EtherEZ Hubs
Ethernet Workgroup Hubs
10BASE-T Models
Easy Access to an Ethernet Network!
SMC's trio of EtherEZ
network. They're plug and play, so there's no configuration necessary.
And, the price is very affordable, so they're the ideal choice for small
workgroups.
These standalone, 10BASE-T hubs feature SMC's EtherEZ Watch
Indicator Panel with a comprehensive array of LEDs. There are
LEDs that display the link, traffic and partition status of each port.
There are also LEDs that display network utilization and collision
levels. These levels are monitored by an on-board microprocessor or
internal circuitry to simplify installation and troubleshooting. For
convenience, each hub also features a daisy-chain port so you can
easily cascade hubs as your network grows.
The compact, 5-port model includes a hub stand so you can mount
it on a wall or on a desktop in either an upright or flat position. The
8-port desktop model features a small form factor and bottom-panel
cutouts so you can also mount it directly on a wall in any position.
This model includes an additional BNC port with T-Connector for
connection to a thin coax backbone. The 16-port, rack-mountable
model includes brackets so you can mount it in a standard 19-inch
equipment rack. And, there are two additional ports (BNC and AUI)
and a BNC T-Connector for connection to a larger, distributed
topology network.
All three EtherEZ models are available with a choice of power
supplies or external line cords for the worldwide
market. They're backed by a lifetime warranty
and free technical support, so you can be sure
you're getting the quality, reliability and value
you've come to expect from SMC.
®
™ hubs offers easy access to an Ethernet
Features/Benefits
Compatible
IEEE 802.3 and ISO/IEC 8802-3 standards
Easy to Install and Use
Plug and play—no software, no switches,
nothing to configure
EtherEZ Watch Indicator Panel with
comprehensive array of hub monitoring
and port status LEDs
Daisy-chain port for convenient connec-
tion to another hub
Automatic port partitioning and recon-
nection isolates problem until faults are
corrected
Jabber lock-up protection prevents data
loss
Automatic polarity detection and correc-
tion on twisted-pair ports
Versatile
Choice of three port densities: 5, 8 and 16
Choice of six power supplies (5- and
8-port models) or external line cords
(16-port model) for the worldwide market
Suitable for desktop and wall mounting or
desktop and rack mounting
Additional port(s) on 8- and 16-port
models for backbone or mixed media
connectivity
Reliable
Lifetime warranty
FCC Class B certified (5- and 8-port
models only)
