- Page 1 ASSEMBLY INSTRUCTIONS L I V I N G S P A C E S SKU:347645 ELSIE CALIFORNIA KING UPHOLSTERED SLEIGH BED COMPONENT'S SKU QUANTITY (Cartons) 347652 347627 347654 15 min...
- Page 2 PART PART LIST Number IMAGE DECRIPTION COMPONENT'S SKU Head Board 347652-01 Headboard right leg 347652-02 347652 Headboard left leg 347652-03 Stretcher rail 347652-04 347627-01 Foot Board 1 Set 347627-02 Slat 347627 347627-03 Middle Support Bar Support With Leveler 347627-04 347654-01 Side Rail 347654 347654-02...
- Page 3 Hardware Number Hardware Number PART IMAGE DECRIPTION COMPONENT'S SKU Bolts 5/16" *45mm 347652-A01 Spring Washer 5/16" Dia 347652-A02 347652 Flat Washer 5/16" * Dia 347652-A03 Allen key 347652-A04 347627 Screw #8* 30mm 347627-A01 347654-A01 Bolts 5/16" *25mm 347654-A02 Spring Washer 5/16" Dia 347654-A03 Flat Washer 5/16"...
- Page 4 1=8pcs STEP 1 2=8pcs 3=8pcs 1=2pcs STEP 2 2=2pcs 3=2pcs NOTE: ASSEMBLE UNIT ON A SOFT SURFACE. DO NOT TIGHTEN BOLTS UNTIL ALL PARTS AND HARDWARE OF THE UNIT ARE ASSEMBLED. SPIRIT LEVELER NOT INCLUDED BUT NEEDED TO EVEN THE FLOOR.
- Page 5 6=8pcs STEP 3 7=8pcs 8=8pcs STEP 4...
- Page 6 5=6pcs STEP 5 10=8pcs STEP 6 That's it ! You've finished assembling your item. Thank you!
