Summary of Contents for FOOTAGE C50
- Page 3 ECN 1813 C50 (1 ¼ inch) MANUAL SQUEEZE OFF TOOL 2 of 6 Page FOR PE PIPE DO NOT OPERATE THESE TOOLS UNLESS THESE INSTRUCTIONS HAVE BEEN CAREFULLY READ AND UNDERSTOOD Preliminary Assembly: To connect C615-A105 static grounding kit, mount the grounding tool lead to the head with the ¼”...
- Page 4 ECN 1813 C50 (1 ¼ inch) MANUAL SQUEEZE OFF TOOL 3 of 6 Page FOR PE PIPE Squeezing the Pipe Set the gauge plate stops on either side of the unit to the proper pipe size and SDR setting. Ensure both sides are identical or tool damage may result.
-
Page 5: Maintenance
ECN 1813 C50 (1 ¼ inch) MANUAL SQUEEZE OFF TOOL 4 of 6 Page FOR PE PIPE Releasing the Pipe To avoid any damage to the plastic pipe, it is critical that a slow release rate be achieved. A release rate of 1/2 inches per minute is acceptable. This time allows for the plastic to "flow"... - Page 7 FOOTAGE TOOLS INC. authorized dealership in a manner of which, in the sole judgement of FOOTAGE TOOLS INC.
