Summary of Contents for FOOTAGE C165-A2
- Page 1 Owner’s Manual C165-A2 Remote Steel / Riser Squeeze Off Tool Phone (905) 695-9900 Toll Free 1 (888) 737-3668 54 Audia Crt. Vaughan, ON, Canada L4K 3N4...
-
Page 2: Safety Warning
Ensure the grounding system is properly planted in the soil to reduce the chances of static discharge. Do not modify or alter the tool in any way. Only use Footage Tools replacement parts provided by the manufacturer or authorized distributor. - Page 3 C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD SAFETY WARNING: WARNING: WHEN OPERATING THIS TOOL, SAFETY EQUIPMENT INCLUDING SAFETY GLASSES ARE REQUIRED BEFORE PERFORMING A SQUEEZE, CLEAN THE POCKETS ON UNDERSIDE OF LOWER BAR AND WHERE THE SIDE SHAFT WILL CONTACT THE LOWER BAR.
-
Page 4: Preliminary Assembly
C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD This Footage Tools’ Hydraulic Squeeze Off Tool is offered with manual release only. The pump is also equipped with a one way safety valve, which can assist in preventing the tool from opening accidentally - turn clockwise to engage. - Page 5 C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD OPERATING INSTRUCTIONS: A. Installation of Pipe Carefully inspect the hydraulic hose to ensure there are no cuts or leaks. Ensure the hydraulic...
- Page 6 C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD OPERATING INSTRUCTIONS: B. Squeezing the Pipe Position the tool centrally over the pipe to be squeezed, so that the pipe is in contact with the centering devices Figure 6 located on both sides of the tool.
- Page 7 C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD OPERATING INSTRUCTIONS: C. Releasing the Pipe With the pipe squeezed and the pump control valve in the squeeze position; carefully turn the control knob to the open position then very slowly turn the control valve towards the release position while watching the tool bars.
- Page 8 C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD PRELIMINARY ASSEMBLY PROCEDURE FOR SIDE GUIDES: Install the guide stop (item #42) over the tool (Figure 11). Use the Socket Head Cap Screws (Item #43) and the .”...
- Page 9 C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD OPERATING INSTRUCTIONS: D. Safety Precautions WARNING: When squeezing a ¾” SCH40 steel pipe, DO NOT exceed the recommended 7500 PSI hydraulic pressure (Figure 13).
-
Page 10: Specifications
C165-A2 Hydraulic Steel Squeeze Off Tool DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD MAINTENANCE This section contains maintenance instructions for the tool. Do not attempt any maintenance which you do not fully understand, nor that you cannot do accurately and safely with the tools and equipment available to you. - Page 13 FOOTAGE TOOLS INC. within thirty (30) days from the date of purchase. This warranty and any possible liability of FOOTAGE TOOLS INC. hereunder are in lieu of all other warranties, expressed, implied, or statutory, including, but not limited to, any warranties of merchantability or fitness for a particular purpose.
