Emmerson Twin & Full
Hardware included in Headboard carton to attach headboard.
B
E
I
Φ8*30
Φ8
Φ8
MM
MM
MM
4PCS
1PC
4PCS
1
Step#1
Attach Headboard to Arms using Wrench (I), Bolt (B) and Washer (E) (factory installed).
Step#2
Install Connecting plate (U) to connect Arms and Headboard , using Wrench (I), Bolt (B) and
Washer (E) (factory installed).
CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning：do not move bed after final assembly as it may result in damages to floor and/or bed.~
Page 1 Emmerson & page 1 Emmerson backless (printed back-to-back)
U
Connecting
plate
2PCS
*Bolt B and Washer E
are factory installed*
Frame
Assembly
2
