Overview
Power Supply
NXA-PAC-3200W-PI
NXA-PAC-3200W-PI
NXA-PDC-3200W-PI
NXA-PDC-3200W-PI
NXA-PDC-3200W-PI
Use dust covers (NXA-ACC-QDD-DC) for unused ports. This protects the connectors and helps divert airflow
for thermal dispensation.
Cisco Nexus 9364D-GX2A NX-OS Mode Switch Hardware Installation Guide
4
Fan MACSec Enabled
NXA-SF AN-160CFM2PI 8 ports
NXA-SF AN-160CFM2PI 0 ports
NXA-SF AN-160CFM2PI 16 ports
NXA-SF AN-160CFM2PI 8 ports
NXA-SF AN-160CFM2PI 0 ports
Ambient Optics Power (W)
Temeprature Limit Consumption
40 °C Odd numbered
ports: 8 ports with
Max. 20W per port
Remaining ports
with Max. 12W per
port
Even numbered
ports: Max. 12W per
port
40 °C Odd numbered
ports: 16 ports with
Max. 20W per port
Remaining ports
with Max. 12W per
port
Even numbered
ports: Max. 12W per
port
40 °C Ports 1-64: Max.
12W per port
40 °C Odd numbered
ports: 8 ports with
Max. 20W per port
Remaining ports
with Max. 12W per
port
Even numbered
ports: Max. 12W per
port
40 °C Odd numbered
ports: 16 ports with
Max. 20W per port
Remaining ports
with Max. 12W per
port
Even numbered
ports: Max. 12W per
port
