WUNDER BABY02 User Manual

Professional electronic baby scale

User manual (16 pages)

Quick Links

Download this manual

USER MANUAL

1. GENERAL RULES ....................................................................................................................................

2. SAFETY ....................................................................................................................................................

3. INDICATOR .............................................................................................................................................

4. USABILITY ...............................................................................................................................................

5. ISTRUCTION FOR USE ...........................................................................................................................

6. PRINTER FUNCTIONS ............................................................................................................................ 13

7. SETTING SETUP ..................................................................................................................................... 14

8. ERROR MESSAGES ................................................................................................................................. 15

9. MAINTENANCE AND ASSISTANCE ....................................................................................................... 15

10. SCRAPPING AND WASTE DISPOSAL .................................................................................................. 16

11. WARRANTY .......................................................................................................................................... 17

12. TECHNICAL SPECIFICATION ............................................................................................................... 17

13. INSTALLATION ..................................................................................................................................... 18

14. CONFORMITY ...................................................................................................................................... 21

15. IDENTIFICATION LABELS .................................................................................................................... 21

BABY 02 (WU150) - REV.09 - 02/09/2024

PROFESSIONAL ELECTRONIC BABY SCALE

MOD. BABY02 - WU150 5 KEYS

Read this manual carefully before using the instrument

www.wunder.it

INDEX

WUNDER SA.BI.SRL

Need help?

Do you have a question about the BABY02 and is the answer not in the manual?

Questions and answers

Summary of Contents for WUNDER BABY02

Page 1: Table Of Contents
USER MANUAL WUNDER SA.BI.SRL www.wunder.it PROFESSIONAL ELECTRONIC BABY SCALE MOD. BABY02 – WU150 5 KEYS Read this manual carefully before using the instrument INDEX 1. GENERAL RULES ............................ 2. SAFETY ..............................3. INDICATOR ............................. 4. USABILITY ............................... 5. ISTRUCTION FOR USE ...........................
Page 2: Read This Manual Carefully Before Using The Instrument
By choosing the WUNDER mod. BABY02 professional electronic scale, you have purchased a high precision instrument. Since over 40 years Wunder has placed its experience at the service of health. This instrument is compliant with national standards in hospitals and clinics with medical class Im with measurement function and is calibrated in conformity with accuracy class III.
Page 3: Intended Use
• Do not remove seals from the instrument. • Do not short-circuit the battery terminals • Use only the power supply provided by Wunder. Before using it, make sure that the local mains voltage is compatible with the voltage of the adapter shown on the identification plate •...
Page 4 USER MANUAL 2.2 MANUFACTURER’S GUIDE AND DECLARATION – ELECTROMAGNETIC IMMUNITY The electronic scale BABY02 model is scheduled for operation in the electromagnetic environment specified be- low. The customer and the user should ensure that it is used in that environment Guide and Statement of manufacturer –...
Page 5 USER MANUAL WUNDER SA.BI.SRL Manufacturer’s guide and declaration - Electromagnetic emissions Immunity test IEC 60601 Compliance Level Electromagnetic environment-guidance Portable and mobile RF communications equipment 3Vrms 150kHz to 80MHz (for Conducted RF should be used no closer to any part of the product...
Page 6 WUNDER SA.BI.SRL USER MANUAL Recommended separation distance between BABY 02 scale and mobile RF communications equipment BABY 02 scale is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help prevent electromagnetic interference by...
Page 7: Function Keys
USER MANUAL WUNDER SA.BI.SRL 3. INDICATOR 1. Weighing capacity and division 2. Key function 3. Main LCD: Weight 4. 2° LCD automatically calculates the amount of Milk consumed 5. Power Indicator FUNCTION KEYS KEY NAME DESCRIPTION Key ON. To reset the display (OFF) long press 3 seconds.
Page 8: Time Setting
WUNDER SA.BI.SRL USER MANUAL 4. USABILITY 1. Make sure to place the instrument on a flat and stable surface away from heat sources, in an environment free of excessive vibrations and air currents. 2. Level the instrument to ensure correct measurement.
Page 9 USER MANUAL WUNDER SA.BI.SRL 5.2 REPLACE ALKALINE BATTERIES WITH RECHARGEABLE BATTERY KIT (OPTIONAL) 1. Open the battery compartment placed on the 2. Remove the alkaline batteries container carefully back side of the indicator 3. Disconnect the connector shown in the figure 4.
Page 10 WUNDER SA.BI.SRL USER MANUAL 5.3 ALKALINE BATTERIES REPLACEMENT 1. Open the battery compartment placed on the 2. Remove the alkaline batteries container carefully back side of the indicator 3. Remove the discharged batteries 4. Insert the new alkaline batteries 5. Insert the batteries container first and then gently 6.
Page 11: Instruction For Charging And Connecting
5.6 HOLD FUNCTION BABY02 is provided with the integrated hold function (determination of average value). It enables baby to be weighed accurately even they keep moving. Once the [HOLD] key is pressed, the weight reading will remain on the display after the baby has been removed from the scale so the reading can easily be read.
Page 12: Tare Function
WUNDER SA.BI.SRL USER MANUAL 5.7 USING MEMORY FUNCTION (MILK DIFFERENCE) This function allows automatically calculates the amount of Milk consumed After weighting, the top row display will show the weight, for example: 3.000kg. Press key to store the first weight, the second display will show “m1”.
Page 13: Printer Functions
WU150 II 20K MED PRINT OUT: WU150 II 20K MED PRINT OUT: USER MANUAL WUNDER SA.BI.SRL ENGLISH PRINT OUT: ITALIAN PRINT OUT: 6. PRINTER FUNCTIONS Weight can be printed for records WUNDER WUNDER WUNDER using RS232 interface cable. After Modello...
Page 14: Setting Setup
WUNDER SA.BI.SRL USER MANUAL 7. SETTING SETUP Switch ON the indicator and press key for 3 seconds, display shows “SETUP” and after “A.OFF”. = ▼ go to the next function = ► enter and edit parameters Setting procedure: Tare_Key Hold/BMI_key ON/OFF/Zero_key When the display shows “...
Page 15: Error Messages
During shipping, make sure not to subject the instrument to blows or excessive mechanical stress. In case of repairs or assistance, contact your dealer or an authorised service centre contacting service2@wunder.it or sales@wunder.it. BABY 02 (WU150) - REV.09 - 02/09/2024...
Page 16: Scrapping And Waste Disposal
WUNDER SA.BI.SRL USER MANUAL 10. SCRAPPING AND WASTE DISPOSAL If set aside for a long period, protect those parts which could be damaged due to dust build-up Scrapping When you decide to no longer use this item, we recommend making it unusable. We also recommend making...
Page 17: Warranty
Wunder Service Centre, expenses and relative travel risk are borne by the user. Wunder will not be held liable for damage of any nature caused directly or indirectly to persons, animals or objects resulting from failure to comply with all the instructions indicated in this manual or anyway resulting from improper use.
Page 18: Installation
WUNDER SA.BI.SRL USER MANUAL 13. INSTALLATION After removing the instruments from the packing check the integrity and right contents. Put the scale far from source from of heat e vibration. Put the scale on a stable surface. 13.1 MODEL WITH COLUMN...
Page 19 USER MANUAL WUNDER SA.BI.SRL 13.2 MODEL WITH FRONT DISPLAY N.B. The scale is already packed with the display mounted on the front support. WARNING! Don’t touch the adjustment screw shown in the figure above. Insert weight tray WARNING! The weighing plate must not touch the display for a correct functioning of the scale.
Page 20 WUNDER SA.BI.SRL USER MANUAL 13.3 BABY HEIGHT ROD INSTALLATION For the installation of digital height rod proceed as follow: 1) Apply the digital height rod support on the 2) Insert the digital height rod on the support weighing tray using the 2 supplied cross screws.
Page 21: Conformity
USER MANUAL WUNDER SA.BI.SRL 14. CONFORMITY WUNDER MODEL BABY02 ELECTRONIC SCALE SERIAL N°......... We hereby certify that this instrument has been inspected and has successfully passed the functional test. It complies with the following standards and directives: EN 45501 / EN60601-1-2 / EN60601-1 REGULATION (EU) 2017/745 –...
Page 22 WUNDER SA.BI.SRL USER MANUAL BABY 02 (WU150) - REV.09 - 02/09/2024...
Page 23 USER MANUAL WUNDER SA.BI.SRL BABY 02 (WU150) - REV.09 - 02/09/2024...
Page 24 Wunder Sa.Bi. S.r.l. Via Vecchia per Monza, 20 20056 Trezzo sull’Adda (MI) Tel. +39 02 90964566 www.wunder.it...

This manual is also suitable for:

Wu150 5 keys
