Partlow MRC 7000 Installation, Wiring, Operation Manual page 38

38
TABLE 3-3 PROFILE ENTRY MODE CONFIGURATION PROCEDURE
Depress and release the SCROLL key until PEnt is displayed. Use the DOWN key to enter
the Profile Entry mode. Depress the SCROLL key to scroll through the parameters and their
values. Use the UP and DOWN keys to adjust the values. After adjusting a parameter,
depress the SCROLL key to proceed to the next parameter. After all selections have been
made, to exit the mode, depress the UP key with a parameter in the display (not a setting) to
exit the mode. For assistance in developing the Profile, refer to Appendix F (page 81).
STEP DESCRIPTION
1 Profile Number
2 Number of Segments
Steps 3 - 18 are repeated for each segment
3 Ramp Time
4 Setpoint Pen 1
4A Setpoint Pen 2
Note: will appear on lower display if Pen 2 is present
5 *Event Output 1
6 *Event Output 2
7 *Event Output 3
8 *Event Output 4
9 *Event Output 5
10 *Event Output 6
11 Soak Time
12 *Event Output 1
13 *Event Output 2
14 *Event Output 3
15 *Event Output 4
16 *Event Output 5
17 *Event Output 6
18 Profile Loop Count
19 Deviation Hold after
Ramp Up for P en 1
20 Deviation Hold after
Ramp Down for Pen 1
21 Deviation Hold after
Ramp Down for Pen 2
22 Deviation Hold after
Ramp Down for Pen 2
DISPLAY AVAILABLE
CODES SETTINGS
Pn 1 to 8
nS 0-6 segments
rt 0 to 9999 units per Ptb
SP1 Setpoint at end of Ramp
SP2 Setpoint at end of Ramp
E1 on or off
E2 on or off
E3 on or off
E4 on or off
E5 on or off
E6 on or off
St 0 to 9999 units per Ptb
E1 on or off
E2 on or off
E3 on or off
E4 on or off
E5 on or off
E6 on or off
PLCt 0 to 9999, 0=continuous
dhru 0 to 3000 units,
0=no auto hold
dhrd 0 to 3000 units,
0=no auto hold
dhru 0 to 3000 units,
0=no auto hold
dhrd 0 to 3000 units,
0=no auto hold
FACTORY YOUR
SETTING SETTING
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
**
