Hot/Cold/Frozen Modular Drop-Ins
Thank you for purchasing this Vollrath® product! Save this manual for reference and the packaging in case shipping is necessary.
SAFETY PRECAUTIONS
To help ensure safe use, please read and fully understand this manual and all safety messages before operation!
WARNING
Warning indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Caution indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTICE:
addresses practices not related to physical injury.
To reduce risk of injury or damage to the unit
• Equipment must be installed by a qualified person
• Use only grounded electrical circuits and outlets that match the nameplate-rated voltage. Do not use extension cords or power strips of any kind.
• Never modify the wiring, cord, or plug. This could damage the unit and cause injury and will void the warranty.
• Use in a flat, level position.
• Keep unit and power cord away from open flames, electric burners, and excessive heat.
• Only operate the hot well with water.
• Use pans 6" (15.2 cm) or less in depth.
• Only operate properly functioning, undamaged units.
• Always attend the unit when operating.
• Do not set anything on the top surface.
UL GUIDANCE FOR PRODUCTS WITH R290 REFRIGERANT
This product utilizes R290 Refrigerant. Follow all safety precautions for use of R290.
Per UL, the following is an explanation of the characters marked on the appliance. All models are Test Room Climate Class 5.
FC-HCF-XXYYY-ZZZ
• FC: Fabricator Component
• HCF: Hot/Cold/Frozen Modular Drop-Ins
• XX: Pan Size
• YYY: Voltage
• ZZZ: Optional suffix to indicate Auto Drain (AD) or Flat Flange (FF) Top
WARNING
Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance..
Operator's Manual
Part 355922-1
1/17/2025

Advertisement

loading
Need help?

Need help?

Do you have a question about the FC-HCF-01120-AD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vollrath FC-HCF-01120-AD

Summary of Contents for Vollrath FC-HCF-01120-AD

  • Page 1 Operator's Manual Hot/Cold/Frozen Modular Drop-Ins Thank you for purchasing this Vollrath® product! Save this manual for reference and the packaging in case shipping is necessary. SAFETY PRECAUTIONS To help ensure safe use, please read and fully understand this manual and all safety messages before operation! WARNING Warning indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 2 Appliance is to be installed in accordance with the Safety Standard for Refrigeration Systems, ANSI/ASHRAE 15. WARNING • Do not use means to clean, other than those recommended by Vollrath®. • The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.
  • Page 3 UL GUIDANCE FOR PRODUCTS WITH R290 REFRIGERANT CONTINUED WARNING Prior to beginning work on systems containing FLAMMABLE REFRIGERANTS, safety checks are necessary to ensure that the risk of ignition is minimized. For repair to the REFRIGERATING SYSTEM, the following steps shall be completed prior to conducting work on the system.
  • Page 4 UL GUIDANCE FOR PRODUCTS WITH R290 REFRIGERANT CONTINUED WARNING Repairs to sealed components • During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.

  • Page 5: Record Your Serial Number

    UL GUIDANCE FOR PRODUCTS WITH R290 REFRIGERANT CONTINUED WARNING Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of recovered refrigerant.

  • Page 6: Unpacking The Unit

    ITEMS & MODELS FC-HCF-03208-AD Item/Model Description FC-HCF-01120-AD 1-Well Auto Drain, 120V FC-HCF-03120 3-Well, 120V FC-HCF-01120-AD-FF 1-Well Auto Drain, Flat Flange, 120V FC-HCF-03120-AD 3-Well Auto Drain, 120V FC-HCF-01208-AD 1-Well Auto Drain, 120/208–240V FC-HCF-03120-AD-FF 3-Well Auto Drain, Flat Flange, 120V FC-HCF-01208-AD-FF 1-Well Auto Drain, Flat Flange 120/208–240V...

  • Page 7: Operation

    BEFORE FIRST USE Unit must be thoroughly cleaned and dried before use per the cleaning section of this manual. OPERATION WARNING Electrical Shock Hazard. Keep water and other liquids from entering the unit. Liquid inside the unit could cause an electrical shock or short circuit. Do not immerse the cord, plug, or unit in water or any other liquid, spray liquids onto the unit, or operate if the unit or cord are damaged or altered.

  • Page 8: Daily Cleaning

    WARRANTY STATEMENT FOR THE VOLLRATH CO. L.L.C. The Vollrath Company LLC warrants to the original commercial end user that each of Vollrath’s foodservice products will be free from defects in materials and workmanship.

This manual is also suitable for:

Fc-hcf-01120-ad-ffFc-hcf-01208-adFc-hcf-01208-ad-ffFc-hcf-02120Fc-hcf-02120-adFc-hcf-02120-ad-ff ... Show all
