  • Page 1 Model# /DB30TMB-LP/ODB30TBN-LP USE AND CARE GUIDE TRIPLICITY 30 IN. CEILING FAN An electronic copy of this user manual can also be obtained online at homedepot.com...
  • Page 2 WARNING: To reduce the risk of fire, electric shock or injury to persons, do not use replacement parts that have not been recommended by the manufacturer (e.g. parts made at home using a 3D printer). DB30TBN/ORB/WH/MB-LP, ODB30TBN-LP RNBB-YO...
  • Page 3: Warranty

    Warranty LIMITED WARRANTY WHAT IS COVERED The retailer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of fifteen years after the date of purchase by the original purchaser. The retailer warrants that the light kit, excluding any glass, to be free from defects in workmanship and material at the time of shipment from the factory for a period of one year after the date of purchase by the original purchaser.
  • Page 4: Package Contents

    Pre-installation (continued) PACKAGE CONTENTS NOTE: Unpack your fan and check the contents. You should have the following items listed below. i r c i t p y t i i t n i l i h t i Set of blade holders (with blade holder screws pre-installed) ½...
  • Page 5 Remove the split pin and pivot pin (EE) from the loose part bag and set them aside for later restoration. Place the downrod assembly (H) through the ceiling canopy (B). (Figure 4) Carefully feed the fan wires up through the downrod assembly (H).
  • Page 6: Attaching The Fan Blades

    Attaching the fan blades NOTE: Your fan blades are reversible. Select the blade side finish which best accentuates your decor. Failure to follow below procedure could result in fan wobble. Mount the blade holders (D) to the fan blades (E) using the square neck screws (AA), hex nuts (CC) and flat washers (DD) provided - 3 each per blade (Figure 6).
  • Page 7 Figure 10 Figure 10. Do...
  • Page 8: Finishing The Installation

    Finishing the installation Installing the light kit When the electrical connections have been WARNING: To reduce the risk of electric shock , made, take the fan off the hook. Slide the ceiling disconnect the electrical supply circuit to the fan before installing light kit.
  • Page 9 Attaching the pull chain extensions Balancing the blades Attached the pull chain extensions (G) provided to the fan All blades are grouped by weight. Because natural woods vary in and light kit pull chain. (Figure 14) density, the fan may wobble even though the blades are weight matched.
  • Page 10 Operating *NOTE: Wait for the fan to stop before changing the setting of the slide switch. The pull chain controls the fan speed as follows: 1 pull – High, 2 The slide switch controls direction: forward (switch down) or pulls - Medium, 3 pulls – Low, and 4 pulls – off. reverse (switch up).* Warm weather - (Forward) A downward air flow creates a cooling Speed settings for warm or cool weather depend on factors such...
  • Page 13 Núm. de modelo /DB30TMB-LP/ODB30TBN-LP GUÍA DE USO Y CUIDADO VENTILADOR DE TECHO TRIPLICITY DE 30 PLUG.
  • Page 14 ADVERTENCIA: Para reducir el riesgo de incendio descarga eléctrica o lesiones personales, no utilice piezas de repuesto que no hayan sido recomendadas por el fabricante (por ejemplo, piezas fabricadas en casa con una impresora 3D). DB30TBN/ORB/WH/MB-LP, ODB30TBN-LP RNBB-YO...
  • Page 15: Especificaciones

    Garantía El distribuidor garantiza que el motor del ventilador está libre de defectos en materiales y mano de obra presentes en el momento del envío de la fábrica por un periodo de quince años después de la fecha de compra por el comprador original. El distribuidor garantiza, por un período de un año a partir de la fecha de adquisicion por le comprador original, que el kit de luces, sin incluir ningun vidrio, no presentará...
  • Page 16: Contenido Del Paquete

    Pre-instalación (continuación) CONTENIDO DEL PAQUETE NOTA : Desempaque su ventilador y compruebe el contenido. Debe tener los siguientes artículos listados a continuación. p i r n ó d i t r e i a l i t n i Conjunto de soportes de las aspas (con tornillos de soportes de las aspas preinstalados) a l l á...
  • Page 17 Saque el pasador partido y el pasador pivotante (EE) de la bolsa de piezas sueltas y apártelos para su posterior restauración. Coloque la unidad de la vara (H) a través de la cubierta del techo (B) (Figura 4). Pase con cuidado los cables del ventilador por el conjunto del vástago (H).
  • Page 18 Instalación de las aspas del ventilador NOTA : Las aspas de su ventilador son reversibles. Seleccione el acabado lateral del aspa que mejor acentúe su decoración. No seguir el procedimiento anterior puede resultar en bamboleo del ventilador. Monte los soportes de las aspas (D) a las aspas del ventilador (E) con los tornillos de cuello cuadrado (AA), las tuercas hexagonales (CC) y las arandelas planas (DD) incluidas (3 por cada aspa) (Figura 6).
  • Page 19 Figura 10 Figura 10 Conecte los cables de conexión a tierra del ventilador (verde) en la placa de montaje; y la unidad de la vara con el cable de conexión a tierra de la conexión del hogar.
  • Page 20: Finalización De La Instalación

    Instalación (continuación) Instalación del juego de lámparas Finalización de la instalación Una vez realizadas las conexiones eléctricas, quite ADVERTENCIA : Para reducir el riesgo de choque el ventilador del gancho. Deslice la cubierta del techo eléctrico, desconecte el circuito de suministro eléctrico al hacia arriba de la vara, asegurándose de que la ranura ventilador antes de instalar el juego de lámparas.
  • Page 21 Instalación (continuación) Cómo instalas las extensiones de Cómo equilibrar las aspas cadena del interruptor Conecta las extensiones de cadena de interruptor (G) Todas las aspas están agrupadas por peso. Debido a que las maderas naturales varían en densidad, el ventilador puede suministradas a las cadenas de los interruptores del ventilador y bambolear incluso si las aspas concuerdan en peso.
  • Page 22 Figura 15 Figura 16 Figura 15 Figura 16 DB30TBN/ORB/WH/MB-LP, ODB30TBN-LP...
