CSG700 Series Hardware Guide
At a Glance
The Versa Cloud Services Gateway (CSG) 700 series appliances deliver highly secure site-to-site data connectivity to
small- and medium-sized businesses and to home offices.
These appliances provide the following features:
• Unified board design that supports different CPUs and memory sizes
• Up to 10 Ethernet ports including:
• Four built-in 1 Gigabit per second (GB) Ethernet over copper (EoC) ports
• Two 1-GB EoC or SFP ports, available through separate interfaces
• Four 1-GB EoC with Power over Ethernet (PoE) ports, available if a Network Interface Card (NIC) module is
installed
• MDI and MDIX autoswitchable EoC ports
• Two USB ports for plugging in external LTE or WiFi modems
• PoE source support on four Ethernet ports
• Two built-in wireless slots
• GPS connector for geographical location
• External AC power supply
• Kensington security lock to physically lock down the appliance
• Fanless design
• Fixed chassis with no field-replaceable parts
• Desktop mount or rack-mountable in a 19" rack
CSG700 Appliance Models
The CSG700 appliances are available in the following models:
• CSG730
• CSG750
• CSG770
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui...
Updated: Tue, 18 Oct 2022 06:10:27 GMT
Copyright © 2021, Versa Networks, Inc.
1
Advertisement
Table of Contents
Related Manuals for Versa Networks CSG700 Series
Summary of Contents for Versa Networks CSG700 Series
- Page 1 • Desktop mount or rack-mountable in a 19” rack CSG700 Appliance Models The CSG700 appliances are available in the following models: • CSG730 • CSG750 • CSG770 https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
-
Page 2: Chassis Views
Figure 1: Front Panel of the CSG730 Appliance Figure 2: Rear Panel of the CSG730 Appliance CSG700 Series Appliance Specifications A CSG700 series appliance chassis is made of aluminum for optimal heat dissipation. This article lists the chassis and https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT... -
Page 3: Chassis Specifications
CSG700 series appliance. It also lists certifications and export control classification numbers (ECCNs) for the appliance. Chassis Specifications Table 1 lists the chassis specifications for a CSG700 series chassis. Table 1: CSG700 Series Chassis Specifications... - Page 4 –20 to 70°C (–4 to 158°F) at sea level Humidity 10 to 85% relative humidity CSG700 Series Appliance SKUs CSG700 series SKUs have the following format: model – xxx – yyy model indicates the CSG700 appliance model number. It can be one of the following: • CSG730 https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui…...
-
Page 5: Regulatory Compliance
• 4GP-120W • 4DS • 4GF • 8GE • 1VA Regulatory Compliance Table 2 lists the regulatory compliance specifications for a CSG700 series chassis. Table 2: CSG700 Series Regulatory Compliance Specifications Item Specification CB (IEC/EN60950-1 and IEC/EN 62368-1) Safety UL (CSA 22.2 No 62368-1 and UL62368-1) TPM 2.0... - Page 6 Certifications A CSG700 series appliance complies with the product safety and regulatory compliance listed in Table 3. For the latest list of certifications and regulatory compliance for various regions, contact Versa Networks customer support. Table 3: CSG700 Series Certifications Region...
-
Page 7: Front And Rear Panel Components
8542310001 G156910L1 series appliance Front and Rear Panel Components This article describes the front and rear panel components of a CSG700 series appliance. For the exact location of these components on the appliance, see At a Glance. Front Panel The front panel of a CSG700 series appliance has two status LEDs and two SIM card slots. - Page 8 SIM Card Slots The front panel of a CSG700 series appliance has two nano-SIM card slots. If you subscribe to a single wireless service, use the SIM 1 slot to install the LTE device. If you are subscribing to dual wireless service, use both the SIM 1 and SIM 2 slots to activate the LTE devices.
- Page 9 • Solid blue—Bluetooth service is started and advertised. Power Button The Power button on the rear panel of a CSG700 series appliance turns the power on and off. To turn the power on, press and immediately release the Power button when the appliance is off.
- Page 10 Reset Button The Reset button on the rear panel of a CSG700 series appliance resets the appliance. The reset functionality depends on the number of times you press the butter within a span of 30 seconds, as described in Table 3. In between each press on the reset button, you must pause for a second to register the key presses.
-
Page 11: Kensington Security Lock
Running, [-] process 5775 5. Power off the appliance. Kensington Security Lock The Kensington security lock on he rear panel of a CSG700 series appliance is a small metal-enforced hole for attaching a Kensington lock to secure the appliance. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui…... -
Page 12: Gps Input
GPS Input The GPS antenna input on the rear panel of a CSG700 series appliance allows you to connect an external GPS antenna. When you connect a GPS antenna to the appliance, it automatically identifies the geographical location of the unit, allowing you to detect any theft or movement of the appliance. - Page 13 Supports fiber Gigabit Ethernet for1000BASE-SX and • NIC-4GF 4-port Gigabit Ethernet SFP 1000BASE-LX. The four Ethernet ports on the NIC are labeled Port 6 through Port 9. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
-
Page 14: Nic Specifications
Figure 2 shows the four RJ-45 connectors/SFP slots for the 1 GbE /SFP combination port. Figure 2: RJ-45 Connectors or SFP Slots for 1 GbE /SFP Combination Port NIC Specifications Table 3 lists the NIC specifications for a CSG700 series chassis. Table 3: CSG700 Series NIC Specifications Item... - Page 15 10 to 85% relative humidity Altitude Maximum 3000 m (10000 ft) Noise level 0 dBm Storage Conditions Temperature –20 to 70°C (–4 to 158°F) at sea level https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 16 10 to 85% relative humidity LTE Modem Module The CSG700 series LTE modem module is a high-performance Cat-6 LTE Advanced modem that provides up to 300 Mbps download speeds and 50 Mbps upload speeds. The LTE modem supports multiple carriers, and it has been certified by major global carriers.
- Page 17 Versa Director does not restart the LTE modem. WiFi Access Point Module You can order the CSG700 series appliance with the WiFi access point (AP) module. If you do so, the WiFi AP module comes preinstalled in the SIM 2 slot on the front of the appliance.
-
Page 18: Interface Numbering
It also has built-in spectrum analyzer capabilities to detect rogue frequencies in an environment, if desired. Interface Numbering Figure 1 shows the mapping of the Ethernet ports to Virtual Network Interface (VNI) numbering for the CSG700 series appliances. Figure 3: Port-to-VNI Mapping Power Supply and Airflow This article describes the AC power supply and airflow requirements for CSG700 appliances. -
Page 19: Airflow Requirements
When placing a CSG700 series appliance on a desk, ensure that the vents on the top of the unit are never blocked, to allow hot air to flow out of the appliance. Covering the vents prevents heat from dissipating out of the appliance, which will cause the chassis to overheat and then shut down. -
Page 20: Connection Recommendations
Transceiver Description reach (LR) industrial operating temperature Compatible Remote Switches The following switches have been tested with a 1-Gigabit Ethernet link connection to CSG700 series appliances: • Cisco Nexus 3048T • Dell S3048 and S4128F • Juniper EX2200 Connection Recommendations The following are recommendations for connecting at 1-Gigabit Ethernet speeds: •... -
Page 21: Compatibility Issues
• BASE-T SFP modules for Denverton-based boards are not supported. Installation Guidelines This article provides general safety standards and warnings relating to installing or connecting a CSG700 series appliance. General Safety Guidelines Caution: Before installing or removing a CSG700 series appliance, ensure that the appliance chassis is electrically connected to ground. - Page 22 1. L’appareil ne doit pas produire de brouillage. 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage estsusceptible d’en https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 23 To satisfy RF exposure requirements, a separation distance of 20 cm or more must be maintained between the antenna of CSG700 series device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended.
-
Page 24: Site Preparation Guidelines
เครื ่ อ งโทรคมนาคมและอุ ป กรณ์ น ี ้ มี ค วามสอดคลอ้ งตามมาตรฐานหรื อ ขอ้ กํ า หนดทางเทคนิ ค ของ กสทช. QR Code Prepare the Site for Installation To prepare your site for installing a CSG700 series appliance, follow the guidelines and requirements listed in this article. Site Preparation Guidelines •... -
Page 25: Rack Requirements
When placing a CSG700 series appliance on a desk, ensure that the vents on the top of the unit are never blocked, to allow hot air to flow out of the appliance. Covering the vents prevents heat from dissipating out of the appliance, which will cause the chassis to overheat and then shut down. - Page 26 3. Remove the accessory box and the appliance from the foam packing material. 4. Remove the accessories from the accessories box. 5. Verify the components against the packing list that is included in the box. Figure 1: Unpack a CSG700 Series Appliance https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT...
- Page 27 How To Return Hardware. Packing List for a CSG700 Series Appliance The cardboard carton in which a CSG700 series appliance is shipped contains a packing list. Check the packing list against the parts that you receive in the shipping carton. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui…...
- Page 28 Screws for rack mounting 4 (size M6) Mount a CSG700 Series Appliance in a Rack You can mount a CSG700 series appliance in a 19-inch rack. To mount the appliance, ensure that you have the following tools: • Number 2 Phillips (+) screwdriver •...
- Page 29 4. Attach the two mounting ears to each side of the appliance chassis using a minimum of six M4 screws that are shipped with the appliance. Do not overtighten the screws. Figure 3: Attach the Mounting Ears to a CSG700 Series Appliance 5. Grasp both sides of the appliance chassis, making sure that the front of the chassis is facing you.
- Page 30 Figure 5: Secure the Mounting Ears to the Rack Connect a CSG700 Series Appliance This article describes how to connect a CSG700 series appliance to an AC power source and to a management console. Versa recommends an uninterruptible power strategy that prevents power interruptions. A UPS can isolate unpredictable power outages or blackouts, brownouts, lightning, power surges, or spikes.
- Page 31 2. Plug one end of the AC power cord into the AC power adapter. 3. Plug the other end of the AC power cord into an AC power source outlet. 4. Plug the DC end of the power supply unit into the back of the CSG700 series appliance. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui…...
- Page 32 Series Appliance CSG700 series appliances are equipped with an RJ45 serial console port and an RJ45 console cable that you use to connect the console port. To communicate with the appliance, you must have a terminal emulation program, such as PuTTY, running on your system.
- Page 33 3. In the Category navigation pane, click Connection > Serial. The Options Controlling Local Serial Lines page displays. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 34 4. In the Serial Line To Connect To field, enter the COM port that your device is connected to. The default COM port is COM1. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 35 5. In the Configure the Serial Line section, enter the following information. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 36 In the Speed (Baud) field, enter the digital transmission speed. For CSG700 series appliances, the speed must be 115200. b. In the Data bits field, enter the number of data bits used for each character. The recommended value is 8.
- Page 37 7. Click Save. 8. To open the session, click Open. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 38 9. Log in to the appliance CLI with the username "admin" and the password "versa123". https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_700_Series/Complete_CSG700_Series_Hardware_Gui… Updated: Tue, 18 Oct 2022 06:10:27 GMT Copyright © 2021, Versa Networks, Inc.
- Page 39 To connect a CSG700 series appliance to a management console: 1. Plug one end of the console cable into the console port located on the rear panel of the CSG700 series appliance. 2. Plug the other end of the cable into the console server or into a management console.
