTE or dual LTE. The CSG1000 series appliances have one AP module. It is a dual-band module that simultaneously supports 2.4 GHz, for longer distances, and 5 GHz, for faster throughput.

  • Page 21: Interface Numbering

    Interface Numbering Figure 1 shows the mapping of the Ethernet ports to virtual network interface (VNI) numbering for the CSG1000 series appliance. Note that the CSG1300 and CSG1500 chassis are identical. Figure 1: CSG1500 Port-to-VNI Mapping Figure 2 shows port-to-VNI mapping for the CSG1300 and CSG1500 appliances. Note that the CSG1300 and CSG1500 chassis are identical.

  • Page 22: Airflow Requirements

    When planning your site for installing a CSG1000 series appliance in a 19-inch rack, keep in mind that the front side of the rack is the cool area, and the rear side is where hot air exits from the fan. Ensure that there is space on the rear side of the appliance to allow air to exit from the fan.
  • Page 23 CSG1500 series appliances. vni-0/12 vni-0/2 through vni-0/3 vni-0/15 Type Manufacturer Part Number Transceiver Description Short 10GBASE-SR/SW 300-m, multimode reach Finisar FTLX8574D3BCL datacom SFP+ optical transceiver (SR) https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.

  • Page 24: Connection Recommendations

    The following switches have been tested with a 1-Gigabit Ethernet link connection to CSG1300 series appliances: • Cisco Nexus 3048T • Dell S3048 and S4128F • Juniper EX2200 Connection Recommendations The following are recommendations for connecting at 1-Gigabit Ethernet speeds: https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.

  • Page 25: Compatibility Issues

    • Link flap issues may occur if the remote device is an older Cisco Nexus 3064 switch (2012). • After you reboot CSG1000 series appliances, the link error "DCX-NO Ack in 100 PDUs" may occur on Cisco Nexus switches. As a workaround, issue the shutdown command followed by a no shutdown on the Cisco switch interface that is used for link detection.

  • Page 26: Federal Communication Commission Interference Statement

    • Install the CSG1000 series appliance in compliance with the following local, national, and international electrical codes: • United States—National Fire Protection Association (NFPA 70), United States National Electrical Code. • Other countries—International Electromechanical Commission (IEC) 60364, Part 1 through Part 7.

  • Page 27: Site Preparation Guidelines

    10% to 85%, non-condensing. Rack Requirements You can mount a CSG1300 or CSG1500 series appliance in a 19-inch four-post rack using slide rails. Table 1 lists the https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 28 When placing a CSG1000 series appliance on a desk, ensure that there is space on the rear side of the appliance to allow air to exit from the fan. Also ensure that the vents on the side of the unit are never blocked, to allow hot air to flow out of the appliance.
  • Page 29 Hardware. Packing List for the CSG1000 Series Appliance The cardboard carton in which a CSG1000 series appliance is shipped contains a packing list. Check the packing list against the parts that you receive in the shipping carton. Table 1 lists the parts shipped with a CSG1300 or CSG1500 appliance.
  • Page 30 Do not overtighten the screws. 4. Secure the appliance to the rack using the four M6 screws that are shipped with the appliance. Do not overtighten the screws. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 31 Step 1: Connect Earth Ground to a CSG1000 Series Appliance To ensure proper operation of a CSG1000 series appliance and to meet safety and electromagnetic interference (EMI) requirements, you must connect the appliance to earth ground before you connect power to the appliance.
  • Page 32 Figure 2: Connect AC Power to a CSG1000 Series Appliance Step 3: Check that the CSG1000 Series Appliance Is Powered On To check the CSG1000 series appliance is powered on, check that the Power LED is on. When operating normally, the power LED is green.
  • Page 33 CSG1000 series appliances are equipped with an RJ45 serial console port. To connect to the console port, use the RJ45-to-USB serial console supplied with the appliance: 1. Plug the RJ45 end of the console cable into the console port located on the rear panel of the CSG1000 series appliance.
  • Page 34 2. In the Category navigation pane, click Session, and then in the Connection Type menu, click Serial. 3. In the Category navigation pane, click Connection > Serial. The Options Controlling Local Serial Lines page displays. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 35 4. In the Serial Line To Connect To field, enter the COM port that your device is connected to. The default COM port is COM1. 5. In the Configure the Serial Line section, enter the following information. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 36 In the Speed (Baud) field, enter the digital transmission speed. For CSG1000 series appliances, the speed must be 115200. b. In the Data bits field, enter the number of data bits used for each character. The recommended value is 8.
  • Page 37 7. Click Save. 8. To open the session, click Open. 9. Log in to the appliance CLI with the username "admin" and the password "versa123". https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_1000_Series/Complete_CSG1000_Series_Hardware_… Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 38 Updated: Fri, 03 Jan 2025 15:22:49 GMT Copyright © 2024, Versa Networks, Inc.
