- Page 1 Shenzhen Linshang Technology Co., Ltd. LS178 Colorimeter User Manual V1.00 QR code for app installation https://www.linshangtech.cn/a/170/ Please read this manual carefully before using and reserve it for reference. 25/12/2024 Page 1 of 15...
-
Page 2: I Product Introduction
Shenzhen Linshang Technology Co., Ltd. I Product Introduction The small-aperture split-type multifunctional colorimeter, with a 1 mm measuring aperture, is ideal for measuring the color of small workpieces and irregularly shaped materials. The probe and main unit are designed separately, making it easy to align the probe with small objects. The probe can also be inverted, with the measuring aperture facing upward, allowing small objects to be placed on the aperture for measurement without affecting the reading. - Page 3 Shenzhen Linshang Technology Co., Ltd. Measurement conditions Light source D65, field of view 10° Measuring time About 1s CIE Lab, Luv, LCh, Yxy, CMYK, RGB, WI-98, WI-Gauz, WI- Color space Hunter, YI-98, WI-R457, HSL, HSV, Spectra ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1) , ΔE*cmc(1.4:1), Color difference formula ΔE*00...
-
Page 4: Operation
Shenzhen Linshang Technology Co., Ltd. operation. Contains multiple electronic color charts, which can quickly match the closest color code with matching accuracy rate greater than 90%. QC testing function: the color difference threshold can be set and a variety of color difference formulas are optional. - Page 5 Shenzhen Linshang Technology Co., Ltd. For failed calibration, the possible reasons are as below: The standard tile is not closed properly; The standard tile needs to clean; The attenuation of the light source leads to failure of normal use and it needs to be returned to the factory for inspection and repair.
- Page 6 Shenzhen Linshang Technology Co., Ltd. To enter the main measurement interface, there are two modes: "Color Scan" and "Color Compare". You can press the button at the bottom of screen to switch and the selected mode will turn blue .
- Page 7 Shenzhen Linshang Technology Co., Ltd. 3.1 Color Compare In the measurement interface, press the "Scan Standard" button to set current value as standard. Press the "Scan Sample" button to use current value as sample. If short press the power button side, another measurement will also be taken and the current value will replace the previous one.
- Page 8 Shenzhen Linshang Technology Co., Ltd. Pass The following steps can be performed after completing compare measurement: Save To save the comparison result, press "Save" on the upper right corner. You can choose default or name the record manually. ...
- Page 9 Shenzhen Linshang Technology Co., Ltd. 3.2 Color Scan In the measurement interface, click on "Scan" or short press the button on the right side of the instrument to measure. Matching colors: According to the selected color chart by the user, the closest three color chart numbers are matched for display.
-
Page 10: Bluetooth Connection
Shenzhen Linshang Technology Co., Ltd. 4.1 Language Support Simplified Chinese and English. 4.2 Calibration Can enter the calibration interface to perform calibration operation of the instrument. 4.3 Device Info "Device Info" displays the basic information of the instrument, including: Serial Number, Firmware Version, and Device Status. -
Page 11: Device Connection
Shenzhen Linshang Technology Co., Ltd. download and install LScolor. App icon Precautions: Open the App during the installation process or after the first installation, the mobile phone will prompt the permission of setting, the customer needs to allow all of them, otherwise the App cannot search for the device, and App cannot be used. - Page 12 Shenzhen Linshang Technology Co., Ltd. "import_mycolor" and long press the file to be imported. If use the iOS system, click the file and download it first, and then select "Open with other app" to realize data sharing. If the above interface appears, click "Open with other app" and select the App "LScolor", after confirmation, jump to the import interface and select the file to complete the import.
- Page 13 Shenzhen Linshang Technology Co., Ltd. printing, etc. For specific operation, please refer to the "Color Haze Meter Software Operation Manual". VII Precaution The surface of the measured object should be smooth, flat, clean and opaque within the aperture range; otherwise, measurement accuracy may be affected.
-
Page 14: Packing List
Provide users with spare parts and lifelong maintenance services. Provide the users with the gauge calibration service. Free technical support for long term. Manufacturer: Shenzhen Linshang Technology Co., Ltd. Website: www.linshangtech.com 25/12/2024 Page 14 of 15... - Page 15 Shenzhen Linshang Technology Co., Ltd. Service hotline: +86-755-86263411 Email: sales21@linshangtech.com 25/12/2024 Page 15 of 15...
