- Page 1 ASSEMBLY INSTRUCTIONS L I V I N G S P A C E S ELSIE QUEEN UPHOLSTERED SLEIGH BED W/ STORAGE SKU:347619 COMPONENT'S SKU QUANTITY (Cartons) 347626 347612 347613 15 min...
- Page 2 PART PART LIST Number IMAGE DECRIPTION COMPONENT'S SKU Head Board 347626-01 Headboard right leg 347626-02 347626 Headboard left leg 347626-03 Stretcher rail 347626-04 347612-01 Foot Board 1 Set 347612-02 Slat 347612 347612-03 Middle Support Bar Support With Leveler 347612-04 347612-01 Storage Side Rail 347613 347612-02...
-
Page 3: Cleaning Instructions
Hardware Number Hardware Number PART IMAGE DECRIPTION COMPONENT'S SKU Bolts 5/16" *45mm 347626-A01 Spring Washer 5/16" Dia 347626-A02 347626 Flat Washer 5/16" * Dia 347626-A03 Allen key 347626-A04 347612 Screw #8* 30mm 347612-A01 347613-A01 Bolts 5/16" *25mm 347613-A02 Spring Washer 5/16" Dia 347613-A03 Flat Washer 5/16"... - Page 4 1=8pcs STEP 1 2=8pcs 3=8pcs 1=2pcs STEP 2 2=2pcs 3=2pcs NOTE: ASSEMBLE UNIT ON A SOFT SURFACE. DO NOT TIGHTEN BOLTS UNTIL ALL PARTS AND HARDWARE OF THE UNIT ARE ASSEMBLED. SPIRIT LEVELER NOT INCLUDED BUT NEEDED TO EVEN THE FLOOR.
- Page 5 10=3pcs STEP 3 11=3pcs 12=3pcs STEP 4 6=4pcs 7=4pcs 8=4pcs...
- Page 6 STEP 5 5=6pcs STEP 6 That's it ! You've finished assembling your item. Thank you!
