Install a CSG5000 Series Appliance
This article provides instructions about how to unpack a Cloud Services Gateway (CSG) 5000 series appliance and how
to install it. You can mount a CSG5000 series appliance directly in a 19-inch rack, or you can install a slide rail in a
19-inch rack and then mount the CSG5000 series appliance on the slide rail. The minimum depth of the slide rail is 698
mm (27.48 inches), and the maximum depth is 998 mm (39.39 inches).
Unpack a CSG5000 Series Appliance
The CSG5000 series appliance is packed in a plastic bag, and it is shipped in a cardboard carton, secured with foam
packing material. The carton also contains an accessory box. It is recommended that you unpack the appliance only
when you are ready to install it.
To unpack a CSG5000 series appliance:
1. Open the top flaps of the cardboard carton.
2. Remove from the box the foam packing material holding the appliance and the accessories in place. See Figure 1.
3. Remove the accessory box and the appliance from the foam packing material.
4. Remove the accessories from the accessories box.
5. Verify the components against the packing list that is included in the box.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_5000_Series/Planning_and_Installation/03_Install_a_C...
Figure 1: Unpack a CSG5000 Appliance
Updated: Fri, 21 Mar 2025 17:06:39 GMT
Copyright © 2024, Versa Networks, Inc.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Versa Networks CSG5000 Series
Summary of Contents for Versa Networks CSG5000 Series
- Page 1 This article provides instructions about how to unpack a Cloud Services Gateway (CSG) 5000 series appliance and how to install it. You can mount a CSG5000 series appliance directly in a 19-inch rack, or you can install a slide rail in a 19-inch rack and then mount the CSG5000 series appliance on the slide rail.
- Page 2 Hardware. Packing List for a CSG5000 Series Appliance The cardboard carton in which a CSG5000 series appliance is shipped contains a packing list. Check the packing list against the parts that you receive in the shipping carton. Table 1 lists the parts shipped with a CSG5000 series appliance.
- Page 3 Mount a CSG5000 Series Appliance on a Slide Rail You can install a slide rail in a 19-inch rack and then install a CSG5000 series appliance on the slide rail. You can purchase an optional slide rail kit when you purchase a CSG5000 series appliance.
- Page 4 2. Use the M4 screws from accessory box to mount the inner rail to chassis. 3. Attach the cabinet (outer) member to the rail. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_5000_Series/Planning_and_Installation/03_Install_a_C… Updated: Fri, 21 Mar 2025 17:06:39 GMT Copyright © 2024, Versa Networks, Inc.
- Page 5 4. Mount the chassis into the cabinet. Align and push the inner rails into the extended middle rails. After the chassis is mounted in the middle rails, hold down the locking lever to push the chassis all the way into the rack. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_5000_Series/Planning_and_Installation/03_Install_a_C… Updated: Fri, 21 Mar 2025 17:06:39 GMT Copyright © 2024, Versa Networks, Inc.
