- Page 1 Shenzhen Linshang Technology Co., Ltd. LS155 Color Haze Meter User Manual V1.01 Please read this manual carefully before using and reserve it for reference. 2024-03-12 Page 1 of 10...
-
Page 2: I Product Introduction
Shenzhen Linshang Technology Co., Ltd. I Product Introduction The instrument is a multifunctional color haze meter. It adopts full spectrum LED light source and spectral sensor design, which is used for the measurement of haze, transmittance and color of various... - Page 3 Shenzhen Linshang Technology Co., Ltd. Haze resolution 0.01% Haze accuracy Better than ±2% ≤0.03 (The standard deviation of 30 times measurements of a haze Haze repeatability standard with haze measurement of approximately 30 at 3s intervals after calibration) Color resolution 0.01...
- Page 4 Shenzhen Linshang Technology Co., Ltd. IV Operation 1. Power on/off Power on: Plug in the power supply, short press the right side button to turn on the instrument. Power off: Long press the right side button to turn off or press “Power off” in the menu bar.
- Page 5 Shenzhen Linshang Technology Co., Ltd. Entering the measurement interface, you can click the " Compare" on the top of the screen to switch the compare measurement mode. 3.1 Compare off In the measurement interface, click on "Scan" or short press the button on the right side of the instrument to measure.
- Page 6 Shenzhen Linshang Technology Co., Ltd. The following steps can be performed after completing measurement: ⚫ Save To save the comparison result, press "Save" on the upper right corner. You can choose default or name the record manually. ⚫ History If users need to view the saved results, click "History" to view the records, and records can be paged, deleted, renamed and searched.
- Page 7 Shenzhen Linshang Technology Co., Ltd. When the measurement parameter is selected as Lab, LCh, or Yxy, ΔE is calculated using the ΔE*ab color difference formula; ◆ QC test Suitable for color difference inspection in production process. If ΔE is higher than the set threshold, it will read “NG”...
- Page 8 Shenzhen Linshang Technology Co., Ltd. ⚫ Input standard The user can manually input the Haze, Transmittance, Lab, LCh, Yxy value as standard. ⚫ Tolerance Setting Setting the threshold for QC inspection. 4. Menu bar In the measurement interface, click the "...
- Page 9 Shenzhen Linshang Technology Co., Ltd. V PC Software You can use the PC software to connect the computer via USB. The software has functions of compare measurement, reading compare record, export compare data to Excel, qualified number, unqualified number, total number statistics, report generation and printing, etc. For specific operation, please refer to the "Color Haze Meter Software Operation Manual".
-
Page 10: Packing List
Provide users with spare parts and lifelong maintenance services. Provide the users with the gauge calibration service. Free technical support for long term. Manufacturer: Shenzhen Linshang Technology Co., Ltd. Website: www.linshangtech.com Service hotline: +86-755-86263411 Email: sales21@linshangtech.com...
