CSG3000 Series Hardware Guide
At a Glance
The Versa Cloud Services Gateway (CSG) 3000 series appliances deliver carrier-grade reliability, high performance,
line-rate switching, and high compute capacity for enterprise-grade routing, SD-WAN, next-generation security, and
uCPE scenarios. They are designed for deployment in large enterprise branches, campus sites, and data centers that
require advanced secure SD-WAN along with comprehensive advanced application and cloud-intelligent SD-WAN
services on premises.
The CSG3000 appliances run Versa Operating System
integrated security, including NGFW, UTM, ZTNA, application intelligence, and application policy-based forwarding
along with line-rate Layer 2/Layer 3 switching, scalable advanced routing, multitenancy, and big-data–based analytics.
The CSG3000 series appliances come with LAN and WAN ports. The ports provide support for Ethernet and non-
Ethernet (ADSL2+/VDSL2 and T1/E1) interfaces and for built-in wireless, including 4G, LTE, LTE-advanced-pro, and
sub-6 5G.
Copper LAN ports are multi-rate Gigabit Ethernet ports with built-in PoE++ (Power over Ethernet) capacities. The
CSG3000 series appliances high-speed fiber uplink and downlink ports, including 25/10 Gigabit Ethernet and 100
Gigabit Ethernet, provide fast connectivity to other network elements in the LAN environment.
CSG3000 series appliances are designed with built-in high compute capacity, including multiple core x86 CPUs,
memory, and storage, to help in hosting third-party virtual machines (VMs), thus eliminating the need for separate
hardware platforms and simplifying network deployments.
CSG3000 appliances provide the following features:
• Management Ethernet ports
◦ One RJ45 1-Gigabit Ethernet port for management
◦ One RJ45 serial console port for management
• Two RJ45 10-Gigabit Ethernet ports for WAN Interfaces
• Two SFP+ 10-Gigabit Ethernet ports for WAN Interfaces
• Eight RJ45 10/5/2.5/1-Gigabit Ethernet PoE++ (60-W) ports for LAN Interfaces
• Sixteen RJ45 2.5/1-Gigabit Ethernet PoE (30-W) ports for LAN Interfaces
• Four SFP+ 28 25/10-Gigabit Ethernet ports for LAN Interfaces
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C...
TM
TM
(VOS
) software, which provides fully comprehensive
Updated: Fri, 03 Jan 2025 22:34:23 GMT
Copyright © 2024, Versa Networks, Inc.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CSG3000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Versa Networks CSG3000 Series

Summary of Contents for Versa Networks CSG3000 Series

  • Page 1 Layer 2/Layer 3 switching, scalable advanced routing, multitenancy, and big-data–based analytics. The CSG3000 series appliances come with LAN and WAN ports. The ports provide support for Ethernet and non- Ethernet (ADSL2+/VDSL2 and T1/E1) interfaces and for built-in wireless, including 4G, LTE, LTE-advanced-pro, and sub-6 5G.

  • Page 2: Chassis Views

    LAN interfaces for WAN connections. CSG3000 Series Appliance Models The CSG3000 series appliances are available in the following models: • CSG3300—Powerful appliance for deployment in large enterprise branch or campus sites for networks that require advanced switching and routing, secure SD-WAN, and comprehensive application and cloud-intelligent SD-WAN services on-premises.

  • Page 3: Chassis Specifications

    1G/10G SFP/SFP+ Ethernet ports for WAN 10G/5G/2.5G/1G Power over Ethernet (PoE) (60-W) ports for LAN 2.5G/1G PoE (30-W) ports for LAN 25/10 Gigabit Ethernet SFP28 ports for LAN https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 4 Maximum power consumption (with PoE) 383 W Typical power consumption (without PoE) Platinum (80 Plus) or better Power supply efficiency rating Chassis Physical Specifications 1.73" (44 mm) Chassis height https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 5 Front-to-back cooling with FRU fans with built-in 3+1 System cooling redundancy Idle: 52.3 dBA Acoustic noise level Full load: 66.8 dBA Storage Conditions –20°C to 70°C (–4°F to 158°F) at sea level Temperature https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 6 16 GB (for diagnostics) Field-replaceable 1 + 1 redundant and hot-swappable Power supply AC input Hardware offload engines for crypto and compression/ Specialized hardware offload decompression https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 7 Humidity 15% to 85% non-condensing Front-to-back cooling with FRU fans with built-in 3+1 System cooling redundancy Idle: 52.3 dBA Acoustic noise level Full load: 66.8 dBA https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.

  • Page 8: Regulatory Compliance

    • CSG3500 In addition, CSG3000 series appliances have NICs. For more information, see Network Interface Cards. Regulatory Compliance Table 3 lists the regulatory compliance specifications for the CSG3000 series appliance. Table 3: CSG3000 Series Regulatory Compliance Specifications Item Specification 2014/35/EU Safety •...
  • Page 9 • FCC 47 CFR Part 15, Subpart B, Class A • ANSI C63.4-2014 Japan VCCI—CISPR 32:2016 Class A Export Control Information Table 5 lists the ECCN, HTS, and CCATS numbers for a CSG3000 series appliance. Table 5: ECCN, HTS, and CCATS Numbers ECCN CCATS Item...

  • Page 10: Front And Rear Panel Components

    Glance. Front Panel The front panel of a CSG3000 series appliance has a power button, a reset button, and six status LEDs located in two rows, as shown in Figure 1. Figure 1: Front Panel of a CSG3000 Series Appliance LEDs Status LEDs provide the operational status of the appliance and of the WLAN and LTE connections.

  • Page 11: Power Button

    • Blinking white—LTE module is connecting. Power Button Pressing the power on/standby button on the front panel of a CSG3000 series appliance turns on the power. To turn off the power, use one of the following methods: • Press and release the power on/standby button. This method initiates a controlled shutdown of applications and the operating system before the appliance enters standby mode.

  • Page 12: Reset Button

    Reset Button The Reset button on the front panel of a CSG3000 series appliance resets the appliance to the factory-default settings. The reset functionality depends on the number of times you press the button within a span of 30 seconds, as described in Table 3.

  • Page 13: Rear Panel

    # sudo poweroff Rear Panel The rear panel of a CSG3000 series appliance has the following components, as shown in Figure 2: • Two hot-swappable power supply units (PSUs), each about 1000 W, that provide 1+1 redundancy with front-to-back airflow •...

  • Page 14: Interface Numbering

    Figure 2: Rear Panel of a CSG3000 Series Appliance Interface Numbering Figure 1 shows the mapping of the Ethernet ports to virtual network interface (VNI) numbering for the CSG3000 series appliance. Note that the CSG3300 and CSG3500 chassis are identical.
  • Page 15 5G maximum DL—5 Gbps speeds UL—650 Mbps LTE maximum DL—2 Gbps speeds UL—200 Mbps Antenna 4x4 MIMO LTE carrier DL—Up to 7CC aggregation UL—Up to 2CC https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.

  • Page 16: Network Interface Card

    Up to 26 dBm You can order CSG3000 series appliances with one or two optional LTE modem modules. The LTE modem modules have one SIM slot. For CSG3000 with one LTE module, you insert the SIM card into the SIM1 slot, which is on the front of the appliance.

  • Page 17: Nic Specifications

    To supplement the eight built-in PoE+ ports, you can add a 4-port copper Gigabit Ethernet PoE+ NIC, to provide a total of twelve PoE+ ports. CSG3000 series appliances and the optional 4-port PoE+ NIC support the 802.3af and 802.3at standards. Note that an external power supply unit is required for the optional 4-port PoE+ NIC.
  • Page 18 Altitude Maximum 3000 m (10000 ft) Noise level 0 dBm Temperature –20 to 70°C (–4 to 158°F) at sea level Humidity 10 to 85% relative humidity https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.

  • Page 19: Ac Power Supply

    When placing a CSG3000 series appliance on a desk, ensure that there is space on the rear side of the unit to allow air to exit from the fan. Also ensure that the vents on the side of the unit are never blocked, to allow hot air to flow out of the appliance.
  • Page 20 Step 1: Connect Earth Ground to a CSG3000 Series Appliance 1. To ensure proper operation of a CSG3000 series appliance and to meet safety and electromagnetic interference (EMI) requirements, you must connect the appliance to earth ground before you connect power to the appliance.
  • Page 21 Figure 2: Connect AC Power to a CSG3000 Series Appliance< Step 3: Check that the CSG3000 Series Appliance Is Powered On To check the CSG3000 series appliance is powered on, check that the Power LED is on. When operating normally, the power LED is green.
  • Page 22 • Parity—None • Flow control—None To connect a management console to a CSG3000 series appliance: 1. Open the PuTTY application. The PuTTY configuration window displays. 2. In the Category navigation pane, click Session, and then in the Connection Type menu, click Serial.
  • Page 23 4. In the Serial Line To Connect To field, enter the COM port that your device is connected to. The default COM port is COM1. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 24 In the Data bits field, enter the number of data bits used for each character. The recommended value is 8. c. In the Stop bits field, enter the number of bits to be sent at the end of every character. The recommended https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 25 6. Optionally, in the Category navigation pane, click Session, and then in the Saved Sessions field, enter a name to save the session settings. 7. Click Save. 8. To open the session, click Open. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_3000_Series/Complete_CSG3000_Hardware_Guide/C… Updated: Fri, 03 Jan 2025 22:34:23 GMT Copyright © 2024, Versa Networks, Inc.
  • Page 26 Step 5: Connect a CSG3000 Series Appliance to a Management Console You can configure and manage a CSG3000 series appliance using a management console. To connect a CSG3000 series appliance to a management console, use the console port on the appliance.

  • Page 27: General Safety Guidelines

    Gateway (CSG) 3000 series appliance. General Safety Guidelines Caution: Before installing or removing a CSG3000 series appliance, ensure that the appliance chassis is electrically connected to ground. When you are installing or removing an appliance, ensure that you wear an ESD grounding wrist strap.

  • Page 28: Federal Communication Commission Interference Statement

    This article provides instructions about how to unpack a Cloud Services Gateway (CSG) 3000 series appliance and how to install it. You can mount a CSG3000 series appliance directly in a 19-inch rack, or you can install a slide rail in a 19-inch rack and then mount the CSG3000 series appliance on the slide rail.
  • Page 29 Unpack a CSG3000 Series Appliance The CSG3000 series appliance is packed in a plastic bag, and it is shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box. It is recommended that you unpack the appliance only when you are ready to install it.
  • Page 30 Mount a CSG3000 Series Appliance on a Slide Rail You can install a slide rail in a 19-inch rack and then install a CSG3000 series appliance on the slide rail. You can purchase an optional slide rail kit when you purchase a CSG3000 appliance.

  • Page 31: Site Preparation Guidelines

    Rack Requirements You can mount a CSG3300 or CSG3500 series appliance in a 19-inch four-post rack using slide rails. Table 1 lists the rack requirements. Table 1: Rack Requirements for a CSG3000 Series Appliance Requirement Guidelines Use a 19-inch four-post rack that has bracket holes spaced at 1 U (1.75 in. or 4.45 cm) increments, Rack type and that has panels strong enough to support the weight of the appliance.
  • Page 32 When placing a CSG3000 series appliance on a desk, ensure that there is space on the rear side of the unit to allow air to exit from the fan. Also ensure that the vents on the side of the unit are never blocked, to allow hot air to flow out of the appliance.
