Topdon RLink J2534 Quick User Manual

Quick User Guide
RLink J2534
All-in-one Pass-thru Device
Thank you for purchasing the TOPDON RLink J2534. This quick user guide
will walk you through the basic setup and operation of the RLink J2534.
Please carefully read all the instructions before use. For further information,
please download the detailed user manual via www.topdon.com/products/
RLink-J2534.
+86-755-21612590
TEL
+34 930 038 094 (Europe)
EMAIL SUPPORT@TOPDON.COM
WEBSITE WWW.TOPDON.COM
FACEBOOK @TOPDONOFFICIAL
X @TOPDONOFFICIAL
FCC Statement
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
+1-833-629-4832 (North America)
Product Overview
OBD-II
Diagnostic
Port
Communication
Indicator
LED Indicators
Connection Indicator
Power Indicator
Communication Indicator
Activate Device & Download Software
①
Download and install the RLink Platform software to your PC.
Go to www.topdon.com. Click Diagnostic Tools > RLink J2534.
Then click Download and click
Note: It is recommended to disable antivirus software during
installation. Because RLink Platform is the driver management
platform for OEM software. It may be mistakenly removed by antivirus
software.
②
Launch the RLink Platform software. Register or log in to your TOPDON
account. Connect the RLink J2534 to a PC using the supplied USB 2.0
cable. Then click Bind and Activate to activate the RLink J2534.
Note: Upgrade the firmware to the latest version after binding the
device.
Power
Indicator
Connection
Indicator
USB Type-C Port
Solid Blue: PC connected
Solid Red: power on
Flashing Green: communicating with the
vehicle
.
