Backyard Discovery BEAUMONT 2405028 Manual
Backyard Discovery BEAUMONT 2405028 Manual

Backyard Discovery BEAUMONT 2405028 Manual

12x12 pergola

Advertisement

Quick Links

Manufactured by:
Backyard Discovery
3305 Airport Drive, Pittsburg, KS 66762
800-856-4445
Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476
J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands Phone: 08005678990
BEAUMONT 12X12 PERGOLA
MODEL: # 2405028
For the most up to date assembly manual, to register your product, or to order replacement parts
Please visit www.backyarddiscovery.com
Para obtener instrucciones en español, visite www.backyarddiscovery.com
3D INTERACTIVE INSTRUCTIONS
ONLY AVAILABLE IN NORTH AMERICA
EASY STEP-BY-STEP
DOWNLOAD THE FREE APP
INS-2405028-A-BEAUMONT 12X12 PERGOLA ENG 9-6-2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the BEAUMONT 2405028 and is the answer not in the manual?

Questions and answers

Summary of Contents for Backyard Discovery BEAUMONT 2405028

  • Page 1 Manufactured by: Backyard Discovery 3305 Airport Drive, Pittsburg, KS 66762 800-856-4445 Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476 J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands Phone: 08005678990 BEAUMONT 12X12 PERGOLA MODEL: # 2405028 ONLY AVAILABLE IN NORTH AMERICA Please visit www.backyarddiscovery.com...
  • Page 2 OWNER'S MANUAL - BASIC SETUP DIMENSIONS & ASSEMBLY NOTES It is critically important that you start with square and level footings or concrete pad to attach your structure − Pay close attention to the items needed for each step. Make sure you are using the correct hardware for each step.
  • Page 3 OWNER'S MANUAL - ANCHORING LAYOUT 114" 2896mm 107 13/16" 2738mm NOTE: DIMENSIONS ARE TO ANCHOR PLATES MOUNTED TO POSTS EXCEPT WHERE NOTED. 4" 101mm METAL ANCHOR PLATES 1 11/16" 4 ANCHORS 43mm PER POST 3 3/8" 86mm DETAIL 'A'...
  • Page 4 OWNER'S MANUAL - PARTS IDENTIFICATION WOOD COMPONENTS (NOT TO SCALE) JOIST END - W4L 15500 JOIST END - W4L 15501 (x4) 1 3/8"X5 1/4"X35 1/2" (36x134x902) (x4) 1 3/8"X5 1/4"X35 1/2" (36x134x902) JOIST END -W4L20658 JOIST END - W4L20657 (x2) 1 3/8"X5 1/4"X39 3/4"...
  • Page 6 OWNER'S MANUAL - PARTS IDENTIFICATION Hardware Components H100202 | SCREW PWH BLK (x4) | 8x5/8 H100630 | WASHER FLAT BLK H100198 | WASHER LOCK EXT BLK | 8x19 (x16) (x138) | 8x19 H100200 | SCREW PFH BLK (x16) | 8x1-1/2 H100405 | WASHER LOCK EXT BLK H100379...
  • Page 7 OWNER'S MANUAL - PARTS IDENTIFICATION Hardware Components H100147 | TORX BIT (x1) | T-30 H100764 | SCREW SETTER (x1) | H100114 | TORX WRENCH | T-30 (x1) H101100 | MAGNETIC DRIVER (x1)
  • Page 9: Hardware Parts

    PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the wood and hardware. WOOD PARTS: − Organize wood parts by the three-digit, alpha-numeric number stamped on each board (ex. P01). −...
  • Page 11 PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
  • Page 15 STEP 4 - PERGOLA ASSEMBLY QTY PART NUMBER DESCRIPTION H100198 WASHER LOCK EXT 8x19 H100379 T-NUT 5/16 BLK H100459 BOLT WH 5/16x1 1/4 BLK JOIST - W4L 15506 (x2) 1 3/8"X5 1/4"X83 1/8" (36x134x2112) - INSERT T-NUTS FIRST. - HAND TIGHTEN ONLY. - COMPLETE THIS STEP TWICE.
  • Page 16 STEP 5 - PERGOLA ASSEMBLY QTY PART NUMBER DESCRIPTION H100198 WASHER LOCK EXT 8x19 H100379 TNUT-5/16" BLK H100405 WASHER LOCK EXT 6x15 POST - W2A04448 H100792 LAG SCREW WH 1/4x3 BLK (x2) 6"X6"X89 1/2" (152x152x2274) H101058 BOLT WH 5/16x8 3/4 BLK POST - W2A04449 (x2) 6"X6"X89 1/2"...
  • Page 23 STEP 12 - PERGOLA ASSEMBLY QTY PART NUMBER DESCRIPTION H100201 SCREW PFH 8x2 1 /2 BLK PURLIN ASSEMBLY (x14)- FROM STEP 11 -ALIGN PILOT HOLES. -WHEN LIFTING UP EACH PURLIN ASSEMBLY, ENSURE THAT JOINTS ARE SUPPORTED AND PURLIN IS KEPT LEVEL. -TO AVOID WOOD SPLITTING OUT, IT IS RECOMMENDED THAT A 1/8"...
  • Page 27: Electrical Enclosure

    PowerPort™ 9205413 ELECTRICAL ENCLOSURE (x1) FOR POWERPORT INSTALLATION REFER TO ASSEMBLY INSTRUCTIONS THAT COME PACKAGED WITH THE POWERPORT KIT. INSTALL ON ANY POST THAT IS DESIRED. FOLLOW DIRECTIONS FOR PROPER INSTALLATION.
