Item #1012 002 050,
xxxx xxx xxx
Model #52411, 52410
UL Model #OSCW-18MD
USE AND CARE GUIDE
18 INCH HENTON WALL MOUNT FAN
Questions?
Before returning to the store, call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this wall mount fan. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY OSCW-18MD
Summary of Contents for HAMPTON BAY OSCW-18MD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this wall mount fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents................2 Operating Instructions..............6 Safety Information................2 Cleaning..................6 Pre-Installation................3 Warranty..................6 Assembly..................4 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of fire or electrical shock, DO NOT use this fan with any solid state speed control device. -
Page 3: Pre-Installation
Pre-Installation TOOLS REQUIRED Phillips Flat head Step Wrench screwdriver screwdriver ladder PACKAGE CONTENTS Part Description Quantity Part Description Quantity Motor assembly Wall mounting bracket Rear grill Blade locking nut Blade Screw Front grill Screw Hexagonal nut / Screw Spring washer HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 4 Assembly Instructions Installing the wall mounting bracket to wall CAUTION: If you are going to attach the fan assembly (A) to a wood stud or wood post or concrete wall, the stud or wood post or concrete wall must be wide enough and thick enough to sustain the wall mounting bracket (F) and the weight of the fan assembly (A).
-
Page 5: Assembly
Assembly Instructions (continued) Attaching motor assembly □ Attach the four long holes at the bottom of fan motor assembly (A) to the four hooks of the wall bracket (F). □ Install the screw (J) into the base screw hole of the motor assembly (A) through the bottom hole of the wall bracket (F) and tighten it. -
Page 6: Operating Instructions
Operating Instructions Speed control □ Plug in and pull the right pull chain to check the power, low, middle, and high speed. Oscillating control □ Pull the left pull chain to check the oscillating switch. OFF-H-M-L ON-OFF Cleaning □ Use soft damp cloth then wipe with dry cloth. Do not use harmful cleaners. Do not bend the blades. Warranty We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. - Page 7 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. Net weight: 15.87 lbs (7.2 kgs) Gross weight: 28.22 lbs (12.8 kgs)
- Page 8 GRACIAS Apreciamos la plena confianza que has depositado en Hampton Bay al comprar este ventilador de techo. Nos esforzamos en crear continuamente productos de calidad diseñados para mejorar tu hogar. Visítanos por Internet para ver nuestra línea completa de productos...
-
Page 9: Información De Seguridad
Tabla de contenido Tabla de contenido...............2 Instrucciones de operación............6 Información de seguridad............2 Limpieza..................6 Preinstalación................3 Garantía..................6 Ensamblaje...................4 Información de seguridad LEE Y GUARDA ESTAS INSTRUCCIONES. ADVERTENCIA: Para reducir el riesgo de incendio o descarga eléctrica, NO uses este ventilador con ningún dispositivo de control de velocidad de estado sólido. -
Page 10: Herramientas Necesarias
Preinstalación HERRAMIENTAS NECESARIAS Destornillador Destornillador de Escalera Llave Phillips Flat head Step Wrench Phillips cabeza plana de tijera screwdriver screwdriver ladder CONTENIDO DEL PAQUETE Pieza Descripción Cantidad Pieza Descripción Cantidad Ensamblaje del motor Soporte de montaje en la pared Rejilla posterior Tuerca de bloqueo de aspa Aspa Tornillo... -
Page 11: Instrucciones De Ensamblaje
Instrucciones de ensamblaje Cómo instalar el soporte para montaje en la pared CUIDADO: Si vas a instalar el ensamblaje del ventilador (A) a una viga o poste de madera o pared de concreto, debe tener el ancho y grosor suficiente para sostener el soporte para montaje en la pared (F) y el peso del conjunto del ventilador (A). - Page 12 Instrucciones de ensamblaje (continuación) Cómo fijar el conjunto del motor □ Conecta los cuatro orificios largos en la parte inferior del conjunto del motor del ventilador (A) a los cuatro ganchos del soporte de pared (F). □ Instala el tornillo (J) en el orificio del tornillo de la base del conjunto del motor (A) a través del orificio inferior del soporte de pared (F) y apriétalo.
-
Page 13: Instrucciones De Uso
Instrucciones de uso Control de velocidad □ Conecta y tira de la cadena derecha para comprobar la potencia y la velocidad baja, media y alta. Control de oscilación □ Tira de la cadena izquierda para comprobar el OFF-H-M-L APAGADO-ALTO-MEDIO-BAJO interruptor oscilante. ON-OFF ENCENDIDO-APAGADO Limpieza... - Page 14 ¿Preguntas, problemas o piezas faltantes? Antes de devolver a la tienda, llama al Servicio al Cliente de Hampton Bay de lunes a viernes de 8 a.m. a 7 p.m. (Hora del Este) o los sábados de 9 a.m. a 6 p.m. (Hora del Este).
