MODEL # : 2406063
Gazebo
Please visit www.backyarddiscovery.com
For the most up to date assembly manual, to register your product, or to order
replacement parts Para obtener instrucciones en español, visite
www.backyarddiscovery.com
EASY STEP-BY-STEP
3D INTERACTIVE INSTRUCTIONS
DOWNLOAD THE FREE APP
INS-2406063-A-14x12 ARCADIA GAZEBO-ENG 8-28-2024
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Backyard Discovery Arcadia 2406063
Summary of Contents for Backyard Discovery Arcadia 2406063
- Page 1 Manufactured by: Backyard Discovery 3305 Airport Drive, Pittsburg, KS 66762 800-856-4445 Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476 J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands Phone: 08005678990 14 12 Gazebo MODEL # : 2406063 Please visit www.backyarddiscovery.com...
- Page 2 OWNER'S MANUAL - BASIC SETUP DIMENSIONS & ASSEMBLY NOTES It is critically important that you start with square and level footings or concrete pad to attach your structure − Pay close attention to the items needed for each step. Make sure you are using the correct hardware for each step.
- Page 3 OWNER'S MANUAL - ANCHORING LAYOUT 11'-7 5/16" 3538mm 11'-1 5/16" 3386mm 10'-7 5/16" 3234mm 4" 101mm NOTE: DIMENSIONS ARE TO ANCHOR PLATES MOUNTED TO POST EXCEPT WHERE NOTED. 1 11/16" 43mm 3 3/8" METAL ANCHOR PLATES 86mm DETAIL A...
- Page 7 OWER'S MANUAL - PARTS IDENTIFICATION HARDWARE COMPONENTS H100147 | TORX BIT H101100 | MAGNETIC (x1) T-30 (x1) DRIVER H100764 | SCREW SETTER (x1) H101106 | SOCKET DRIVER (x1) H100378 | BOLT WH BLK | 5/16 x 1 3/4 (x12) H100114 | TORX WRENCH (x1) | T-30...
- Page 8 OWER'S MANUAL - PARTS IDENTIFICATION HARDWARE COMPONENTS H100653 | NUT LOCK BLK H100630 | WASHER FLAT BLK H100405 | WASHER LOCK EXT BLK | 8 x 19 (x12) | 1/4 (x28) | 6 x 15 (x8) H100198 | WASHER LOCK EXT BLK H100379 | T-NUT BLK H100192...
- Page 9 PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the wood and hardware. WOOD PARTS: − Organize wood parts by the three-digit, alpha-numeric number stamped on each board (ex. P01). −...
- Page 10 PRE-ASSEMBLY STEP 2 - TOOLS REQUIRED Drill Attachments: Phillips Head Open End Wrenches 1/2" & 7/16" 1/8", 3/16", 3/8" & 7/16" Drill Bits Cordless Drill or Electric Drill 3/8" Drive Ratchet, 1/2" & 7/16" STD Sockets, 1/2" & 7/16" Deep Sockets Phillips Screw Driver 3/8 &...
- Page 11 PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
- Page 57 PowerPort™ 9205413 ELECTRICAL ENCLOSURE (x1) FOR POWERPORT INSTALLATION REFER TO ASSEMBLY INSTRUCTIONS THAT COME PACKAGED WITH THE POWERPORT KIT. INSTALL ON ANY POST THAT IS DESIRED. FOLLOW DIRECTIONS FOR PROPER INSTALLATION.
