STEP DESCRIPTION
23 Profile End Control
After selecting the Profile End Control parameter value, press the SCROLL key to advance
the display to Pn. Press the UP key with Pn or any parameter code displayed to exit the
Profile Entry Mode.
* Event outputs will remain in their current status during an error condition (i.e. Sensor break
SnSr) and upon entering the Profile Continue mode PCon but will turn off when entering other
non-control modes (i.e. Program Mode Prog).
** All values except Profile Loop Count PLCt are initialized to zero and all event outputs are
initialed to OFF, with the exception of hte first profile. Profle Loop count PLCt is set to 1.
The first profile has the number of segments initalized to zero, to turn the profile OFF, but the
profile has values stored in it for demonstration purposes. By setting the number of seg-
ments to two, the profile can be reviewed and/or executed.
PROFILE 1 VALUES FOR DEMONSTRATION PURPOSES
Code Value
rt .10
SP 100
E1 on
E2 oFF
E3 oFF
St .10
E1 oFF
E2 on
E3 oFF
rt .10
SP 0
E1 oFF
E2 oFF
E3 on
St .10
E1 oFF
E2 oFF
E3 oFF
PLct 1
dhru 0
dhrd 0
PEnd 0
DISPLAY AVAILABLE
CODES SETTINGS
PEnd -1=Hold at least setpoint
0= Abort- all outputs off or
at 0% Event off
1=Transfer to profile 1
2=Transfer to profile 2
3=Transfer to profile 3
4=Transfer to profile 4
5=Transfer to profile 5
6=Transfer to profile 6
7=Transfer to profile 7
8=Transfer to profile 8
Ramp Time
Setpoint
Event 1 on
Event 2 off
Event 3 off
Soak Time
Event 1 off
Event 2 on
Event 3 off
Ramp Time
Setpoint
Event 1 off
Event 2 off
Event 3 on
Soak Time
Event 1 off
Event 2 off
Event 3 off
Profile Loop Count
Deviation Hold after Ramp Up - None
Deviation Hold after Ramp Down - None
Profile End Control - Abort - oFF mode
FACTORY YOUR
SETTING SETTING
0
